IXFC52N30P
ISOPLUS220TM (IXFC) Outline
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Min.
Typ.
Max.
gfs
VDS = 10V, ID = 26A, Note 1
20
30
S
Ciss
Coss
Crss
3490
550
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
130
td(on)
tr
td(off)
tf
24
22
60
20
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 52A
RG = 4Ω (External)
Note:
Qg(on)
Qgs
110
25
nC
nC
nC
Bottom heatsink (Pin 4) is
electrically isolated from Pin
1,2, or 3.
VGS = 10V, VDS = 0.5 • VDSS, ID = 26A
Qgd
53
RthJC
RthCS
1.25 °C/W
°C/W
0.21
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Min.
Typ.
Max.
IS
VGS = 0V
52
A
A
V
ISM
VSD
Repetitive, pulse width limited by TJM
IF = 52A, VGS = 0V, Note 1
150
1.5
Ref: IXYS CO 0177 R0
trr
QRM
IRM
200 ns
IF = 25A, -di/dt = 100A/μs
800
7
nC
A
VR = 100V, VGS = 0V
Note 1: Pulse test, t ≤ 300μs; duty cycle, d ≤ 2%.
