IXFH270N06T3

型号：

IXFH270N06T3

品牌：

IXYS[ IXYS CORPORATION ]

页数：

6 页

PDF大小：

291 K

下载PDF手册
Advance Technical Information
TrenchT3TM HiperFETTM
Power MOSFET
VDSS = 60V
ID25 = 270A
RDS(on) 3.1m
IXFA270N06T3
IXFP270N06T3
IXFH270N06T3
N-Channel Enhancement Mode
Avalanche Rated
Fast Intrnsic Rectifier
TO-263 AA (IXFA)
G
S
D (Tab)
Symbol
VDSS
Test Conditions
Maximum Ratings
TO-220AB (IXFP)
TJ = 25C to 175C
60
60
V
V
VDGR
TJ = 25C to 175C, RGS = 1M
VGSM
Transient
20
V
G
D
D (Tab)
S
ID25
ILRMS
TC = 25C
Lead Current Limit, RMS
270
160
A
A
TO-247 (IXFH)
IDM
TC = 25C, Pulse Width Limited by TJM
675
A
IA
TC = 25C
TC = 25C
135
1.5
A
J
EAS
G
D
S
PD
TC = 25C
480
W
D (Tab)
TJ
-55 ... +175
175
C
C
C
G = Gate
S = Source
D
= Drain
Tab = Drain
TJM
Tstg
-55 ... +175
TL
TSOLD
Maximum Lead Temperature for Soldering
Plastic Body for 10s
300
260
°C
°C
Features
FC
Md
Mounting Force (TO-263)
Mounting Torque (TO-220 & TO-247)
10..65 / 2.2..14.6
1.13 / 10
N/lb
m/lb.in
International Standard Packages
175°C Operating Temperature
High Current Handling Capability
Avalanche Rated
Weight
TO-263
TO-220
TO-247
2.5
3.0
6.0
g
g
g
Fast Intrinsic Rectifier
Low RDS(on)
Advantages
Symbol
Test Conditions
Characteristic Values
(TJ = 25C Unless Otherwise Specified)
Min. Typ.
Max.
Easy to Mount
Space Savings
High Power Density
BVDSS
VGS(th)
IGSS
VGS = 0V, ID = 250A
VDS = VGS, ID = 250A
VGS = 20V, VDS = 0V
VDS = VDSS, VGS = 0V
60
V
V
2.0
4.0
            200 nA
Applications
IDSS
10 A
DC-DC Converters & Off-Line UPS
Primary-Side Switch
High Current Switching Applications
TJ = 150C
VGS = 10V, ID = 100A, Notes 1, 2
1.5 mA
RDS(on)
3.1 m
DS100698A(01/16)
© 2016 IXYS CORPORATION, All Rights Reserved
IXFA270N06T3 IXFP270N06T3
IXFH270N06T3
Characteristic Values
Min. Typ. Max.
Symbol
Test Conditions
(TJ = 25C, Unless Otherwise Specified)
gfs
VDS = 10V, ID = 60A, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
83
138
S
Ciss
Coss
Crss
12.6
1380
62
nF
pF
pF
RGi
Gate Input Resistance
1.1
td(on)
tr
td(off)
tf
39
36
48
20
ns
ns
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 3(External)
Qg(on)
Qgs
200
68
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
40
RthJC
RthCS
0.31 C/W
TO-220
TO-247
0.50
0.21
C/W
C/W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min. Typ.
Max.
IS
VGS = 0V
270
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = 100A, VGS = 0V, Note 1
IF = 135A, VGS = 0V
1080
1.4
trr
47
23
ns
A
-di/dt = 100A/s
VR = 40V
IRM
QRM
530
nC
Notes: 1. Pulse test, t 300s, duty cycle, d  2%.
2. On through-hole packages, RDS(on) Kelvin test contact location must be 5mm
or less from the package body.
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are
derived from a subjective evaluation of the design, based upon prior knowledge and experi-
ence, and constitute a "considered reflection" of the anticipated result. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXYS MOSFETs and IGBTs are covered
by one or more of the following U.S. patents: 4,860,072 5,017,508
4,881,106 5,034,796
4,835,592 4,931,844
5,049,961
5,063,307
5,187,117
5,237,481
5,381,025
5,486,715
6,162,665
6,259,123 B1
6,306,728 B1
6,404,065 B1 6,683,344
6,534,343
6,583,505
6,727,585
6,710,405 B2 6,759,692
6,710,463
7,005,734 B2 7,157,338B2
7,063,975 B2
6,771,478 B2 7,071,537
IXFA270N06T3 IXFP270N06T3
IXFH270N06T3
Fig. 1. Output Characteristics @ TJ = 25ºC
Fig. 2. Extended Output Characteristics @ TJ = 25ºC
280
240
200
160
120
80
350
300
250
200
150
100
50
V
= 10V
V
= 15V
GS
GS
10V
9V
7V
8V
7V
6.5V
6V
5V
6V
5V
40
0
0
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
0
1
2
3
4
5
6
7
8
9
10
VDS - Volts
VDS - Volts
