DWR-T818P-V233-04

型号：

DWR-T818P-V233-04

描述：

安费诺商用产品[ Amphenol Commercial Products ]

品牌：

AMPHENOL[ Amphenol ]

页数：

12 页

PDF大小：

1458 K

下载PDF手册
R
Amphenol
Now you're connected!
R
Amphenol
Now you're connected!
Table of Contents
CoolPower ® Overview ....................................................................................... Page 3
CoolPower ® Slim Drawer - DWR Series ........................................................... Page 4
CoolPower ® D-Sub - LCC17 Series .................................................................. Page 7
Amphenol Power Solutions ............................................................................... Page 9
Other Amphenol Commercial Products ........................................................... Page 11
Amphenol Commercial Products
Amphenol is a global provider of interconnect solutions to the designers and manufacturers of electronic equipment worldwide.
With our design creativity and cost effectiveness, Amphenol leads the way in interconnect development for internet and wireless
infrastructure, enterprise networks, industrial and medical electronics and storage appliances. Whether industry standard or
specific designs are required, Amphenol provides customers with products capable of performing at the leading edge of today's
technology. Our expertise in understanding and supporting our customers' various design needs has earned Amphenol a
reputation of excellence and quality among the world's technology leaders.
Telephone: (416) 291-4401 E-Mail: sales@amphenolcanada.com
All specifications are subject to change without notice.
R
Amphenol
Now you're connected!
Amphenol CoolPower® connectors are intended for medium and high current applications where cost and space are as critical as
performance. The CoolPower® family is comprised of multiple product series with both standardized and application-specific
designs. Amphenol offers a range of contact performance levels, termination styles and mechanical features.
At the heart of CoolPower® is the contact technology:
CoolBand
• CoolBand - High performance, cost-effective
• RADSOK® - State-of-the-art socket technology
• Low temperature rise, low contact resistance, low voltage drop
• Up to 250A per contact
• Standard gold plating or silver plating for true hot plug capabilities
alliis -
RADSOK®
Telephone: (416) 291-4401 E-Mail: sales@amphenolcanada.com
All specifications are subject to change without notice.
3
Amphenol
Now you're connected!
Amphenol CoolPower® Slim Drawer connectors combine performance, reliability and design flexibility with cost-sensitive features
critical in today's applications. This robust blind mating interconnect solution can be made to accommodate a variety of mixed
power and signal arrangements which may also require sequential mating and true hot plug capabilities. A number of mounting
and termination options are also available.
Slim Drawer features and options include:
• Power, signal and mixed contact combinations up to 8 power + 40 signal
• High current CoolBand or RADSOK® power contacts for maximum performance
• Optional sequential contact engagement (first make / last break)
• UL 1977 compliance
• Integrated alignment correction
• Available metal guide pin / float mount system for additional mating reliability
• PCB orientation features and keying to prevent improper mounting and mating
Telephone: (416) 291-4401 E-Mail: sales@amphenolcanada.com
All specifications are subject to change without notice.
4
R
Amphenol
Now you're connected!
CoolPower® Slim Drawer Ordering Code
DWR - T 8 18 P - V 2 3 3 - 0 4
Series
Panel Mounting Option
0 = No mounting feature
1 = No mounting ears
2 = Ø .128" [3.25mm] clear hole
4 = #4-40 Threaded hole
6 = M3 Threaded hole
Product Type
T = Slim Drawer
Number of Power Contact Positions*
0, 2, 4, 6, or 8
Number of Signal Contact Positions*
00, 02, 04, 06, 08, 10 ... 40
PCB Mounting Option
0 = No mounting feature
(vertical orientation)
Gender
A = Bracket with Ø .128" [3.25mm] clear hole
(right angle only)
P = Pin (Plug)
S = Socket (Receptacle)
B = Bracket with arrow-head board lock
(right angle only)
Orientation
V = Vertical
R = Right Angle
Plating Options
2 = 15µ" gold
3 = 30µ" gold
6 = 200µ" silver power, 15µ" gold signal
Contact Features
2 = Coolband Size CB8, standard signal (use for signal-only arrangements)
3 = Coolband Size CB10, standard signal
* A minimum of 2 power contacts or 10 signal contacts
are required in non-mixed contact arrangements
Consult factory for additional options
Contact Termination
1 = Solder Cup (8 AWG power, 20 AWG signal; vertical only)
3 = PCB Solder Tail, .150" tail length (Ø .148" [ 3.75mm ] power)
4 = Crimp Barrel (8 AWG power, 20 AWG solder cup signal; vertical only)
6 = Press-fit (for .093" PCB thickness; vertical only)
Number of Positions
Maximum Dimension (inch [mm])
Power
Signal
B
C
D
E
F
G
A
2
4
6
8
4.07 [103.48] 3.63 [92.30]
4.79 [121.77] 4.35 [110.59] 4.09 [103.81] 3.86 [98.04]
5.51 [140.06] 5.07 [128.88] 4.81 [122.10] 4.58 [116.33] 4.00 [101.50]
6.23 [158.34] 5.79 [147.17] 5.53 [140.39] 5.30 [134.62] 4.72 [119.79]
3.37 [85.52]
3.14 [79.76]
2.56 [64.92]
3.28 [83.21]
Up to 40
2.56 [64.92] 2.05 [52.12]
Consult factory for detailed specifications and dimensions
3.25
.128
MOUNTING CODE
02 SHOWN
3.25
.128
MOUNTING CODE
E
F
E
F
02 SHOWN
9.14
.360
TYP.
9.14
.360
TYP.
G
G
A1
A1
10.80
.425
10.80
.425
2.74
2.74
.108
TYP.
3.30
.108
.130
TYP.
SLOT ACCEPTS PIN CONNECTOR
HOUSING BLADE LOCATED OFF
CENTRE TO PREVENT IMPROPER
MATING
3.30
.130
A
B
B
3.18
.125
A
Telephone: (416) 291-4401 E-Mail: sales@amphenolcanada.com
All specifications are subject to change without notice.
5
R
Amphenol
Now you're connected!
Materials
Performance Ratings
Current Rating:
Power up to 60 A
Signal 5 A
Housing: High temperature thermoplastic, UL 94V-0
Contacts: PhBz signal, gold over nickel on mating area, matte tin on
termination end
Contact Resistance:
Insulation Resistance:
Power 0.25 mΩ max
Signal 20 mΩ max
5000 MW max
Copper alloy power pins, gold or silver over nickel all over
BeCu / TeCu sockets, gold or silver over nickel all over
Hardware: Steel or brass, nickel plated
Dielectric Withstanding Voltage: 2500 V DC
Operating Temperature:
Durability:
-55°C to 105°C
250 mating cycles
E64911
Available Documentation:
Product Specification S6031C
QTP 9300444
UL File:
CSA / TÜV:
Pending
QTR 9300444
CoolPower® Slim Drawer - Temperature Rise vs. Current
40.0
35.0
30.0
25.0
20.0
15.0
10.0
5.0
8 Circuits
6 Circuits
4 Circuits
2 Circuits
0.0
30
35
40
45
50
55
