Available as: TZ9416, 4 Pin TO-8 (T4)
TN9416, 4 Pin Surface Mount (SM3)
RFAMPLIFIER
FP9416, 4 Pin Flatpack (FP4)
BX9416, Connectorized Housing (H1)
MODEL TZ9416
Features
Typical Intermodulation Performance at 25 º C
Second Order Harmonic Intercept Point ...... +17 dBm (Typ.)
Second Order Two Tone Intercept Point ....... +11 dBm (Typ.)
Third Order Two Tone Intercept Point ............. +9 dBm (Typ.)
!Low Cost
!High Gain
!Operating Temp. -55 ºC to +85 ºC
!Enviromental ScreeningAvailable
Maximum Ratings
Specifications
Ambient OperatingTemperature .............. -55ºC to + 100 ºC
StorageTemperature ............................... -62ºC to + 125 ºC
CaseTemperature .................................................+ 125 ºC
DCVoltage .........................................................+ 18 Volts
Continuous RF Input Power ................................. + 13 dBm
Short Term RF Input Power...... 50 Milliwatts (1 Minute Max.)
Maximum Peak Power .................. 0.5 Watt ( 3 µsec Max.)
CHARACTERISTIC
TYPICAL
Ta= 25 ºC
5 - 400 MHz
MIN/MAX
Ta = -55 ºC to +85 ºC
5 - 400 MHz
Frequency
Gain (dB)
28
27.0 Min.
Power @ 1 dB
Comp. (dBm)
Reverse
-3.4
-40
-6.0 Max.
-35 Max.
Isolation (dB)
VSWR
In
Out
<1.25:1
<1.5:1
4.0
2.0:1 Max.
2.0:1 Max.
5.5 Max.
Noise figure (dB)
Power Vdc
mA
+15
20
+15
25 Max.
Note: Care should always be taken to effectively ground the case of each unit.
Typical Performance Data
Gain (dB)
Reverse Isolation (dB)
Noise Figure (dB)
30
29
0
- 15
- 30
- 45
- 60
6
5
4
28
27
26
3
2
Start 5 MHz
Stop 400 MHz
Start 5 MHz
Stop 400 MHz
Start 5 MHz
Stop 400 MHz
1 dB Comp. (dBm)
Input VSWR
Output VSWR
+ 2
0
2.0
1.5
1.0
2.0
1.5
1.0
- 2
- 4
- 6
Start 5 MHz
Stop 400 MHz
Start 5 MHz
Stop 400 MHz
Start 5 MHz
Stop 400 MHz
Legend
+ 25 ºC
+ 85 ºC - - - - - - -55 ºC
Linear S-Parameters
– – – – S11– – – –
Mag Deg
– – – – S21– – – –
Mag Deg
– – – – S12– – – –
– – – – S22– – – –
Mag Deg
FREQ.
MHz
Mag
Deg
======================================================================================
5
50
100
200
300
400
.03
.05
.08
.12
.16
.25
-138
-126
-127
-132
-130
-123
1
- 20
- 42
- 84
-125
-168
.01
.01
.01
.01
.01
.01
10
6
46
44
24
14
.18
.17
.17
.18
.14
.02
-
-
-
-
5
1
2
5
27.48
27.26
26.97
26.45
26.67
27.49
- 15
72
