Metallized Polypropylene Film Capacitors
Type: MKP for DC-link EZPE 1100VDC Series
Non-inductive construction using metalized polypropylene film
with flame retardant epoxy resin and case.
Features
High safety, Self-healing and Self-protecting function built-in
Long product life, High reliability
Low loss, Low ESR
Flame retardant (Case and sealing resin)
RoHS directive compliant
Recommended Applications
For DC filtering, DC link circuit
Solar inverters
Wind power generation
Industrial power supplies
Resonance circuit for power supply
Inverter circuit in appliances (Air Conditioners etc.)
Construction
Dielectric
Electrodes
Plastic case
Sealing
: Polypropylene film
: Metallized dielectric with segmented pattern
: UL94 V-0
: UL94 V-0
Terminals
: Tinned wires, 4-pin versions
Explanation of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
Rated voltage
Capacitance
Pin type
M
Suffix
Suffix
Product code
Dielectric &
construction
1B
1100 VDC
4-pin type
Specifications
Category temperature range ( TC ) ( *1 )
40
to + 85
1100 VDC
Rated voltage (VR) ( *2 )
( 920 VDC at 85
; Derating of rated voltage at more than 70
(*3)
)
Rated capacitance ( CR )
Capacitance tolerance
10 ꢀF to 40 ꢀF
± 10 %
Between terminals : Rated voltage (VDC) × 150 % 10 s
Terminal to case : 2110 VAC ( 50 Hz or 60 Hz ) 10 s
Withstanding DC voltage
Insulation resistance ( CR )
CR
10,000 ꢁ F ( 20 , 500 VDC, 60 s )
*1 : The temperature of capacitor surface (case)
*2 : Use for DC voltage only
*3 : Refer to the page of “ DC voltage derating ”
D
esign, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