60
Current (Amps)
Telephone: (416) 291-4401 E-Mail: sales@amphenolcanada.com
6
All specifications are subject to change without notice.
R
Amphenol
Now you're connected!
Amphenol CoolPower® D-sub connectors offer the familiar shape and functionality of a combination D-subminature connector with
high current, high performance Amphenol CoolBand contact technology. The LCC17 series is intended for use in higher amperage
power supply and distribution applications where the current handling capabilities of typical combo D-sub connectors is insufficient.
LCC17 features and options include:
• Fully interchangeable with standard D-subs*
• High current CoolBand or RADSOK® power contacts for maximum performance
• 3W3 contact arrangements, male and female
• PCB solder tail, solder cup, crimp terminations
* CoolPower D-sub male and female connectors must be used together.
Telephone: (416) 291-4401 E-Mail: sales@amphenolcanada.com
All specifications are subject to change without notice.
7
R
Amphenol
Now you're connected!
CoolPower® D-Sub Ordering Code
LCC17 - A3W3 P A - 2 N 0
Series
Modifier
0 = Standard
Shell Size and Contact Arrangement
A3W3 = 3W3 Arrangement
Special Identifier
N = Standard / Non-filtered
Gender
P = Pin (Plug)
Mounting Option
S = Socket (Receptacle)
2 = .122" [3.10mm] Diameter clear mounting hole
4 = # 4-40 threaded mounting hole
A = # 4-40 threaded stand-off with board lock
(vertical PCB mount only)
Contact Termination
A = Right Angle PC Tail
E = Vertical PC Tail
F = Crimp
Consult factory for additional options and detailed specifications
M = Solder Cup
39.14
[1.541]
39.14
[1.541]
33.32
[1.312]
33.32
[1.312]
12.55
[.494]
7.90
[.311]
9.27
[.365]
12.55
[.494]
SOCKET
PIN
Ø 3.10
[.122]
MOUNTING
CODE 2
26.16
[1.030]
24.66
[.971]
#4-40 THREAD
MOUNTING
CODE 4
CoolPower® D-Sub Specifications
Materials
Performance Ratings
Housing: High temperature resistant nylon, UL 94V-0, black
Contacts: Power - Copper alloy, gold over nickel
Signal* - PhBz, gold over nickel on mating area
Hardware: Nickel Plated Steel or Brass
Current Rating:
Power 55 A
Signal* 5 A
Contact Resistance:
Insulation Resistance:
Power 0.25 mΩ max
Signal* 20 mΩ max
5000 MΩ max
Dielectric Withstanding Voltage: 1500 V DC
Operating Temperature:
Durability:
-55°C to 105°C
250 mating cycles
*First available LCC17 part numbers are 3W3 arrangements without signal contacts
UL, CSA, TÜV approvals pending
Telephone: (416) 291-4401 E-Mail: sales@amphenolcanada.com
8
All specifications are subject to change without notice.
R
Amphenol
Now you're connected!
Amphenol Power Solutions
Amphenol offers a variety of standard and application-specific power interconnect solutions for different mechanical and
electrical needs. Amphenol Power Solutions design capabilities are both flexible and cost sensitive. Available products can be
modified to fulfill virtually any requirement. Unique solutions are always considered. Please contact your local Amphenol
representative for more information.
Specialized Drawer Connectors
Amphenol's design flexibility allows us to offer non-standard variations of
Slim Drawer. Modifications may include larger diameter power contacts,
atypical contact arrangements or enhanced mechanical features. We
also have the ability to develop unique solutions with either CoolBand or
RADSOK® power contacts and competitive equivalents to legacy Drawer
connectors.
FCC22 Line Card Power
Amphenol Line Card power connectors are a cost effective, efficient
power distribution interconnect solution bringing power from the
supply to the line card. FCC22 is intended to meet very specific
application requirements at minimal cost.
Telephone: (416) 291-4401 E-Mail: sales@amphenolcanada.com
All specifications are subject to change without notice.
9
R
Amphenol
Now you're connected!
RPS Power Block
The RPS Power Block system is an application-specific, variable height
board-to-board solution for power distribution and control. RPS is
designed for current handling requirement between 15 and 150
amperes.
Energy Razor®
Intended for power supply, distribution and control in server, storage
and telecommunications applications, Energy Razor® is a competitive
mixed power and signal solution designed to handle up to 30 amperes
per blade contact.
Energy Edge®
Amphenol's card edge power connector series is designed to
handle up to 9 amperes per power contact. Like Razor®, the
Edge® series is intended for server, storage and networking &
telecom applications.
Telephone: (416) 291-4401 E-Mail: sales@amphenolcanada.com
10
All specifications are subject to change without notice.
R
Amphenol
Now you're connected!
Amphenol Commercial Products
Amphenol Commercial Products/Amphenol Canada Corp. offers a wide range of commercial products in order to
get you connected. Our activities are dedicated to the design, development and manufacturing of interconnect products
intended for use in various electrical and electronic devices. For more information on other Amphenol Commercial Products
such as Harsh Environmen Connectors, Modular Jacks and Filtered Connectors, please visit www.amphenolcanada.com for details.
Harsh Environment Connectors
Amphenol offers superior harsh environment connectors for
use in the data communications and telecommunication
markets. Discover how you can provide your customers with the
needed environmental sealing on the widely used connector
standard for RJ, all within the standard package size.
Modular Jacks
Amphenol's broad range of I/O registered jacks (RJ) offer
solutions to meet the increasing demand for faster speeds
and greater bandwidth required by telecom & networking
markets for VolP, Ethernet, WLAN, and other applications.
With the variety of available options coupled wih exceptional
performance and reliability, Amphenol has the solution for
your RJ requirements.
Filtered Connectors
Amphenol manufactures a complete line of filter D subs used
in all market segments. Our filter connectors are unique, offering
stress-isolated, solder-less technology in the chip capacitor design.
Our expertise in understanding and supporting our customer's filter
connect needs has earned us a reputation of quality and excellence
among the world's leading users of electronic components.
Telephone: (416) 291-4401 E-Mail: sales@amphenolcanada.com
All specifications are subject to change without notice.
11
Connectors
Phone: 416.291.4401
Fax: 416.754.8668
E-mail: sales@amphenolcanada.com
www.amphenolcanada.com
605 Milner Avenue, Toronto, ON M1B 5X6
R
Amphenol
Now you're connected!
厂商 型号 描述 页数 下载

