Power Divider
The content of this specification may change without notification 7/01/09
2-Way Power Divider
P/N: JXWBGF-T-2-2300-5300
Frequency Range(GHz)
Insertion Loss(dB)
Isolation(dB)
2.3-5.3
0.8 max
20 min
Phase Unbalance(º)
Amplitude Unbalance(dB)
VSWR
Connector
Operating Temperature(°C)
Storage Temperature(°C)
6 max
0.4 max
1.3:1 max
N-Female
-40 ~ +80
-55 ~ +85
Outline Drawing (Size: mm)
For current data sheets, please contact: sales@aacix.com
188 Technology Drive, Unit H, Irvine, CA 92618
1
Tel: 949-453-9888 Fax: 949-453-8889 Email: sales@aacix.com
