PXI Chassis
PXIS-2690P
14-Slot 3U Integrated Portable PXI Chassis with AC
Introduction
The ADLINK PXIS-2690P is one of the world’s first highly-integrated, 14-slot portable PXI chassis designed for advanced
PXI instrumentation applications. The PXIS-2690P comes with a system slot and 13 peripheral slots that conveniently
accommodate multiple PXI modules. The PXI chassis incorporates a bright 15” TFT LCD display with touch panel,
keyboard/touchpad, and a slim DVD combo drive into a single frame to provide superior portability and maximum
performance.
Constructed in high-quality aluminum alloy, the PXIS-2690P delivers a fortified and compact chassis minus the weight. An
industrial-grade 500 W AC power supply comes pre-installed to the chassis and offers reliable and stable power to system
components and peripheral modules. With three 120 mm x 120 mm x 25 mm system fans, the PXIS-2690P guarantees
superb air flow to maintain a cool and efficient operating temperature. The ADLINK PXIS-2690P is an ideal solution for
advanced PXI applications requiring portability, robustness, and easy-deployment.
■ꢀNotice:
As the display interface between the PXIS-2690P LCD and embedded controller is proprietary, the LCD can only be
operated by ADLINK’s PXI-3920 and PXI-3950 embedded controller.
■ꢀWarning:
Features
If any embedded controller other than ADLINK’s PXI-3920 and PXI-3950 is installed in the PXIS-2690P, the LCD may not
operate and damage to the PXI controller or backplane can occur.
■
Ruggedly-designed for portable instrumentation applications
■
ꢀ Supportsꢀbothꢀ3UꢀPXIꢀandꢀCompactPCIꢀmodules
■
PXI Specifications Rev. 2.2 compliant
■
ꢀ Equippedꢀwithꢀoneꢀsystemꢀslotꢀandꢀ13ꢀPXI/CompactPCIꢀꢀ
peripheral slots
■
ꢀ 15"ꢀhigh-brightnessꢀTFTꢀLCDꢀdisplayꢀwithꢀupꢀtoꢀ1024x768ꢀꢀ
resolution
■
Multiple input devices, including keyboard, touch pad, and
Top cover to protect
touch panel.
PXI/cPCIꢀmodulesꢀandꢀwirings
■
ꢀ Built-inꢀslim-typeꢀDVDꢀcomboꢀdrive
ꢀ
500ꢀWꢀindustrial-gradeꢀATXꢀpowerꢀsupply
Specifications
Recommended System Controller
PXIS-2690P-B
Power Supply
Operating Environment
PXI-3950/3920
√
■
■
Form factor: 500 W 2U ATX AC power supply
Ambientꢀtemperature:ꢀ0˚Cꢀtoꢀ50˚Cꢀ(32˚Fꢀtoꢀ122˚F)
Note: The PXI-3980 is incompatible for use in the PXIS-2690P-B
■
■
AC input: 100 to 240 VAC, 50 Hz to 60 Hz
Relative humidity: 10% to 90%, non-condensing
■
DC output: 500 W
Storage Environment
Ordering Information
ꢀ ꢀ
VDC
+5 V
Minimum
3.0 A
2.0 A
0.3 A
0.1 A
Maximum
50.0 A
35.0 A
28.0 A
0.8 A
■
Ambientꢀtemperature:ꢀ-20˚Cꢀtoꢀ70˚Cꢀ(-4˚Fꢀtoꢀ158˚F)
■ꢀPXIS-2690P-B
■
Relative humidity: 5% to 95%, non-condensing
14-Slot 3U integrated Portable PXI Chassis for
PXI-3920 and PXI-3950 (shipped with top cover
& a carriage bag)
+12 V
+3.3 V
-12 V
ꢀShockꢀandꢀVibration
■
Shock: 10 Gpeak-to-peak, 11 ms duration
■
Random Vibration
Integrated Devices
ꢀ ꢀ •ꢀOperating:ꢀ5ꢀHzꢀtoꢀ500ꢀHz,ꢀ0.31ꢀGRMS, each axis
ꢀ ꢀ •ꢀNon-operating:ꢀ5ꢀHzꢀtoꢀ500ꢀHz,ꢀ2.46ꢀGRMS, each axis
■
Display: 15" TFT LCD, up to 1024 x 768 resolution
Input device:
■
Emissions Compliance
ꢀ ꢀ •ꢀ87-keyꢀkeyboardꢀwithꢀtouchpad
ꢀ ꢀ •ꢀBuilt-inꢀ15"ꢀtouchꢀscreen
■
EN 55022
■
FCC Class A
■
DVD drive: slim-type DVD combo drive
CE Compliance
Cooling
■
Immunity: EN 55024
■
Fans: Three 120 mm x 120 mm x 25 mm (4.68” x
4.68” x 0.97”) ball-bearing fans, 74.5 CFM/each
Physical
■
Number of Slots: 14 (1 system slot + 13 peripheral slots)
■
Dimensions: 400 mm (W) x 291 mm (H) x 223.3 mm
(D) (15.6” x 11.34” x 8.7”), without fan frame
■
Weight: 12.5 kg (27.5 lbs)
Updated January 29, 2013. ©2013 ADLINK Technology, Inc. All Rights Reserved. All specifications are subject to change without further notice.
