Mechanical operating cycles as operating time / typical
Item designation
10,000,000
• according to DIN EN 61346-2
S
S
• according to DIN 40719 extendable after IEC 204-2 / according
to IEC 750
Tightening torque / of the screws in the bracket / maximum
Ambient temperature
N·m
1
• during operating
°C
°C
-25 … +70
-40 … +80
IP66
• during storage
Protection class IP
climatic class / during the operating phase / according to EN
60721
3K6
Type of mounting
Shape / of the installation hole
Installation width
front mounting
round
28.5
22
mm
mm
mm
mm
Mounting diameter
Mounting height
8
Mounting depth
29
Certificates/approvals:
General Product Approval
Test Certificates
Special Test
Certificate
Shipping Approval
other
Confirmation
other
Further information:
Information- and Downloadcenter (Catalogs, Brochures,…)
http://www.siemens.com/industrial-controls/catalogs
Industry Mall (Online ordering system)
http://www.siemens.com/industrial-controls/mall
Cax online generator:
http://www.siemens.com/cax
Service&Support (Manuals, Certificates, Characteristics, FAQs,...)
http://support.automation.siemens.com/WW/view/en/3SB3000-0AA41/all
3SB3000-0AA41
