OX-4011-EAE-2580-20M00
OCXO
Preliminary version: Subject to technical modification.
Nominal frequency (f0)
20 MHz
Frequency stabilities
Parameter
vs. operating temp. range (df/f@25 °C)
Parameter
Frequency stability
-25 to 25 ppb
Value
Operating temp. range
-40 ... 85 °C
Condition
initial tolerance (df/f0)
vs. supply voltage change (df/f)
vs. load change (df/f)
vs. aging / daily (df/f)
vs. aging / month (df/f)
vs. aging / year (df/f)
-200 to 200 ppb
-10 to 10 ppb
-10 to 10 ppb
<± 1 ppb
<± 25 ppb
<± 100 ppb
<± 1 ppm
@25 °C
static; 3.3 V ±5 %
static; Load ± 5 %
after 30 days ; @ 25 °C
after 30 days ; @ 25 °C
after 30 days ; @ 25 °C
after 30 days ; @ 25 °C
vs. aging / 10 years (df/f)
Drift 24h over -40..85°C: <50 ppb peak-peak
RF output
Parameter
Signal
Value
LVCMOS
15 pF ±10 %
< 10 ns
Condition
Load
Rise Time
Fall Time
Duty cycle
V Low
V High
Harmonics
@ 10 to 90 %Vout
@ 90 to 10 %Vout
@ 1.65 V
< 10 ns
45 / 55 %
x < 0.4 V
x > 2.4 V
<- 30 dBc
Supply voltage
Parameter
Value
Condition
Supply voltage (Vs)
Current consumption steady state
Current consumption during warm up
3.3 V ± 5 %
< 330 mA
< 757 mA
@ Vsnom & 25 °C
@ Vs
Additional Parameters
Parameter
Phase Noise
Typ.
-85
Max.
-60
Condition
dBc/Hz@1Hz
-110
-130
-143
-150
-90
dBc/Hz@10Hz
dBc/Hz@100Hz
dBc/Hz@1kHz
dBc/Hz@10kHz
Condition
-115
-130
-145
Parameter
Value
Warm-up time
Processing & Packing
< 3 min
handling&processing note
@ 25 °C to final frequency
Additional environmental conditions
Rapid temperature changes
MIL-883-1010 Cond B 1000 cycles -55/125°C
Vibration
MIL-STD-883 Meth 2007 Cond A 20G 20-2000Hz 4x in each 3axis 4 min
Fine/Gross Leakage MIL-883-1014 A1/C4
Shock
MIL-STD-202 Meth 213 Cond.C 100G 6ms 6 shocks in each direction
Solderability
J_STD_002B Cond A leaded/ Cond. B SMD 245°C (diving Ti me 5 ±0,5sec.)
DipLook with 8h damp pre-treatment: solder wetting >95%
Solvent resistance
MIL-STD-883 Meth 2015 Solv. 1,3,4
ESD
HBM JESD22-A114-A Class 2 10* 2000V
Moisture Sensit.
Level 1 JESD22-A113-B
RoHS compliance
100% ROHS compliant
• Product Specifications OX-4011-EAE-2580
Vectron International
20-May-26 by Göhrig, Detlef Index : P2
printed 2011-05-26 • page 1 of 4
