DXT751
LOW VCE(SAT) PNP SURFACE MOUNT TRANSISTOR
Please click here to visit our online spice models database.
Features
•
•
•
•
•
•
Epitaxial Planar Die Construction
Complementary NPN Type Available (DXT651)
Ideally Suited for Automated Assembly Processes
Ideal for Medium Power Switching or Amplification Applications
Lead Free By Design/RoHS Compliant (Note 1)
"Green" Device (Note 2)
SOT89-3L
TOR
LLEC
CO
Mechanical Data
2,4
3 E
2 C
1 B
•
•
Case: SOT89-3L
Case Material: Molded Plastic, "Green” Molding Compound.
UL Flammability Classification Rating 94V-0
C 4
T
1
ASE
B
•
•
Moisture Sensitivity: Level 1 per J-STD-020C
Terminals: Finish — Matte Tin annealed over Copper leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
3
EMITTER
VIEW
OP
Schematic and Pin Configuration
•
•
•
Marking Information: See Page 4
Ordering Information: See Page 4
Weight: 0.072 grams (approximate)
Maximum Ratings @TA = 25°C unless otherwise specified
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Continuous Collector Current
Peak Pulse Collector Current
Symbol
VCBO
VCEO
VEBO
IC
Value
-80
-60
-5
-3
-6
Unit
V
V
V
A
A
ICM
Thermal Characteristics
Characteristic
Symbol
PD
Rθ
Value
1
Unit
W
Power Dissipation (Note 3) @ TA = 25°C
125
°C/W
Thermal Resistance, Junction to Ambient Air (Note 3) @TA = 25°C
Operating and Storage Temperature Range
JA
-55 to +150
°C
TJ, TSTG
Notes:
1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
3. Device mounted on FR-4 PCB; pad layout as shown on page 4 or in Diodes Inc. suggested pad layout document AP02001, which can
be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
DS31185 Rev. 3 - 2
1 of 4
www.diodes.com
DXT751
© Diodes Incorporated
