IWR 0520F; IWR0520FM; IWR0520U; IWR 0260U;
IWR0520UM
HIGH VOLTAGE FAST RECTIFIER DIODES & DIODES
ARRAYS
TO-22320
1
MAXIMUM RATINGS
Rating
Symbol
URR
IF
IWR 0520F
IWR 0520FM
200
IWR 0520U IWR 0260 U IWR 0520UM
Unit.
V
Peak Repetitive Reverse
Voltage
Peak Rectified Forward
Current tJ=175°C
Nonrepetitive Peak Surge
Current
200
5
600
2
200
5
5
A
IFS
35
35
14
35
A
, t ≤ 8 ms
Operating Junction
Temperature
TJ
+175
-65 … +175
°C
°C
Storage Temperature
TSTG
ELECTRICAL CHARACTERISTICS for ТAMB=25°C
Rating
Symbol
UR.
IWR 0520F
IWR 0520U
1,2
IWR 0260 U IWR 0520UM
Unit.
(Mode of measure
Maximum Instantaneous
Forward Voltage *
IWR 0520FM
1,1
1,7
60
1,2
V
(IFMAX
)
Maximum Instantaneous
Reverse Current *
IF.
µA
50
(URRMAX
)
Maximum Reverse
Recovery Time
tREC
250
25
25
Ns
(IF=1 А, di/dt=50 A/µs,
URR=30 V, IREC=10% IR)
Maximum Thermal
Resistance, Junction to
Case
4,5
RθJC
°C/W
* tp ≤ 300 µs, Q ≥ 50
IWR 0520F; IWR0520U; IWR 0260U – diodes (pinning: pin 2 – cathode , pin 3 - anode)
IWR0520FM; IWR0520UM – diode array with common cathode (pinning: pin 1- anode 1, pin 2- common
cathode, pin 3 - anode 2)