MURATA

 		DWR-5/2.65-3.3/3-D12L1 [ DC-DC Regulated Power Supply Module, 2 Output, Hybrid, METAL PACKAGE-9 ] 9 页

MURATA

 		DWR-5/2.65-3.3/3-D12L2-C [ DC-DC Regulated Power Supply Module, 2 Output, Hybrid, ROHS COMPLIANT, METAL PACKAGE-9 ] 9 页

MURATA

 		DWR-5/2.65-3.3/3-D24-C [ DC-DC Regulated Power Supply Module, 2 Output, 10.395W, Hybrid, SMT-9 ] 9 页

MURATA

 		DWR-5/2.65-3.3/3-D24L1 [ DC-DC Regulated Power Supply Module, 2 Output, Hybrid, METAL PACKAGE-9 ] 9 页

MURATA

 		DWR-5/2.65-3.3/3-D48 [ DC-DC Regulated Power Supply Module, 2 Output, Hybrid, METAL PACKAGE-9 ] 9 页

MURATA

 		DWR-5/2.65-3.3/3-D48L1-C [ DC-DC Regulated Power Supply Module, 2 Output, Hybrid, ROHS COMPLIANT, METAL PACKAGE-9 ] 9 页

MURATA

 		DWR-5/2.65-3.3/3-D48L2-C [ DC-DC Regulated Power Supply Module, 2 Output, Hybrid, ROHS COMPLIANT, METAL PACKAGE-9 ] 9 页

DOMINANT

 		DWR-EJS-V1 大功率LED[ Power LED ] 13 页

DOMINANT

 		DWR-EJS-V2 大功率LED[ Power LED ] 13 页

DOMINANT

 		DWR-EJS-VW1-1 大功率LED[ Power LED ] 13 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.193933s
