IXSH 45N120B
IXST 45N120B
"S" Series - Improved SCSOA Capability
HighVoltageIGBT
IC25
= 75 A
= 1200 V
VCES
VCE(sat) = 3.0 V
Preliminary data
Symbol
TestConditions
MaximumRatings
TO-247 AD (IXSH)
VCES
VCGR
TJ = 25°C to 150°C
1200
1200
V
V
TJ = 25°C to 150°C; RGE = 1 MW
(TAB)
(TAB)
VGES
VGEM
Continuous
Transient
±20
±30
V
V
G
C
E
IC25
IC90
ICM
TC = 25°C (limited by leads)
TC = 90°C
75
45
A
A
A
TO-268 ( IXST)
TC = 25°C, 1 ms
180
G
E
SSOA
(RBSOA)
VGE= 15 V, TJ = 125°C, RG = 5 W
Clampedinductiveload
ICM = 90
@ 0.8 VCES
A
ms
W
tSC
TJ = 125°C, VGE = 720 V; VGE = 15 V, RG = 5 W
TC = 25°C
10
G = Gate
C = Collector
TAB = Collector
S = Emitter
PC
300
TJ
-55 ... +150
150
°C
°C
°C
TJM
Tstg
-55 ... +150
Features
Md
Mountingtorque
(TO-247)
TO-247
1.13/10 Nm/lb.in.
Maximumleadtemperatureforsoldering
1.6 mm (0.062 in.) from case for 10 s
300
°C
• EpitaxialSilicondriftregion
- fastswitching
- small tail current
Weight
6
g
• MOS gate turn-on for drive simplicity
Applications
• AC motor speed control
• DC servo and robot drives
• Uninterruptiblepowersupplies(UPS)
• Switched-modeandresonant-mode
powersupplies
Symbol
TestConditions
CharacteristicValues
(TJ = 25°C, unless otherwise specified)
min. typ. max.
BVCES
VGE(th)
IC = 1.0 mA, VGE = 0 V
1200
3
V
V
• Welding
IC = 250 mA, VCE = VGE
6
ICES
VCE = 0.8 • VCES
Note 1
50 mA
2.5 mA
TJ = 125°C
TJ = 125°C
IGES
VCE = 0 V, VGE = ±20 V
±100 nA
VCE(sat)
IC = IC90, VGE = 15 V
Note 2
2.5
2.6
3.0
V
V
IXYS reserves the right to change limits, test conditions, and dimensions.
© 2000 IXYS All rights reserved
98713A(7/00)
1 - 2
