Ordering Information
DX - 170 0 - B A J - 400 1 - 10M0000000
Frequency
Product Family
DX: DOCXO
Frequency Control
1: 0.25 to 0.75ppm
Package
25x38mm
Height
0: A19.00mm
Stability Code
400: 0.4ppb
200: 0.2ppb
Supply Voltage
B: +12V
D: +5V
Temperature Range
J: -20°C to +70°C
T: 0°C to +70°C
RF Output Code
A: HCMOS
E: Sinewave
Notes:
1. Contact factory for improved stabilities or additional product options. Not all options and codes are available at all
frequencies.
2. Unless other stated all values are valid after warm-up time and refer to typical conditions for supply voltage, frequency
control voltage, load, temperature (25°C).
3. Phase noise degrades with increasing output frequency.
4. Subject to technical modiꢁcation.
5. Contact factory for availability.
For Additional Information, Please Contact
USA:
Europe:
Vectron International
Landstrasse, D-74924
Neckarbischofsheim, Germany
Tel: +49 (0) 3328.4784.17
Asia:
Vectron International
1F-2F, No 8 Workshop, No 308 Fenju Road
WaiGaoQiao Free Trade Zone
Pudong, Shanghai, China 200131
Tel: 86.21.5048.0777
Vectron International
267 Lowell Road
Hudson, NH 03051
Tel: 1.888.328.7661
Fax: 1.888.329.8328
Fax: +49 (0) 3328.4784.30
Fax: 86.21.5048.1881
Disclaimer
Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application.
No rights under any patent accompany the sale of any such product(s) or information.
Rev: 4-16-09 daf
