Data Sheet
2.0 Amp
SINGLE PHASE SILICON BRIDGE
Mechanical Dimensions
Description
Mechanical Data: Mounting Position - Any.
Weight - 1.1 Grams.
Features
n COMPACT SIZE
n 200 AMP SURGE OVERLOAD RATING
n LOW LEAKAGE CURRENT
n MEETS UL SPECIFICATION 94V-0
2W005 . . . 10 Series
Units
Maximum Ratings
2W005 2W01
2W02
200
2W04 2W06 2W08
2W10
1000
700
50
35
50
100
70
400
280
400
600
420
600
800
560
800
Volts
Volts
Volts
Peak Repetitive Reverse Voltage...VRRM
RMS Reverse Voltage...VR(rms)
DC Blocking Voltage...VDC
140
100
200
1000
Average Forward Rectified Current...IF(av)
Amps
Amps
°C
............................................. 2.0 ...............................................
............................................. 60 ...............................................
........................................ -55 to 125 .........................................
TA = 25°C
Non-Repetitive Peak Forward Surge Current...IFSM
8.3 ms Single ½ Sine Wave Imposed on Rated Load
Operating & Storage Temperature Range...TJ, TSTRG
Electrical Characteristics
Maximum Forward Voltage...VF
Per Bridge Element @ 2.0 Amps
............................................. 1.0 ............................................... Volts
Maximum DC Reverse Current Per Bridge Element...IR
@ Rated DC Blocking Voltage
T = 25°C
............................................. 10 ............................................... µAmps
............................................. 1.0 ............................................... mAmps
TAA =100°C
Page 3-11
