PXIS-2508
8-Slot 3U PXI Chassis with AC
Introduction
The ADLINK PXIS-2508 is the PXI chassis equipped with advanced features and functionalities. Compliant with PXI and Com-
pactPCI specifications, these chassis offer one system slot and seven peripheral slots for more versatile test and measurement
computing. Set in a sleek and lightweight chassis for superior portability, the PXIS-2508 also boasts of wider operating temperature
range, lower operating noise, and robust system build.
The PXIS-2508 is equipped with an intelligent control board that dynamically monitors and manages the chassis status including
the fan speed, system voltages, and internal temperature. A standard RS-232 monitoring port makes remote management possible
as chassis status are exported to and viewed from a remote computer using serial communications.
Equipped with an industrial grade 350 W AC power supply, the PXIS-2508 also come with front panel LED indicators, and easy-
access PXI slots with card guides for convenient installation and deployment. With innovative features and design, PXIS-2508 is
your best choices of PXI platform for test and measurement applications.
Features
■
PXI Hardware Specification Rev. 2.2 compliant
■
ꢀ Compactꢀ8-slotꢀPXIꢀchassisꢀwithꢀoneꢀsystemꢀslotꢀandꢀsevenꢀꢀ
ꢀ
PXI/CompactPCIꢀperipheralꢀslots
■
0°C to 55°C extended operating temperature range
ꢀ 41.6ꢀdBAꢀsilentꢀoperation
92 mm Fan
3000 RPM, 60 CFM, 38 dBA
■
■
Intelligent chassis management
ꢀ
ꢀ
•ꢀAutomaticꢀfanꢀspeedꢀcontrol
•ꢀChassisꢀstatusꢀmonitoringꢀandꢀexporting
•ꢀRemoteꢀchassisꢀpowerꢀon/offꢀcontrol
5.9 kg lightweight aluminum-metal construction
ꢀ 350ꢀWꢀindustrial-gradeꢀACꢀpowerꢀsupply
Power, temperature, and fan monitoring LEDs
Extended Operating Temperature Range
Silent Operation
ꢀ
■
■
■
Specifications
Power Supply
Physical
Emissions Compliance
■
AC Input
■
■
Number of slots: 8
EN 61326-1
FCC Class A
ꢀ ꢀ •ꢀInput voltage range: 100 to 240 VAC
ꢀ ꢀ •ꢀInput voltage frequency: 50 to 60 Hz
ꢀ ꢀ •ꢀInput current rating: 8 A/115 VAC or 4 A/230 VAC
■
(1 system slot + 7 peripheral slots)
Dimensions:
■
CE Compliance
ꢀ ꢀ •ꢀ280 mm (W) x 177 mm (H) x 303 mm (D)
■
Safety: EN 61010-1
■
DC Output
(10.9” x 6.9” x 11.8”)
■
Immunity: EN 61326-1
ꢀ ꢀ •ꢀTotal DC power output 350 W
■
Weight:
ꢀ ꢀ •ꢀ5.9 kg (13 lbs)
Load
Regulation
Maximum Ripple
& Noise
VDC
Minimum
Maximum
Recommended System Controller
Operating Environment
+5 V
+12 V
+3.3 V
-12 V
3.0 A
2.0 A
1.0 A
0.1 A
35.0 A
18.0 A
20.0 A
2.0 A
±5%
±5%
±5%
±5%
50 mV
120 mV
50 mV
PXIS-2508
■
Ambientꢀtemperature:ꢀ0˚Cꢀtoꢀ55˚Cꢀ(32˚Fꢀtoꢀ131˚F)
PXI-3980/3950/3920
√
■
Relative humidity: 10% to 90%, non-condensing
120 mV
Storage Environment
Cooling
■
Ambient temperature:
Ordering Information
■
Fans: 2 x 60 CFM fans with filters
Per-slot cooling capacity: 25 W
(verified by 55°C chamber test)
ꢀ ꢀ •ꢀ-20˚Cꢀtoꢀ70˚Cꢀ(-4˚Fꢀtoꢀ158˚F)
■
■ꢀPXIS-2508
3U 8-Slot Smart PXI Chassis with 350 W AC
Power Supply
■
Relative humidity: 10% to 90%, non-condensing
ꢀShockꢀandꢀVibration
Acoustic Emission
■
Functional shock: 30 G, half-sine, 11 ms pulse duration
■ꢀPXIS-2508ꢀRack-mountꢀKit
Rack-mount Kit for PXIS-2508
■
Sound Pressure Level (dBA)
■
Random vibration:
41.6 dB
47.3 dB
Minimal fan speed
Maximal fan speed
ꢀ ꢀ •ꢀOperating: 5 to 500 Hz, 0.5 GRMS, 3 axes
ꢀ ꢀ •ꢀNon-operating: 5 to 500 Hz, 2.46 GRMS, 3 axes
The combined output power of +5 V and +3.3 V cannot exceed 35 A.
■
Sound Power (dBA)
51.9 dB
55.5 dB
Minimal fan speed
Maximal fan speed
Tested in accordance with ISO 7779:1999/Amd. 1:2003(E)
