Part Number:
Status:
15020-0928
Active
Overview:
Description:
Premo-Flex™ FFC and Etched Polyimide Jumpers
0.50mm Pitch Premo-Flex™ FFC Jumper, Opposite Side Contacts (Type D), 23
Circuits, 0.127m Cable Length, 0.27mm Cable Thickness, Gold (Au) Plating
Documents:
Drawing (PDF)
Packaging Specification PK-15020-001 (PDF)
Product Specification PS-15020-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
China RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Low-Halogen Status
Not Reviewed
General
Product Family
Series
Comments
Crimp Quality Equipment
Overview
Cable
15020
EU RoHS
Contacts on opposite sides, Type D
Yes
Premo-Flex™ FFC and Etched Polyimide Jumpers
Premo-Flex™FFC Jumper
884982182035
Product Name
UPC
Physical
Need more information on product
environmental compliance?
Cable Length
0.127m
23
Circuits (Loaded)
Circuits (maximum)
Packaging Type
Pitch - Termination Interface
Temperature Range - Operating
Wire Size AWG
23
Bag
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
0.50mm
-40°C to +105°C
N/A
Please visit the Contact Us section for any
non-product compliance questions.
Wire/Cable Type
Flat Flex Cable
Electrical
Current - Maximum per Contact
Voltage - Maximum
0.5A
60V AC
Search Parts in this Series
15020Series
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
PK-15020-001
PS-15020-001
SD-15020-001
Sales Drawing
