WT-1005660-12K2-A6-G

型号：

WT-1005660-12K2-A6-G

描述：

线径：我?? 0.08毫米×105 （类型2线）线圈匝数： 12TS / 1层[ Wire Diameter: φ0.08mm x 105 ( Type2 Wire) Coil Turns: 12TS / 1 layer ]

品牌：

TDK[ TDK ELECTRONICS ]

页数：

8 页

PDF大小：

583 K

下载PDF手册
PRODUCT SPECIFICATION
SPEC. No:
Attn:
DATE: July.05.2012
CUSTOMER PRODUCT NAME:
TDK PRODUCT NAME:
WT-1005660-12K2-A6-G
THIS SPECIFICATION IS:
TDK-EPC Corporation
Head Office Address:
1-13-1, Nihonbashi, Chuo-ku, Tokyo
103-0027 , Japan
ENGINEERING
APPROVED CHECKED
SALES
ISSUED
MANAGER
SALES
PRELIMINARY
Sales Office
Sales Tel.
PRODUCT
CLASSIFICATION CODE
REVISED HISTORY
CUSTOMER PRODUCT NAME:
TDK PRODUCT NAME:
WT-1005660-12K2-A6-G
REVISED CONTENT
REVISED REASON
NO. REV.
DATE
To establish specification
1
0
2012.07.05
PRELIMINARY
1/6
PRODUCT SPECIFICATION
TDK PRODUCT NAME:
SPEC. NO.
CUSTOMER PRODUCT NAME:
Weight: 46.7 g (Typ.)
WT-1005660-12K2-A6-G
(1) Apperance & Dimensions (Unit: mm)
TOP VIEW
Lead wire pitch
position
SIDE VIEW
BOTTOM VIEW
PRELIMINARY
[ Remarks]
1. Lead wire pitch is end of wire position, not ouput terminal.
2. Marking Content:
a. T: Manufacturing Centers
b: Lot No.: □□ ○○ △△
(1)
(2) (3)
(1) Year: A.D. end number in double
(2) Month: Jan.(1), Feb.(02)…Dec.(12)
(3) Day: 01,02,03,…31.
2/6
PRODUCT SPECIFICATION
TDK PRODUCT NAME:
SPEC. NO.
CUSTOMER PRODUCT NAME:
WT-1005660-12K2-A6-G
(2) Air coil specification
Wire Diameter: φ0.08mm x 105 ( Type2 Wire)
Coil Turns: 12TS / 1 layer
(3) Electrical Characteristics
No.
Parameter
Specification
Test Instrument
12.5 μH ±10%
Coil 0
Coil 1
Coil 2
Coil 0
Coil 1
Coil 2
Coil 0
Coil 1
Coil 2
HP 4284A DIGITAL LCR METER
or EQUIVALENT
(＠100kHz 1.0 Vrms)
11.5 μH ±10%
12.5 μH ±10%
1
Inductance
HP 4284A DIGITAL LCR METER
or EQUIVALENT
(＠100kHz 1.0 Vrms)
2
Q Value
70 (Min.)
0.08 Ω (Max.)
(At 25℃)
DC
Resistance
CHEN HWA 502A OHM METER
or EQUIVALENT
3
* Remark:
(4) Temperature Characteristics
No.
1
Parameter
Specification
Operating Temperature
-30～70℃
PRELIMINARY
2
Storage Temperature
-40～85℃
(5) Application
1. The product fit in with RoHS rule.
2. The product fit in with Halogen-Free.
3. Reflow and dip-flow soldering can not used for this product.
3/6
PRODUCT SPECIFICATION
TDK PRODUCT NAME:
SPEC. NO.
CUSTOMER PRODUCT NAME:
WT-1005660-12K2-A6-G
(6) Reliability Conditions
No. Parameter
Conditions
Low Temperature
(Storage)
(1) Temperature：-40±2℃
(2) Time：240Hrs
1
2
High Temperature
(Storage)
(1) Temperature：+85±2℃
(2) Time：240Hrs
(1) Temperature : - 40±5℃/ 30min ~ + 85±5℃/ 30min
(2) Ambient Time : 5min
(3) Times : 100cycles
3
4
Thermal Shock
Unpacked:
(1)frequency:10~500Hz sweep
1 octave wave / 1 min
(2)Amplitude:1.5mm (p-p) or 10G
(3)Direction:X.Y.Z. direction
(4)Time:X.Y.Z for 2 hours each.
Vibration
(1) Temperature : +60±2℃
(2) Humidity: 90% RH.
(3) Time: 240Hrs
5
6
7
