PXIe Chassis
■ꢀInnovative Cooling Mechanism
The ADLINK PXES-2590 features an innovative heat dissipation solution. Two 185.9CFM cooling fans in the
rear section of the chassis draw cool air through lower apertures, which is then exhausted through the back.
This design generates uniform airflow for each PXI slot, delivering exceptional cooling.
When installed in a rack, the cooling design minimizes intake of hot air from the rear side, separating airflow
for modules and power supplies, while isolating noise source (fan) from modules and maintaining a steady
internal temperature.
■ꢀIntelligent Chassis Management
The PXES-2590 has a built-in system monitoring controller that monitors and manages full chassis status,
including internal temperature, fan speed, and DC voltages.
■ꢀAll Hybrid Peripheral Slots Design*
The ADLINK PXES-2590 features an all-hybrid peripheral slot design, with PXI Express, cPCI Express, PXI,
and CompactPCI modules compatible with every slot.
Note:
1. ADLINK’s PXI Express chassis accepts hybrid slot-compatible PXI-5 modules (with XJ4 connector).
Legacy PXI-1 boards (with J2 connector) need to be upgraded to hybrid slot-compatible PXI modules.
A detailed list of ADLINK PXI hybrid slot-compatible modules is available online at:
http://www.adlinktech.com/PXI/pxi-breakthrough-bandwidth.php#FAQ
2. Contact your ADLINK sales representative for assistance in upgrading ADLINK legacy PXI modules.
If the PXI modules were purchased from a third party, please contact the original vendor.
•BackplaneꢀLinkꢀConfiguration
Recommended System Controller
Specifications
PXES-2590
Physical
Power Supply
PXIe-3975
√
■
Number of slots:
■
AC Input
ꢀ ꢀ •1 system slot + 1 system timing hybrid slot
ꢀ ꢀ •ꢀInput voltage range: 100 to 240 VAC
Ordering Information
+ 7 peripheral slots
ꢀ ꢀ •ꢀInput voltage frequency: 50 to 60 Hz
■
Dimensions:
■
ꢀ
DC Output
■ PXES-2590
3U 9-slot PXI Express chassis with all-hybrid
peripheral slots and universal AC power supply
ꢀ ꢀ •ꢀ322 mm (W) x 190 mm (H) x 456 mm (D) (12.55” x 7.4” x 17.8”)
ꢀ ꢀ •ꢀMaximum total usable power is 400 W
Load
Regulation
Maximum Ripple
■
VDC
Maximum
Weight: 9 kg (19.8 lbs)
& Noise
■ꢀPXES-2590/PMK-1524ꢀwithꢀTrolleyꢀCase
3U 9-slot PXI Express chassis with all hybrid
slots with factory-mounted 15” 24-bit monitor/
keyboard kit, pre-installed in trolley case for
shipping.
+5 V
+12 V
+3.3 V
-12 V
23.0 A
27.0 A
33.0 A
1.75 A
±3%
±3%
±3%
±3%
50 mV
50 mV
50 mV
50 mV
Operating Environment
■
Ambientꢀtemperature:ꢀ0˚Cꢀtoꢀ55˚Cꢀ(32˚Fꢀtoꢀ131˚F)
■
Relative humidity: 10% to 90%, non-condensing
Storage Environment
■
Ambientꢀtemperature:ꢀ-20˚Cꢀtoꢀ70˚Cꢀ(-4˚Fꢀtoꢀ158˚F)
ꢀBusꢀInterface
■
Optional Accessories
Relative humidity: 10% to 90%, non-condensing
■
Four-link capacity PXI Express chassis
Up to 7 GB/s system bandwidth
■
ꢀShockꢀandꢀVibration
■ꢀPMK-1524
Portable LCD monitor/keyboard accessory kit
for PXES-2590
ꢀꢀꢀꢀꢀ■
Up to 2 GB/s peripheral bandwidth for all slots
■
Functional shock: 30 G, half-sine, 11 ms pulse duration
■
ꢀIO/SwitchꢀonꢀRearꢀPanel
Random vibration:
■ Trolley Case
■
BNC connectors for 10MHz clock input/output
ꢀ ꢀ •ꢀOperating:ꢀ5ꢀtoꢀ500ꢀHz,ꢀ0.3ꢀGrms,ꢀ3ꢀaxes
Trolley case for PXES-2590/PMK-1524,
570 x 270 x 390 mm, 5 kg
ꢀ
ꢀ
■
■
■
Fan speed selector switch
ꢀ ꢀ •ꢀNon-operating:ꢀ5ꢀtoꢀ500ꢀHz,ꢀ2.46ꢀGrms,ꢀ3ꢀaxes
Inhibit mode selector switch
Emissions Compliance
■ꢀPXES-2590ꢀRack-mountꢀKit
Flexible rack-mount kit for PXES-2590
D-SUB9 for voltage monitoring and remote inhibit
■
EN 61326-1
Cooling
■
FCC Class A
■
Fans: 2 x 185.9 CFM fans
CE Compliance
■
Per-slot cooling capacity: 30 W
■
Safety: EN 61010-1
■
Immunity: EN 61326-1
Updated January 29, 2013. ©2013 ADLINK Technology, Inc. All Rights Reserved. All specifications are subject to change without further notice.
