continued
supply to the NAC will not be allowed to close if a short circuit condition
share a common external supply. Otherwise, each module operates
currently exists on the NAC. In addition, an algorithm is incorporated to find a independently from the others. The first module is addressed from 01 to 94
short when the module is active. The module will close all circuits that are not while the remaining modules are assigned to the next five higher addresses.
shorted to find the NAC with the problem.
Provisions are included for disabling a maximum of two unused modules.
All two-wire detectors being monitored must be two-wire compatibility
listed with the modules. The CZ-6 transmits the status of a zone of two-wire
detectors to the fire alarm control panel. Status conditions are reported as
normal, open or alarm. The interface module supervises the zone of detectors
and the connection of the external power supply.
SYNC-1 ACCESSORY CARD
The SYNC-1 is an optional accessory to the SC-6 and is designed to provide
aꢀmeansꢀofꢀsynchronizingꢀaꢀseriesꢀofꢀhorns,ꢀstrobes,ꢀandꢀhorn/strobes.ꢀTheꢀ
SYNC-1 is able to synchronize the temporal-coded horns, the one second
flashꢀtimingꢀofꢀtheꢀstrobe,ꢀandꢀsilencingꢀtheꢀhornsꢀofꢀtheꢀhorn/strobeꢀ
combination over a two-wire circuit while leaving the strobes active. Each
SYNC-1 accessory card has the capability of synchronizing six Class B circuits
or three Class A circuits.
IM-10 TEN INPUT MONITOR MODULE
The IM-10 Ten Input Monitor module provides an interface between a
control panel and normally open contact devices such as pull stations,
security contacts, or flow switches. The first address is set from 01 to 90 and
the remaining modules are automatically assigned to the next nine higher
addresses. Provisions are included for disabling a maximum of two unused
addresses. The supervised state (normal, open or short) of the monitored
device is sent back to the panel.
CZ-6 SIX ZONE INTERFACE MODULE
The CZ-6 Six Zone Interface module provides an interface between the
intelligent alarm system and a two-wire conventional detection zone. A
common SLC input is used for all modules, and the initiating device circuits
500 Series Module Specifications
General Specifications
Specifications: IM-10
Operating Voltage
15 to 32 VDC
Standby Current
Alarm Current
3.5 mA maximum
Maximum SLC Wiring Resistance 40 Ohms
60 mA maximum (assumes all ten LEDs
solid on)
Temperature Range
Relative Humidity
Wire Gauge
32°F to 120°F (0° to 49°C)
Maximum IDC Wiring Resistance 40 Ohms
10% to 85% noncondensing
12 to 18 AWG
Maximum IDC Voltage
Maximum IDC Current
12 VDC
1 mA
Dimensions
6.8˝H × 5.8˝W × 1.25˝D
Specifications: CR-6
Standby Current
Alarm Current
Accessories
1.45 mA maximum
32 mA maximum (assumes all six relays
have been switched once and all six
LEDs solid on)
Maximum IDC Wiring Resistance 40 Ohms
Relay Current
30ꢀmA/RelayꢀPulseꢀ(15.6ꢀmSꢀpulseꢀ
duration) pulse under panel control
SYNC-1 Accessory Card
Relay Contact Ratings
Specifications: CZ-6
Standby Current
30ꢀVDC;ꢀ70.7ꢀVAC
2 mA maximum
Alarm Current
40 mA maximum (assumes all six LEDs
solid on)
Maximum IDC Wiring Resistance 25 Ohms
External Supply Voltage
DC Voltage: 18 to 28 volts power
limited
BB-6 Enclosure with CH-6 Chassis
Ripple Voltage: 0.1 volts RMS maximum
Current: 90 mA per circuit
Specifications: SYNC-1
Operating Voltage
Compatible Detectors
Specifications: SC-6
Standby Current
Contact System Sensor for a current list
11 to 30 VDC
Maximum Load on a Loop
ClassꢀA/StyleꢀZ:ꢀ3A
ClassꢀA/StyleꢀY:ꢀ3Aꢀperꢀpair
2.25 mA maximum
Standby Current
+0 Position: 15 mA
+2 or +4 Position if connected to
supply: 2.5 mA
Alarm Current
35 mA maximum (assumes all six relays
have been switched once and all six
LEDs solid on)
Specifications: BB-2 Enclosure
Dimensions
Maximum NAC Circuit Wiring
Resistance
40 Ohms
12˝Hꢀ×ꢀ9˝Wꢀ×ꢀ3.67˝D
Power Rating Per Circuit
Relay Contact Ratings
63ꢀWꢀ@ꢀ70.7ꢀVAC
Specifications: BB-6 Enclosure
Dimensions
30 VDC; 110 VAC
24˝Hꢀ×ꢀ12.55˝Wꢀ×ꢀ6.47˝D
©2008 System Sensor.
3825ꢀOhioꢀAvenueꢀ•ꢀSt.ꢀCharles,ꢀILꢀ60174
Phone:ꢀ800-SENSOR2ꢀ•ꢀFax:ꢀ630-377-6495
Product specifications subject to change without notice. Visit systemsensor.com for
current product information, including the latest version of this data sheet.
A05-0344-003ꢀ•ꢀ1/09ꢀ•ꢀ#2088
