IXFN62N80Q3

型号:

IXFN62N80Q3

描述:

HiperFETTM功率MOSFET Q3级[ HiperFETTM Power MOSFET Q3-Class ]

品牌:

IXYS[ IXYS CORPORATION ]

页数:

5 页

PDF大小:

132 K

Preliminary Technical Information
HiperFETTM
Power MOSFET
Q3-Class
VDSS = 800V
ID25 = 49A
RDS(on) 140mΩ
IXFN62N80Q3
trr
300ns
N-Channel Enhancement Mode
Fast Intrinsic Rectifier
Avalanche Rated
miniBLOC
E153432
S
Symbol
VDSS
Test Conditions
Maximum Ratings
G
TJ = 25°C to 150°C
TJ = 25°C to 150°C, RGS = 1MΩ
800
800
V
V
VDGR
S
VGSS
VGSM
Continuous
Transient
±30
±40
V
V
D
ID25
IDM
TC = 25°C
TC = 25°C, Pulse Width Limited by TJM
49
A
A
G = Gate
S = Source
D = Drain
180
IA
EAS
TC = 25°C
TC = 25°C
62
5
A
J
Either Source Terminal S can be used as
the Source Terminal or the Kelvin Source
(Gate Return) Terminal.
dv/dt
PD
IS IDM, VDD VDSS, TJ 150°C
TC = 25°C
50
V/ns
W
960
TJ
TJM
Tstg
-55 ... +150
150
-55 ... +150
°C
°C
°C
Features
z
z
z
International Standard Package
Low Intrinsic Gate Resistance
miniBLOC with Aluminum Nitride
Isolation
VISOL
50/60 Hz, RMS, t = 1minute
2500
3000
V~
V~
IISOL 1mA,
t = 1s
z
z
z
z
Md
Mounting Torque for Base Plate
Terminal Connection Torque
1.5/13
1.3/11.5
Nm/lb.in.
Nm/lb.in.
Avalanche Rated
Low Package Inductance
Fast Intrinsic Rectifier
Low RDS(on) and QG
Weight
30
g
Advantages
z
High Power Density
Easy to Mount
Space Savings
z
z
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C Unless Otherwise Specified)
Min.
800
3.5
Typ.
Max.
Applications
BVDSS
VGS(th)
IGSS
VGS = 0V, ID = 3mA
V
V
z
VDS = VGS, ID = 8mA
VGS = ±30V, VDS = 0V
VDS = 0.8 • VDSS, VGS = 0V
6.5
DC-DC Converters
Battery Chargers
Switch-Mode and Resonant-Mode
z
±200 nA
z
Power Supplies
DC Choppers
Temperature and Lighting Controls
IDSS
50 μA
z
TJ = 125°C
4 mA
z
RDS(on)
VGS = 10V, ID = 31A, Note 1
140 mΩ
DS100342A(04/12)
© 2012 IXYS CORPORATION, All Rights Reserved
IXFN62N80Q3
Symbol
Test Conditions
Characteristic Values
SOT-227B (IXFN) Outline
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 31A, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
Gate Input Resistance
28
48
S
Ciss
Coss
Crss
13.6
1260
100
nF
pF
pF
RGi
0.13
54
Ω
td(on)
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 31A
RG = 1Ω (External)
tr
20
62
ns
ns
td(off)
(M4 screws (4x) supplied)
tf
11
ns
Qg(on)
Qgs
270
90
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 31A
Qgd
120
RthJC
RthCS
0.13 °C/W
°C/W
0.05
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
62
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
250
1.5
trr
QRM
IRM
300 ns
IF = 31A, -di/dt = 100A/μs
1.6
13.4
μC
A
VR = 100V, VGS = 0V
Note
1. Pulse test, t 300μs, duty cycle, d 2%.
