XTR101BG

型号：

XTR101BG

描述：

高精度，低漂移的4-20mA两线制变送器[ Precision, Low Drift 4-20mA TWO-WIRE TRANSMITTER ]

品牌：

TI[ TEXAS INSTRUMENTS ]

页数：

25 页

PDF大小：

736 K

下载PDF手册
XTR101
SBOS146A − OCTOBER 1986 − REVISED AUGUST 2004
Precision, Low Drift
4-20mA TWO-WIRE TRANSMITTER
FD EATURES
DESCRIPTION
INSTRUMENTATION AMPLIFIER INPUT:
− Low Offset Voltage, 30µV max
− Low Voltage Drift, 0.75µV/°C max
− Low Nonlinearity, 0.01% max
The XTR101 is
a microcircuit, 4-20mA, two-wire
transmitter containing a high accuracy instrumentation
amplifier (IA), a voltage-controlled output current source,
and dual-matched precision current reference. This
combination is ideally suited for remote signal conditioning
of a wide variety of transducers such as thermocouples,
RTDs, thermistors, and strain gauge bridges. State-of-the-
art design and laser-trimming, wide temperature range
operation, and small size make it very suitable for
industrial process control applications. In addition, the
optional external transistor allows even higher precision.
D
TRUE TWO-WIRE OPERATION:
− Power and Signal on One Wire Pair
− Current Mode Signal Transmission
− High Noise Immunity
D
D
D
D
DUAL MATCHED CURRENT SOURCES
WIDE SUPPLY RANGE: 11.6V to 40V
SPECIFICATION RANGE: −40°C to +85°C
The two-wire transmitter allows signal and power to be
supplied on a single wire pair by modulating the
power-supply current with the input signal source. The
transmitter is immune to voltage drops from long runs and
noise from motors, relays, actuators, switches,
transformers, and industrial equipment. It can be used by
OEMs producing transmitter modules or by data
acquisition system manufacturers.
SMALL DIP-14 PACKAGE, CERAMIC AND
PLASTIC
AD PPLICATIONS
INDUSTRIAL PROCESS CONTROL:
− Pressure Transmitters
IREF1
Optional
IREF2
− Temperature Transmitters
− Millivolt Transmitters
External
10
Transistor
+VCC
8
3
11
e1
−
D
D
D
D
D
D
D
RESISTANCE BRIDGE INPUTS
THERMOCOUPLE INPUTS
5
6
RTD INPUTS
12(1)
XTR101
Span
B
CURRENT SHUNT (mV) INPUTS
PRECISION DUAL CURRENT SOURCES
AUTOMATED MANUFACTURING
4
e2
+
9
POWER/PLANT ENERGY SYSTEM
MONITORING
13(1)
E
14
7
2
IOUT
1
Optional
Offset Null
NOTE: (1) Pins 12 and 13 are used for optional BW control.