Fig. 4. Normalized RDS(on) to ID = 135A Value vs.
Junction Temperature
Fig. 3. Output Characteristics @ TJ = 150ºC
280
240
200
160
120
80
2.2
2.0
1.8
1.6
1.4
1.2
1.0
0.8
0.6
V
= 15V
GS
V
= 10V
GS
10V
9V
8V
7V
6V
I
D
= 270A
I
D
= 135A
5V
4V
40
0
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
-50
-25
0
25
50
75
100
125
150
175
TJ - Degrees Centigrade
VDS - Volts
Fig. 5. Normalized RDS(on) to ID = 135A
vs. Drain Current
Fig. 6. Drain Current vs. Case Temperature
180
160
140
120
100
80
2.4
2.2
2.0
1.8
1.6
1.4
1.2
1.0
0.8
V
= 10V
GS
15V
External Lead Current Limit
T = 175ºC
J
60
40
T = 25ºC
J
20
0
-50
-25
0
25
50
75
100
125
150
175
0
40
80
120
160
200
240
280
ID - Amperes
TC - Degrees Centigrade
© 2016 IXYS CORPORATION, All Rights Reserved
IXFA270N06T3 IXFP270N06T3
IXFH270N06T3
Fig. 7. Input Admittance
Fig. 8. Transconductance
160
140
120
100
80
280
240
200
160
120
80
V
= 10V
V
= 10V
DS
DS
T
J
= - 40ºC
25ºC
150ºC
T
J
= 150ºC
60
25ºC
40
- 40ºC
40
20
0
0
0
20
40
60
80
100
120
140
160
3.0
3.5
4.0
4.5
5.0
5.5
6.0
6.5
ID - Amperes
VGS - Volts
Fig. 10. Gate Charge
Fig. 9. Forward Voltage Drop of Intrinsic Diode
10
9
8
7
6
5
4
3
2
1
0
300
250
200
150
100
50
V
= 30V
DS
I
I
= 135A
= 10mA
D
G
T
J
= 150ºC
T
J
= 25ºC
0
0
20
40
60
80
100
120
140
160
180
200
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
QG - NanoCoulombs
VSD - Volts
Fig. 11. Capacitance
Fig. 12. Forward-Bias Safe Operating Area
100000
10000
1000
100
1000
100
10
R
Limit
DS(on)
= 1 MHz
f
C
iss
External Lead Limit
100µs
C
oss
1ms
1
T = 175ºC
J
10ms
T
= 25ºC
C
DC
C
rss
Single Pulse
0.1
10
1
10
100
0
5
10
15
20
25
30
35
40
VDS - Volts
VDS - Volts
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXFA270N06T3 IXFP270N06T3
IXFH270N06T3
Fig. 14. Resistive Turn-on Rise Time
vs. Drain Current
Fig. 13. Resistive Turn-on Rise Time
vs. Junction Temperature
40
39
38
37
36
35
34
33
32
39
38
37
36
35
34
33
32
R
= 3Ω , V = 10V
R = 3Ω , V = 10V
G GS
G
GS
V
= 30V
V
= 30V
DS
DS
T
J
= 25ºC
I
= 270A
D
T
J
= 150ºC
I
= 135A
D
120
140
160
180
200
220
240
260
280
25
50
75
100
125
150
TJ - Degrees Centigrade
ID - Amperes
Fig. 16. Resistive Turn-off Switching Times
vs. Junction Temperature
Fig. 15. Resistive Turn-on Switching Times
vs. Gate Resistance
23
22
21
20
19
18
65
600
500
400
300
200
100
0
150
t f
td(off)
t r
td(on)
R
= 3Ω, V = 10V
GS
TJ = 150ºC, V = 10V
125
100
75
50
25
0
G
GS
60
55
50
45
40
V = 30V
DS
V
= 30V
DS
I
= 270A
D
I
= 135A
D
I
= 135A
D
I
= 270A
D
25
50
75
100
125
150
2
4
6
8
10
12
14
16
18
RG - Ohms
TJ - Degrees Centigrade
Fig. 18. Resistive Turn-off Switching Times
vs. Gate Resistance
Fig. 17. Resistive Turn-off Switching Times
vs. Drain Current
300
250
200
150
100
50
300
250
200
150
100
50
23
22
21
20
19
70
60
50
40
30
t f
td(off)
I
= 270A, 135A
t f
td(off)
D
R
G
= 3ꢀ, VGS = 10V
T = 150ºC, V = 10V
J
GS
VDS = 30V
V
= 30V
DS
T = 25ºC
J
I
= 270A
D
T = 150ºC
J
T = 25ºC
J
0
0
2
4
6
8
10
12
14
16
18
120
140
160
180
200
220
240
260
280
ID - Amperes
RG - Ohms
© 2016 IXYS CORPORATION, All Rights Reserved
IXFA270N06T3 IXFP270N06T3
IXFH270N06T3
Fig. 19. Maximum Transient Thermal Impedance
1
0.1
0.01
0.001
0.00001
0.0001
0.001
0.01
0.1
1
10
Pulse Width - Seconds
TO-247 Outline
TO-220 Outline
TO-263 Outline
E
A
E
E
A
A1
A
R
A2
0P
E2/2
E1
4
0P
L2
c2
Q
U
T
H1
Q
D1
S
D
L
E2
L1
D
(D2)
(E1)
D
1
2
3
4
D1
b2
4
1
2
3
L3
L1
1
2
3
b
c
e
A2
EJECTOR
PIN
L1
L
1 = Gate
L
A1
2,4 = Drain
3 = Source
L4
0- 8
b2
b
c
c
3X
b
e
L1
b4
e1
3X b2
A1
e
1 = Gate
2,4 = Drain
3 = Source
1 = Gate
2,4 = Drain
3 = Source
W
BOTTOM FLATNESS
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXYS REF: F_270N06T3(U6-M05) 1-27-16
厂商 型号 描述 页数 下载

