IXFP4N100PM
Symbol
Test Conditions
Characteristic Values
ISOLATED TO-220 (IXFP...M)
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 2A, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
Gate Input Resistance
1.8
3.0
S
Ciss
Coss
Crss
1456
90
pF
pF
pF
16
RGi
1.6
Ω
1
2
3
td(on)
tr
td(off)
tf
24
36
37
50
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 2A
RG = 5Ω (External)
Qg(on)
Qgs
26
9
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 2A
Qgd
12
Terminals: 1 - Gate
2 - Drain
RthJC
2.2 °C/W
3 - Source
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
4
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS , VGS = 0V, Note 1
16
1.3
300
trr
ns
μC
A
IF = 2A, -di/dt = 100A/μs
QRM
IRM
0.34
5.30
VR = 100V, VGS = 0V
Note 1. Pulse test, t ≤ 300μs, duty cycle, d ≤ 2 %.
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from a subjective evaluation of the design, based upon prior knowledge and experience, and constitute a
"considered reflection" of the anticipated result. IXYS reserves the right to change limits, test
conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
