DATA SHEET
SEMICONDUCTOR
2W005G THRU 2W10G
Glass Passivated Bridge Rectifiers
FEATURES
‧ Plastic package has underwriters laboratory
‧ Flammability classification 94V-0
WOG Unit: inch(mm)
‧ This seeries is UL recognized under component index, file number E127707
‧ Glass passivated chip junction
‧ High case dielectric strength
‧ Typical IR less than 0.5_A
‧ High surge current capability
‧ Ideal for printed circuit boards
‧ High temperature soldering guaranteed
260_/10 seconds, 0.375" (9.5mm) lead length at 5 lbs (2.3kg) tension
‧ High temperature soldering : 260OC / 10 seconds at terminals
‧ Pb free product at available : 99% Sn above meet RoHS
environment substance directive request
MECHANICAL DATA
‧ Case: Molded Plastic body over passivated junctions
‧ Terminal: Plated leads solderable per MIL - STD - 750
method 2026
‧ Mounting position : Any
‧ Weight: 0.04 ounce, 1.1 gram
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25_ ambient temperature unless otherwise specified
SYMBOLS 2W005G 2W01G 2W02G 2W04G 2W06G 2W08G 2W10G UNIT
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
VRRM
VRMS
VDC
1000
Volts
50
35
50
100
70
200
140
200
400
280
400
600
420
600
800
560
800
700
Volts
Volts
Maximum DC Blocking Voltage
1000
100
Maximum Average Forward Rectified
Current, at 0.375' (9.5mm) lead length (Note 1)
Peak Forward Surge Current
IF(AV)
IFSM
2.0
Amps
8.3ms single half sine - wave superimposed on
rated load (JEDEC method )
60
Amps
Rating for Fusing (t<8.3ms)
I2t
A2s
15
per element at 2.0A DC
VF
1.1
Volts
Maximum Instantaneous Forward Voltage Drop
TA=25℃
5.0
μA
μA
pF
Maximum Average Reverse Current
at rated DC blocking voltage
IR
TA=125℃
500
Typical Junction Capacitance per leg at 4.0V, 1MHz
Typical Thermal Resistance
Cj
40
20
R_JI
R_JA
TJ
15
40
℃/W
per leg (Note1)
Operating Temperature Range
Storage Temperature Range
NOTES:
-55 to +150
-55 to +150
℃
TSTG
1. Thermal resistance from junction to lead at 0.375" (9.5mm) lead length P.C.B. mounting.
http://www.yeashin.com
1
REV.02 20120305