ILSI

 		IXF 晶体滤波器3线金属包装[ Crystal Filter 3 Lead Metal Package ] 1 页

ILSI

 		IXF-10A15AF 晶体滤波器3线金属包装[ Crystal Filter 3 Lead Metal Package ] 1 页

ILSI

 		IXF-10A15AT 晶体滤波器3线金属包装[ Crystal Filter 3 Lead Metal Package ] 1 页

ILSI

 		IXF-10A15BF 晶体滤波器3线金属包装[ Crystal Filter 3 Lead Metal Package ] 1 页

ILSI

 		IXF-10A15BT 晶体滤波器3线金属包装[ Crystal Filter 3 Lead Metal Package ] 1 页

ILSI

 		IXF-10A15CF 晶体滤波器3线金属包装[ Crystal Filter 3 Lead Metal Package ] 1 页

ILSI

 		IXF-10A15CT 晶体滤波器3线金属包装[ Crystal Filter 3 Lead Metal Package ] 1 页

ILSI

 		IXF-10A15DF 晶体滤波器3线金属包装[ Crystal Filter 3 Lead Metal Package ] 1 页

ILSI

 		IXF-10A15DT 晶体滤波器3线金属包装[ Crystal Filter 3 Lead Metal Package ] 1 页

ILSI

 		IXF-10A20AF 晶体滤波器3线金属包装[ Crystal Filter 3 Lead Metal Package ] 1 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.201338s
