Mixer
The content of this specification may change without notification 7/01/09
Mixer
P/N: JXWBHP-MM93PG-40
RF/LO(GHz)
0.5-18
IF(MHz)
DC-150
LO Power(dBm)
Conversion Loss(dB)
+7
8.0 Typ.,11.0 max
12 min, 20 Typ.(0.5-1.0GHz)
20 min, 30 Typ.(1.0-18.0GHz)
5 min, 12 Typ.(0.5-1.0GHz)
20 min, 31 Typ.(1.0-18.0GHz)
30 Typ.(0.5-18.0GHz)
+2
LO-RF Isolation(dB)
LO-IF Isolation(dB)
RF-IF Isolation(dB)
Input 1dB Compression Point(dBm)
IP3(dBm)
+11
Connector
SMA-Female
Operating Temperature(ºC)
Storage Temperature(ºC)
Gross Weight(Kg)
-40 ~ +80
-55 ~ +85
0.079 Around
For current data sheets, please contact: sales@aacix.com
188 Technology Drive, Unit H, Irvine, CA 92618
1
Tel: 949-453-9888 Fax: 949-453-8889 Email: sales@aacix.com
