OTS-1VTR2DTR
Optiva® Standard, 1 Duplex Composite Video
and 2 Duplex RS-232/422/485 Data
Composite Video and Serial Data
The OTS-1VTR2DTR provides for the digital
transmission of 1 Channel of Duplex
Composite Video and 2 Channels of Duplex
Serial Data.
ST, LC,
SC or FC
ST, LC,
SC or FC
Composite
Video In
Composite
Video Out
Video
Audio
Data
Each insert card comes with a label
identifying the specific protocols
handled, connector pin-out and other
vital information.
System Design
Composite
Video Out
Composite
Video In
A
L
E
R
T
A
L
E
R
T
S
S
All units come in an insert card version.
The cards can be inserted into our 16-slot,
19” rack-mountable card cage (OT-CC-16-100)
or one of our smaller Optiva Desktop Card
Racks (OT-DTCR Series).
T
A
T
U
S
T
A
T
U
S
For optimal bandwidth allocation,
each insert card can daisy-chain with
an additional card in the same chassis.
See “Optiva™ Upgrade Path”.
Serial Data
In/Out
Serial Data
Out/In
®
The Optiva Desktop Card Racks can handle
™
™
Optiva
Optiva
one, two or four insert cards, creating
compact, mountable, stand alone systems.
The use of separate OT-DTCR enclosures
allows for future flexibility and expansion as
all cards are hot-swappable and can be used
in any enclosure. Each one of our card
housing units operate with an appropriate
power supply. See “Accessories” for power
supply specifications.
VAD Transmission
VAD Transmission
OTS-1VTR2DTR
OTS-1VRT2DRT
Features
• Composite Video and Serial Data over one fiber
• 12-Bit Digital Transmission (Video)
• TDM - Single fiber, dual wavelength
Optiva® Upgrade Path
• Complies with SMPTE standards for Video transmission
• Compatible with MDM-7000 Series for WDM and CWDM
multiplexing
This system can be purchased without
an optical port as an add-on to an existing
®
Optiva system daisy-chain.
• No EMI or RFI and no ground loops
(See “Non-Optical Version” below).
• Stand alone or rack-mount
®
The Optiva bandwidth requirement
• Ideal for Broadcast/Studio and Professional AV applications
of this system is 369 Mbps.
Versions Available*
Wavelength (nm)
& Fiber
Optical
Connector
Optical Budget Range***
Transmit/Receive**
Receive/Transmit**
(dB)
(km) Form Factor
1310/1550 Multimode
OTS-1VTR2DTR-A1/A3M-XX-IC OTS-1VTR2DRT-A3M/A1-XX-IC
ST, FC, LC or SC
ST, FC, LC or SC
ST, FC, LC or SC
ST, FC, LC or SC
ST, FC, LC or SC
10
12
3
20
IC (1-slot)
IC (1-slot)
IC (1-slot)
IC (1-slot)
IC (1-slot)
1310/1550 Singlemode OTS-1VTR2DTR-A2/A3-XX-IC
OTS-1VTR2DRT-A3/A2-XX-IC
OTS-1VTR2DRT-A3D/A2-XX-IC
OTS-1VTR2DRT-A3H/A2-XX-IC
OTS-1VTR2DRT-L4/L4-XX-IC
1310/1550 SM (D)
1310/1550 SM (H)
1270-1610 SM (CWDM)
OTS-1VTR2DTR-A2/A3D-XX-IC
OTS-1VTR2DTR-A2/A3H-XX-IC
OTS-1VTR2DTR-L4/L4-XX-IC
17
40
25
60
Varies
20-70
Non-Optical Version
OTS-1VTR2DTR-NOC-IC
OTS-1VTR2DRT-NOC-IC
N/A
N/A
N/A
IC (1-slot)
Serial Data Codes - "D" indicates RS-232. For other Serial Data preferences, please use: "DJ" = RS-422; "DK" = RS-485 (2W); and "DW" = RS-485 (4W).
* Contact Opticomm for other versions available.
** XX indicates the type of optical connector. Each of ST, FC, LC or SC are available.
*** Chromatic dispersion and additional losses should be taken into account.
800-867-8426 • info@opticomm.com • www.opticomm.com • Contact Opticomm for custom requirements.
Opticomm reserves the right to change specifications without notice
