IXER 60N120
NPT3 IGBT
IC25
VCES
= 95 A
= 1200 V
in ISOPLUS 247TM
VCE(sat)typ. = 2.1 V
ISOPLUS 247TM
E153432
C
G
G
C
E
Isolated Backside
C = Collector E = Emitter
E
G = Gate
Features
IGBT
• NPT3 IGBT
- low saturation voltage
- positive temperature coefficient for
easy paralleling
- fast switching
Symbol
VCES
Conditions
Maximum Ratings
TVJ = 25°C to 150°C
1200
20
V
V
VGES
IC25
IC90
TC = 25°C
TC = 90°C
95
60
A
A
- short tail current for optimized
performance in resonant circuits
ICM
VCEK
VGE = 15 V; RG = 22 Ω; TVJ = 125°C
100
VCES
A
µs
W
• ISOPLUS 247TM package
- isolated back surface
- low coupling capacity between pins
and heatsink
- high reliability
- industry standard outline
RBSOA, Clamped inductive load; L = 100 µH
tSC
(SCSOA)
VCE = 900 V; VGE = 15 V; RG = 22 Ω; TVJ = 125°C
non-repetitive
10
Ptot
TC = 25°C
375
Applications
Symbol
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
• single switches
and with complementary free wheeling
diodes
• choppers
• phaselegs, H bridges, three phase
bridges e.g. for
- power supplies, UPS
- AC, DC and SR drives
- induction heating
min.
typ. max.
VCE(sat)
IC = 60 A; VGE = 15 V; TVJ = 25°C
TVJ = 125°C
2.1
2.5
2.7
V
V
VGE(th)
ICES
IC = 2 mA; VGE = VCE
4.5
6.5
V
VCE = VCES;VGE = 0 V; TVJ = 25°C
TVJ = 125°C
0.1 mA
mA
0.1
IGES
VCE = 0 V; VGE
=
20 V
200 nA
td(on)
tr
td(off)
tf
Eon
Eoff
80
50
680
30
7.2
4.8
ns
ns
ns
ns
mJ
mJ
Inductive load, TVJ = 125°C
VCE = 600 V; IC = 60 A
VGE = 15 V; RG = 22 Ω
Cies
QGon
VCE = 25 V; VGE = 0 V; f = 1 MHz
VCE = 600 V; VGE = 15 V; IC = 50 A
3.8
350
nF
nC
RthJC
RthJH
0.33 K/W
K/W
0.66
© 2006 IXYS All rights reserved
1 - 4