Temperature / Humidity (Storage)
Temperature / Humidity (OP)
Package Drop
(1) Temperature : +60±2℃
(2) Humidity: 90% RH.
(3) Time: 240Hrs
(4) Current: DC 1.0A
(5) Frequency: 100kHz
(1) Drop the sample package in a carton box.
(2) Height : 100 cm
(3) Direction :1corner,3 edges, 6 faces
(4) Drop time : 16 times
(1) Test Voltage: 1000V
(2) Ambient: 25±5℃
8
9
ESD(HBM)
(3) Time: Negative / Positive each 1 time
(4) Resistance: 1500Ω
(5) Capcitance: 100pF
PRELIMINARY
(1) Test Voltage: 100V
(2) Ambient: 25±5℃
ESD(MM)
(3) Time: Negative / Positive each 1 time
(4) Capcitance: 200pF
4/6
PRODUCT SPECIFICATION
TDK PRODUCT NAME:
WT-1005660-12K2-A6-G
(7) Construction
SPEC. NO.
CUSTOMER PRODUCT NAME:
( 4 )
( 3 )
( 2 )
( 1 )
( 1 )
( 5 )
x 10 dots
( 6 )
(8) Material List
No. Material Name
1
2
3
4
5
6
PET Tape
PRELIMINARY
Ferrite Sheet
Adhesive Tape
Air Coil
Glue
Ink
5/6
PRODUCT SPECIFICATION
TDK PRODUCT NAME:
SPEC. NO.
CUSTOMER PRODUCT NAME:
WT-1005660-12K2-A6-G
(9) Packing
1. To stack the the Trays onto 4 Layers:
- PET tray dimension: 326*329*11.0mm (REF.)
- 6 Pcs / per PET tray (REF.)
TOP Tray is empty
4-Layers
Total : 6x3=18pcs
Total : 2x3=6pcs
2. To put 2 Trays of products into the small Carton and affixing the out-going label on the outside .
- Small carton dimension: 331*337*33mm (REF.)
- 4 PET Trays / per small carton ( PET tray of the top side is empty in the small carton)
Out-going Label
PRELIMINARY
CUST PROD ID(P)： １２３４５６７８９.
Customer
ROHS
QTY(Q)：
(6P):ＴＴＸＤＦ１２３４５TWN273711000
72
TDK ITEM(1P)：
WT-1005660-12K2-A6-G
VDR(V):TDK
1411
LOT NO(1T)： WL１２Ｋ３４５６７＋M0001 DATE CODE(T):
0001
001/009
12325A0435
(S)
2011/11/22
MADE IN TAIWAN
(ITEM:
WT-1005660-12K2-A6-G)
M)TTXDF１２３４５
TDK TAIWAN CORPORATION
Out-going Label
6/6
PRODUCT SPECIFICATION
TDK PRODUCT NAME:
SPEC. NO.
CUSTOMER PRODUCT NAME:
WT-1005660-12K2-A6-G
3. To put 3 small corton into the Carton .
- Outer carton dimension: 347*340*124mm (REF.)
- 3 small cartons / per outer carton
- Total quantity : 54 Pcs (REF.)
3 small cartons
Outer carton
4. Packing.
-To pack the carton by scoth tape and affix out-going label (outside) on it outside.
-The Inspection data in the box , there would be a signet mark on it outside.
scoth tape
INSPECTION DATA
ENCLOSED
檢驗紀錄表在內
signet mark of Inspection data
(3S) TTW+WL11K0600200101400000360
Customer
ꢀCUSTOMER：
ꢀ
CUST. PART NO(P)：ꢀ１２Ａ３４５６７－８９Ａ
ＴＴＸＤＦ１２３４５TWN
TDK ITEM CODE(6P):
BOX COUNT
(6S) C/NO：1
001/009
ROHS
PRELIMINARY
ꢀꢀꢀꢀꢀ SHIPPING MARK
P/O NO.(K): TTTT－S123456789
LOT NO.(1T): WL12345678
DATE:
Nov.22.2011
288
QTY(Q):
Customer
Location
TDK ITEM (1P):
WT-1005660-12K2-A6-G
(WT-1005660-12K2-A6-G)
4500059424
MADE IN TAIWAN
WL１２Ｋ３４５６７
１２３４５A６７８９
SUB P/O NO.(6K):
TDK SPEC.
( CT )
GW 4.0
WAREHOUSE
3.6
ＴＴＸＤＦ１０１０５
TDK TAIWAN CORPORATION
C/NO：1
9
YANGMEI, TAIWAN
NW
out-going label
