Available as: TZ9207, 4 Pin TO-8 (T4)
TN9207, 4 Pin Surface Mount (SM3)
RFAMPLIFIER
FP9207, 4 Pin Flatpack (FP4)
BX9207, Connectorized Housing (H1)
MODEL TZ9207
Features
Typical Intermodulation Performance at 25 º C
Second Order Harmonic Intercept Point ...... +39 dBm (Typ.)
Second Order TwoTone Intercept Point ...... +33 dBm (Typ.)
Third Order Two Tone Intercept Point .......... +20 dBm (Typ.)
ꢀ High Gain: 28.5 dB Typical
ꢀ Operating Temp. -55 ºC to +85 ºC
ꢀ Environmental ScreeningAvailable
Maximum Ratings
Specifications
Ambient OperatingTemperature .............. -55ºC to + 100 ºC
StorageTemperature ............................... -62ºC to + 125 ºC
CaseTemperature .................................................+ 125 ºC
DCVoltage .........................................................+ 15 Volts
Continuous RF Input Power ................................... + 6 dBm
Short Term RF Input Power..... 50 Milliwatts (1 Minute Max.)
Maximum Peak Power .................. 0.5 Watt ( 3 µsec Max.)
CHARACTERISTIC
TYPICAL
Ta= 25 ºC
5 - 200 MHz
MIN/MAX
Ta = -55 ºC to +85 ºC
5 - 200 MHz
Frequency
Gain (dB)
28.5
26.0 Min.
Power @ 1 dB
Comp. (dBm)
Reverse
+8
+6.0 Min.
-39 Max.
Isolation (dB)
-41
VSWR
In
Out
<1.25:1
<1.5:1
<5.0
2.0:1 Max.
2.0:1 Max.
6.0 Max.
Noise figure (dB)
Power Vdc
mA
+12
38
+12
42 Max.
Note: Care should always be taken to effectively ground the case of each unit.
Typical Performance Data
Gain (dB)
Reverse Isolation (dB)
Noise Figure (dB)
30
0
- 15
- 30
- 45
- 60
6
5
4
29
28
27
26
3
2
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
1 dB Comp. (dBm)
Input VSWR
Output VSWR
+10
+ 9
+ 8
+ 7
2.0
1.5
1.0
2.0
1.5
1.0
+ 6
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
Legend
+ 25 ºC
+ 85 ºC - - - - - - -55 ºC
Linear S-Parameters
FREQ.
MHz
– – – – S11– – – –
Mag Deg
– – – – S21– – – –
Mag Deg
– – – – S12– – – –
– – – – S22– – – –
Mag Deg
Mag
Deg
=========================================================================================================
5
10
50
100
150
200
.13
.13
.13
.12
.11
.08
-168
-176
176
167
159
150
33.89
33.82
33.66
33.12
32.59
31.82
2
2
- 22
- 45
- 68
- 90
0.01
0.00
0.01
0.01
0.01
0.01
8
- 19
26
.17
.17
.16
.15
.14
.13
- 8
- 7
- 20
- 41
- 63
- 92
22
25
30
01/14/05
