IXFL60N60
Symbol
gfs
TestConditions
Characteristic Values
ISOPLUS264OUTLINE
(TJ = 25°C, unless otherwise specified)
min.
typ. max.
VDS = 15 V; ID = 0.5 • ID25, pulse test
40
60
S
Ciss
Coss
Crss
10000
pF
pF
pF
VGS = 0 V, VDS = 25 V, f = 1 MHz
1600
360
td(on)
tr
td(off)
tf
43
52
110
26
ns
ns
ns
ns
VGS = 10 V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 1 Ω (External),
Qg(on)
Qgs
Qgd
380
78
190
nC
nC
nC
VGS = 10 V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RthJC
RthCK
0.18 K/W
K/W
0.05
Source-DrainDiode
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
Symbol
TestConditions
IS
VGS = 0 V
60
A
A
ISM
Repetitive;
240
pulse width limited by TJM
VSD
IF = IS, VGS = 0 V,
Pulse test, t ≤ 300 µs, duty cycle d ≤ 2 %
1.3
V
trr
IF = 25A, -di/dt = 100 A/µs, VR = 100 V
250 ns
QRM
IRM
1.5
10
µC
A
Notes: 1. Pulse test, t ≤ 300 µs,
duty cycle d ≤ 2%
2. Test current IT = 30A
