IXFL 39N90
Symbol
gfs
TestConditions
Characteristic Values
ISOPLUS264OUTLINE
(TJ = 25°C, unless otherwise specified)
min.
typ. max.
VDS = 15 V; ID = IT, Note 2
30
45
S
Ciss
Coss
Crss
13400
1230
320
pF
pF
pF
VGS = 0 V, VDS = 25 V, f = 1 MHz
td(on)
tr
td(off)
tf
45
68
125
30
ns
ns
ns
ns
VGS = 10 V, VDS = 0.5 • VDSS, ID = IT
RG = 1 Ω (External),
Qg(on)
Qgs
Qgd
375
75
190
nC
nC
nC
VGS = 10 V, VDS = 0.5 • VDSS, ID = IT
RthJC
RthCK
0.22 K/W
K/W
0.07
Source-DrainDiode
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
Symbol
IS
TestConditions
VGS = 0 V
39
154
1.3
A
A
V
ISM
Repetitive;
Note 1
Please see IXFN39N90 data sheet
forcharacteristiccurves.
VSD
IF = IS, VGS = 0 V,
Note 2
trr
IF = 25A, -di/dt = 100 A/µs, VR = 100 V
250 ns
QRM
IRM
2
9
µC
A
Notes: 1. Pulse width limited by TJM.
2. Pulse test, t ≤ 300 ms, duty cycle d ≤ 2%.
3. IT Test current: IT = 19.5 A
IXYS reserves the right to change limits, test conditions, and dimensions.
IXYSMOSFETs andIGBTsarecovered byoneormore
ofthefollowingU.S.patents:
4,835,592 4,881,106 5,017,508 5,049,961 5,187,117 5,486,715 6,306,728B1 6,259,123B1 6,306,728B1
4,850,072 4,931,844 5,034,796 5,063,307 5,237,481 5,381,025 6,404,065B1 6,162,665 6,534,343
