IXFC 12N80P
ISOPLUS220TM (IXFC) Outline
Symbol
gfs
Test Conditions
Characteristic Values
(TJ = 25° C unless otherwise specified)
Min.
Typ.
Max.
VDS= 20 V; ID = IT, pulse test
12
18
S
Ciss
Coss
Crss
2800
210
19
pF
pF
pF
VGS = 0 V, VDS = 25 V, f = 1 MHz
td(on)
tr
td(off)
tf
21
22
62
22
ns
ns
ns
ns
VGS = 10 V, VDS = 0.5 VDSS, ID = IT
RG = 10 Ω (External)
Note:
Bottom heatsink (Pin 4) is
electrically isolated from Pin
1,2, or 3.
Qg(on)
Qgs
51
13
19
nC
nC
nC
VGS= 10 V, VDS = 0.5 VDSS, ID = IT
Qgd
RthJC
RthCS
1.05 °C/W
° C/W
0.21
Source-Drain Diode
Characteristic Values
(TJ = 25° C unless otherwise specified)
Symbol
IS
Test Conditions
Min.
Typ.
Max.
Ref: IXYS CO 0177 R0
VGS = 0 V
Repetitive
12
A
A
V
ISM
36
VSD
IF = IS, VGS = 0 V,
1.5
Pulse test, t ≤300 µs, duty cycle d≤ 2 %
trr
IRM
IF = 12 A, -di/dt = 100 A/µs
VR = 100 V, VGS = 0 V
250
ns
A
7
QRM
0.7
µC
Note 1: Test Current IT = 6 A
