Available as: TZ9208, 4 Pin TO-8 (T4)
TN9208, 4 Pin Surface Mount (SM3)
RFAMPLIFIER
FP9208, 4 Pin Flatpack (FP4)
BX9208, Connectorized Housing
MODEL TZ9208
Features
Typical Intermodulation Performance at 25 º C
Second Order Harmonic Intercept Point ...... +50 dBm (Typ.)
Second Order Two Tone Intercept Point ....... +44 dBm (Typ.)
Third Order TwoTone Intercept Point ........... +28 dBm (Typ.)
!High Gain: 27.5 dB Typical
!Output Power: + 15.5 dBm Typical
!Operating Temp. -55 ºC to +85 ºC
!Environmental ScreeningAvailable
Maximum Ratings
Specifications
Ambient OperatingTemperature .............. -55ºC to + 100 ºC
StorageTemperature ............................... -62ºC to + 125 ºC
CaseTemperature .................................................+ 125 ºC
DCVoltage .........................................................+ 15 Volts
Continuous RF Input Power ................................. + 13 dBm
Short Term RF Input Power...... 50 Milliwatts (1 Minute Max.)
Maximum Peak Power .................. 0.5 Watt ( 3 µsec Max.)
CHARACTERISTIC
TYPICAL
Ta= 25 ºC
5 - 200 MHz
MIN/MAX
Ta = -55 ºC to +85 ºC
5 - 200 MHz
Frequency
Gain (dB)
27.5
26.0 Min.
Power @ 1 dB
Comp. (dBm)
Reverse
+15.5
-42
+14.5 Min.
-40 Max.
Isolation (dB)
VSWR
In
Out
<1.25:1
<1.5:1
<5.0
2.0:1 Max.
2.0:1 Max.
6.0 Max.
Noise figure (dB)
Power Vdc
mA
+12
90
+12
100 Max.
Note: Care should always be taken to effectively ground the case of each unit.
Typical Performance Data
Gain (dB)
Reverse Isolation (dB)
Noise Figure (dB)
29
28
27
26
25
0
- 15
- 30
- 45
- 60
7
6
5
4
3
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
1 dB Comp. (dBm)
Input VSWR
Output VSWR
+17
+16
+15
+14
2.0
1.5
1.0
2.0
1.5
1.0
+13
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
Legend
+ 25 ºC
+ 85 ºC - - - - - - -55 ºC
Linear S-Parameters
F R E Q . – – – – S11– – – –
MHz Mag Deg
– – – – S21– – – –
Mag Deg
– – – – S12– – – –
– – – – S22– – – –
Mag Deg
Mag
Deg
======================================================================================
5
50
.03
.02
.03
.05
.09
-116
-125
- 94
- 74
- 71
24.78
3
.00
.00
.00
.01
.01
8
7
71
60
66
.13
.13
.15
.17
.19
-165
-176
-176
-179
176
24.66 - 24
24.17 - 50
23.50 - 74
22.50 - 99
100
150
200
01/14/05
