OX 8100 et OX 8050 - 100 MHz and 60 MHz analog/digital oscilloscopes
SPECIFICATIONS
OX 8100
OX 8050
• Vertical deflection
Blandwidth
100 MHz
Analog 40 MHz
Digital 60 MHz
2
Number of channels
Input impedance
2
1 MΩ / 15 pF
400 V
1 MΩ / 25 pF
400 V
Maximum input voltage
Sensitivity
2 mV to 5 V/div.
1 to 2.5
1 mV to 20 V/div.
1 to 2.5
Continuous gain adjustment
Operating modes
CH1, CH2, XY, ALT, CHOP,
ADD, BWL, -CH2
CH1, CH2, XY, CHOP,
ADD, -CH2, MULT
• Horizontal deflection
Timebase
2
1 + delay
Sweep speed
Analog: 50 ns to 100 ms/div.
Analog: 50 ns to 100 ms/div.
Digital: 5 ns to 200 s/div.
Digital: 5 ns to 200 s/div.
Timebase magnification (analog)
Continuous LV adjustment (analog)
XY mode
10
10
1 to 2.5
4 MHz
1 to 2.5
2 MHz
• Triggering
Trigger sensitivity
Internal: 0.5 to 1 div.
External : 60 to 150 mV
PAL, SECAM, NTSC
Line counting
Internal: 0.5 to 1 div.
External : 100 to 200 mV
PAL, SECAM, NTSC
Line counting
TV trigger
• Digital memory
Sampling frequency
Single shot: 100 MS/s
Single shot: 100 MS/s
EST: 20 GS/s
EST: 20 GS/s
Memory capacity
Vertical resolution
Number of converters
Glitch mode
2 x (1, 8, or 16 k)
2 x (1, 8, or 16 k)
8 bits
2
8 bits
2
20 ns
yes
20 ns
yes
Envelope mode
Triggered Roll mode
XY digital mode
yes
yes
100 MHz
60 MHz
• Special features
AUTOSET
yes
yes
Probe ratio compensation
Measurement cursors (analog/digital)
Automatic measurements
1/1, 1/10, 1/100
Vt, 1/t, phase
17
1/1, 1/10, 1/100
Vt, 1/t, phase
17
GENERAL CHARACTERISTICS
Configuration memory
READOUT
1
yes
1
yes
Interfaces
RS232 and Centronics
IEEE option
RS232 and Centronics
IEEE option
Interface drivers
Power supply
Weight
PC and printers
96 to 264 V - 45 to 440 Hz
7 kg
PC and printers
96 to 264 V - 45 to 440 Hz
5.5 kg
IEC 1010 safety
Warranty
Cat. II, 400 V
24 months
Cat. II, 400 V
24 months
