PolarTM Power MOSFET
HiPerFETTM
VDSS = 1200V
ID25 = 15A
RDS(on) ≤ 500mΩ
≤ 300ns
IXFR26N120P
N-Channel Enhancement Mode
Avalanche Rated
Fast Intrinsic Diode
trr
ISOPLUS247 (IXFR)
E153432
Symbol
VDSS
Test Conditions
Maximum Ratings
TJ = 25°C to 150°C
1200
1200
V
V
VDGR
TJ = 25°C to 150°C, RGS = 1MΩ
VGSS
VGSM
Continuous
Transient
± 30
± 40
V
V
Isolated Tab
ID25
IDM
TC = 25°C
15
60
A
A
TC = 25°C, pulse width limited by TJM
G = Gate
D
= Drain
S = Source
IA
TC = 25°C
TC = 25°C
13
A
J
EAS
1.5
Features
dV/dt
PD
IS ≤ IDM, VDD ≤ VDSS, TJ ≤ 150°C
TC = 25°C
15
V/ns
W
• Silicon chip on Direct-Copper-Bond
substrate
320
- High power dissipation
- Isolated mounting surface
- 2500V electrical isolation
TJ
-55 ... +150
150
°C
°C
°C
TJM
Tstg
• Low drain to tab capacitance(<30pF)
-55 ... +150
• Low R
HDMOSTM process
• RuggeDdS p(ono)lysilicon gate cell structure
TL
Maximum lead temperature for soldering
Plastic body for 10s
300
260
°C
°C
V~
• Unclamped Inductive Switching (UIS)
TSOLD
VISOL
FC
• Fraatsetdintrinsic Rectifier
50/60 Hz, RMS, 1 minute
Mounting force
2500
Advantages
20..120/4.5..27
5
N/lb.
• Easy assembly
• Space savings
• High power density
Weight
g
Applications:
z High Voltage Switched-mode and
resonant-mode power supplies
z High Voltage Pulse Power Applications
z High Voltage Discharge circuits in
Lasers Pulsers, Spark Igniters, RF
Generators
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Min.
Typ. Max.
BVDSS
VGS(th)
IGSS
VGS = 0V, ID = 3mA
VDS = VGS, ID = 1mA
VGS = ± 30V, VDS = 0V
1200
3.5
V
V
6.5
± 200 nA
z High Voltage DC-DC converters
z High Voltage DC-AC inverters
IDSS
VDS = VDSS
VGS = 0V
50 μA
5 mA
TJ = 125°C
RDS(on)
VGS = 10V, ID = 13A, Note 1
500 mΩ
