1SS355
SURFACE MOUNT SWITCHING DIODE
Unit: inch (mm)
SOD-323
200 mW
POWER
90 Volts
VOLTAGE
FEATURES
.078(1.95)
.068(1.75)
• Small surgace mounting type (SOD-323)
• High Speed (TRR=1.2ns Typ)
• High reliability with surge current handing capability
• In compliance with EU RoHS 2002/95/EC directives
.038(.95)
.027(.70)
MECHANICAL DATA
Case: SOD-323 plastic
Terminals : Solderable per MIL-STD-750,Method 2026
Polarity : Color band cathode
Approx Weight: 0.0041 grams
Silicon epitaxial planar
.107(2.7)
.090(2.3)
.012(.30)MIN.
1
2
Cathode
Anode
MAXIMUM RATINGS
PARAMETER
SYMBOL
LIMITS
UNITS
V
Maximum Recurrent Peak Reverse Voltage
VRM
VR
90
80
Maximum DC Reverse Voltage
Maximum Peak Forward Current
Mean Rectifying Current
V
mA
mA
A
IFM
225
100
0.5
IO
Surge Current tp=1000ms(1sec)
IFSM
TJ,TSTG
Operating Junction and Storage Temperature Range
-55 to + 150
OC
ELECTRICAL CHARACTERISTICS
PARAMETER
SYMBOL
MIN.
--
TYP.
--
MAX.
1.2
UNITS
CONDITONS
Forward Voltage
V
F
V
IF=100mA
μA
pF
ns
Reverse Current
I
R
--
--
--
--
--
--
0.1
3.0
4.0
VR=80V
Capacitance Between Terminals
Reverse Recovery Time
C
T
V
R
=0V,f=1MH
Z
T
RR
V
R
=6V,I
F
=10mA,R
L
=100Ω
Note : 1.Mounted on min pad conditions using FR-4 PCB
REV.0.5-MAR.5.2010
PAGE . 1
