INDICATORS
4mm LED Indicators
CHROME PLATED BRASS BEZEL
ᔢ Chrome Plated Brass Bezel
ᔢ Prominent or Recessed Style
ᔢ Choice of LED Types and
Colours
DX1116
DX1118
BLACK NICKEL PLATED BRASS BEZEL
ᔢ Aluminium, Black Anodised
Bezel
ᔢ Prominent or Recessed Style
ᔢ Choice of LED Types and
Colours
DX1117
DX1119
Specification
DX1116, DX1118/Colour
DX1117, DX1119/Colour
Bezel Materials:
Style:
Brass, Chrome Plated
Aluminium, Black Anodised
Recessed (DX1116)
Prominent (DX1118)
Recessed (DX1117)
Prominent (DX1119)
Operating Temp. Range:
Storage Temperature:
Lead Solder Time:
LED Colours:
Dependent on LED used
Dependent on LED used
260ºC for 5 seconds max.
Dependent on LED used
Dependent on LED used
260ºC for 5 seconds max.
/RD (Red), /GN (Green), /YL (Yellow),
/BL (Blue)
/RD (Red), /GN (Green), /YL (Yellow),
/BL (Blue)
RoHS
Compliant
Compliant
See Page 172 for LED specifications
