ELECTRICAL CHARACTERISTICS (Ta=25 deg C Unless otherwise Specified)
Device
VZT
@IZT*
rZT
@IZT*
IZT
rZK
IZK
Temp. Coeff
of
IR
Ta=
@
VR IZM IZSM##
@IZK
Zener Voltage 25 deg C 150degC
min
(V)
max max
(V) (ohm) (mA) (ohm) (mA)
max
typ
(%/deg C)
+0.09
max
(uA)
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
max
(uA)
10
10
10
10
10
10
10
(V) (mA)
(mA)
288
260
238
219
203
181
167
154
BZX85C 27
BZX85C 30
BZX85C 33
BZX85C 36
BZX85C 39
BZX85C 43
BZX85C 47
BZX85C 51
25.10 28.90 30
28.00 32.00 30
31.00 35.00 35
34.00 38.00 40
37.00 41.00 50
40.00 46.00 50
44.00 50.00 90
48.00 54.00 115
8.0
8.0
8.0
8.0
6.0
6.0
4.0
4.0
750
0.25
20
22
24
27
30
33
36
39
41
36
33
30
28
26
23
21
1000 0.25
1000 0.25
1000 0.25
1000 0.25
1000 0.25
1500 0.25
1500 0.25
+0.09
+0.09
+0.09
+0.09
+0.09
+0.09
+0.09
10
*Pulse Condition : 20ms <=tp<=50ms, Duty Cycle =2%
## Rectangular wave form (tp=10ms)
DO-41 Glass Axial Package
A
B
A
DIM
MIN
MAX
A
B
C
D
27.90
4.06
0.71
2.03
—
5.51
0.87
2.72
NOTES
1. Cathode is marked by Band.
2. All dimensions are in mm.
DO-41, 52mm Taping Specification
5.50
4.50
52 mm Taping Specification
1.5 R M AX.
T & A indicates Axil Tape & Ammo packing (52 mm
Tape Spacing).
1.
2. 300 mm (min) leader tape on every spool.
3. No. of empty places allowed 0.25% without
consecutive empty places.
4. Ends of leads shall preferably not protrude beyond
the tapes.
5. Components shall be held sufficiently in the tap e or
tapes so that they can not come free in normal
handling.
LEADER
52.0
48.0
11 DIODES
All dimensions in m m .
TAPES
LABEL
DO-41:- 2500 pcs./Ammo Pack
DIODE AMMO PACK
On request also available in 26 mm Tape and Ammo Pack