PRELIMINARY TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from data gathered during objective characterizations of preliminary engineering lots; but also may yet
contain some information supplied during a pre-production design evaluation. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXYS MOSFETs and IGBTs are covered
by one or more of the following U.S. patents: 4,860,072 5,017,508
4,881,106 5,034,796
4,835,592 4,931,844
5,049,961
5,063,307
5,187,117
5,237,481
5,381,025
5,486,715
6,162,665
6,259,123 B1
6,306,728 B1
6,404,065 B1 6,683,344
6,534,343
6,583,505
6,727,585
6,710,405 B2 6,759,692
6,710,463
7,005,734 B2 7,157,338B2
7,063,975 B2
6,771,478 B2 7,071,537
IXFN62N80Q3
Fig. 2. Extended Output Characteristics @ TJ = 25ºC
Fig. 1. Output Characteristics @ TJ = 25ºC
VGS = 10V
VGS = 10V
60
50
40
30
20
10
0
120
100
80
60
40
20
0
9V
8V
8V
7V
6V
7V
6V
0
1
2
3
4
5
6
7
8
0
5
10
15
20
25
30
VDS - Volts
VDS - Volts
Fig. 4. RDS(on) Normalized to ID = 31A Value vs.
Junction Temperature
Fig. 3. Output Characteristics @ TJ = 125ºC
3.0
2.6
2.2
1.8
1.4
1.0
0.6
0.2
VGS = 10V
8V
60
50
40
30
20
10
0
VGS = 10V
I D = 62A
7V
I D = 31A
6V
5V
0
2
4
6
8
10
12
14
16
18
20
-50
-25
0
25
50
75
100
125
150
VDS - Volts
TJ - Degrees Centigrade
Fig. 5. RDS(on) Normalized to ID = 31A Value vs.
Drain Current
Fig. 6. Maximum Drain Current vs.
Case Temperature
2.8
2.6
2.4
2.2
2.0
1.8
1.6
1.4
1.2
1.0
0.8
VGS = 10V
50
40
30
20
10
0
TJ = 125ºC
TJ = 25ºC
-50
-25
0
25
50
75
100
125
150
0
20
40
60
80
100
120
140
ID - Amperes
TC - Degrees Centigrade
© 2012 IXYS CORPORATION, All Rights Reserved
IXFN62N80Q3
Fig. 7. Input Admittance
Fig. 8. Transconductance
100
90
80
70
60
50
40
30
20
10
0
100
90
80
70
60
50
40
30
20
10
0
TJ = - 40ºC
25ºC
TJ = 125ºC
125ºC
25ºC
- 40ºC
4.0
0.2
0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
8.0
8.5
9.0
0
10
20
30
40
50
60
70
80
90
100
VGS - Volts
ID - Amperes
Fig. 10. Gate Charge
Fig. 9. Forward Voltage Drop of Intrinsic Diode
16
14
12
10
8
200
180
160
140
120
100
80
VDS = 400V
I D = 31A
I G = 10mA
6
60
TJ = 125ºC
4
40
TJ = 25ºC
2
20
0
0
0.4
0.6
0.8
1.0
1.2
1.4
0
50
100
150
200
250
300
350
400
VSD - Volts
QG - NanoCoulombs
Fig. 12. Forward-Bias Safe Operating Area
Fig. 11. Capacitance
1000
100
10
100,000
10,000
1,000
100
= 1 MHz
f
RDS(on) Limit
C
iss
250µs
C
oss
TJ = 150ºC
C
rss
TC = 25ºC
Single Pulse
1ms
10
1
5
10
15
20
25
30
35
40
10
100
1,000
VDS - Volts
VDS - Volts
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXFN62N80Q3
Fig. 13. Maximum Transient Thermal Impedance
1
0.1
0.01
0.001
0.0001
0.0001
0.001
0.01
0.1
1
10
Pulse Width - Seconds
© 2012 IXYS CORPORATION, All Rights Reserved
IXYS REF: F_62N80Q3(Q9) 5-20-11
