IXFR64N50P
Symbol
Test Conditions
Characteristic Values
ISOPLUS247 (IXFR) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 32A, Note 1
30
50
S
Ciss
Coss
Crss
9700
970
30
nF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
30
25
85
22
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 32A
RG = 2Ω (External)
Qg(on)
Qgs
150
50
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 32A
Qgd
50
RthJC
RthCS
0.42 °C/W
°C/W
0.15
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
64
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = 64A, VGS = 0V, Note 1
250
1.5
trr
QRM
IRM
200 ns
IF = 25A, -di/dt = 100A/μs
0.6
6.0
μC
A
VR = 100V, VGS = 0V
Note 1: Pulse Test, t ≤ 300μs; Duty Cycle, d ≤ 2%.
