Available as: CZ8202, 4 Pin TO-12 (T7)
TN8202, 4 Pin Surface Mount (SM3)
RFAMPLIFIER
MODEL CZ8202
Features
Typical Intermodulation Performance at 25 º C
Second Order Harmonic Intercept Point ..... +40 dBm (Typ.)
Second Order Two Tone Intercept Point ....... +34 dBm (Typ.)
Third Order TwoTone Intercept Point ........... +23 dBm (Typ.)
ꢀ HighGain: 29 dB Typical
ꢀ Medium Output Power: +9 dBm Typical
ꢀ
Operating Temp. 0 ºC to +70 ºC
ꢀ Environmental ScreeningAvailable
Maximum Ratings
Specifications
Ambient OperatingTemperature .............. -55ºC to + 100 ºC
StorageTemperature ............................... -62ºC to + 125 ºC
CaseTemperature .................................................+ 125 ºC
Continuous RF Input Power ................................. + 13 dBm
Short Term RF Input Power...... 50 Milliwatts(1 Minute Max.)
Maximum Peak Power ................... 0.5 Watt( 3 µsec Max.)
CHARACTERISTIC
TYPICAL
Ta= 25 ºC
5 - 200 MHz
MIN/MAX
Ta = 0 ºC to +70 ºC
5 - 200 MHz
Frequency
Gain (dB)
Power @ 1 dB
Comp. (dBm)
29
27 Min.
+11.5
+9.5 Min.
Reverse
Isolation (dB)
-41
-39 Max.
VSWR
In
Out
<1.25:1
<1.25:1
<5.5
2.0:1 Max.
2.0:1 Max.
6.5 Max.
Noise figure (dB)
Power Vdc
mA
+15
55
+15
60 Max.
Note: Care should always be taken to effectively ground the case of each unit.
Typical Performance Data
Reverse Isolation (dB)
Noise Figure (dB)
Gain (dB)
31
30
0
- 15
- 30
- 45
- 60
7
6
5
29
28
27
4
3
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
1dB Comp. (dBm)
Input VSWR
Output VSWR
+14
+13
+12
+11
2.0
1.5
1.0
2.0
1.5
1.0
+10
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
Start 5 MHz
Stop 200 MHz
Legend
+25 ºC
+70 ºC - - - - - - 0 ºC
Linear S-Parameters
FREQ.
– – – – S11– – – –
Mag Deg
– – – – S21– – – –
Mag Deg
– – – – S12– – – –
– – – – S22– – –
Mag Deg
MHz
Mag Deg
======================================================================================
5
25
50
100
150
200
.07
.07
.07
.07
.07
.06
-160
-173
-174
-171
-169
-165
30.53
2
.01
0.00
.01
7
-6
4
.08
.07
.07
.06
.05
.04
-15
-5
-8
-5
2
30.44 -10
30.23 -21
29.49 -42
28.26 -63
26.74 -83
.01
5
.01 18
.01 20
21
11/04/04
