IXFP4N100QM
Symbol
Test Conditions
Characteristic Values
OVERMOLDED TO-220 (IXFP...M)
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 2A, Note 1
2.5
4.3
S
Ciss
Coss
Crss
1185
130
65
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
17
15
32
18
ns
ns
ns
ns
1
2
3
Resistive Switching Times
VGS = 10V, VDS = 0.5 VDSS, ID = 2A,
ꢀ
RG = 4.7Ω (External)
Qg(on)
Qgs
43.5
6.2
nC
nC
nC
VGS= 10V, VDS = 0.5
ꢀ
VDSS, ID = 2A
Qgd
23.0
RthJC
2.7 °C/W
Terminals: 1 - Gate
2 - Drain (Collector)
3 - Source (Emitter)
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
4
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
16
1.5
trr
QRM
IRM
250 ns
IF = 4A, -di/dt = 100A/μs,
VR = 100V, VGS = 0V
480
6.16
nC
A
Note 1. Pulse test, t ≤ 300μs; duty cycle, d ≤ 2 %.
