DIP Switches
DIP Switch Half Pitch SMT for Highest Reliability
DX62 Series
UNIT: mm
10 14.43 11.43
08 11.89
06 9.35
04 6.81
8.89
6.35
3.81
PO Dim.A Dim.B
How to order:
Material:
1
2
3
RoHS Compliant
Part Name
Material
P. P. S.
quantity
1
Treatment
Black Color
DX62
1
2
3
4
Cover
Base
P. P. S.
1
Black Color
1
NO. OF POSITIONS:
Slide
Polyamide
Cupper Alloy
1xPole
Yellow Color
04
06
08
10
4 Positions
6 Positions
8 Positions
10 Positions
Terminal
2xPole Gold over Nickel
(0.2μmAu average)
5
6
Moving
Contact
BeCu Alloy
Polyimide
1xPole Gold over Nickel
(0.2μmAu average)
2
T
TAPE SEALING:
Top Tape Sealed (Standard)
Tape
1
+/- 0.3 mm
no code Without Top Tape
GENERAL TOLERANCE:
3
TR
* The switch is 100% machine inspection.
* The plating process is electrolytic plating.
PACKAGE STYLE:
Tape and Reel
