Type
Date
Part Number
Project
Comments
Prepared By
Mechanical Information:
Patents Pending
Container Dimensions: 15” X 16” X 10”
381mm x 407mm x 254mm
®
SafeSite LED White Downlight
Container Weight:
Mounting:
19 lbs (8.2 kg)
Threaded 1” NPT on 3 sides of splice box
Electrical specifications:
Operating Voltage:
120-277 VAC, 50/60 Hz
(DC versions available - consult factory)
Mtg. Hole
Power Consumption:
Amps:
100 W
0.83
Operating Temp:
Harmonics:
-40ºF to +133ºF (-40ºC to +55ºC)
IEC 6100-3-2
Surge / Lightning
Protection:
1 kV line to line
2 kV line to ground
THD:
< 20 %
> 0.9
Dimensions in Inches [mm]
Power Factor:
Material:
Lens:
Certifications & Ratings:
w Class I, Div 2, Groups A, B, C, D hazardous environments T4A rated
w Class II, Div 2, Groups F, G hazardous environments T3B rated
w Certified to UL844 / NEMA 4X / UL1598 / UL1598A / CSA 22.2
w IP66 rated
UV stabilized Polycarbonate with enhanced
abrasive resistance
Body:
Grey epoxy powder coat aluminum
Clear anodized aluminum
Features & Benefits:
w Low power consumption
Heat sink:
w Instant on/off response
Accessories (hardware): Stainless steel
w Weather/corrosion resistant lamp assembly and housing
w Universal input (120-277 VAC), 50/60 Hz
w *Resistant to shock (IEC 68-2-27) and vibration (FAA 150/5345-46C)
w 5 year warranty
Photometric Information:
CRI (typ):
CCT:
70
w 70% lumen maintenance over 60,000 operating hours
4500-7000K
Order Codes:
SafeSite Series 150 Watt Equivalent Fixtures
SafeSite Series 250 Watt Equivalent Fixtures
HZC-02-150-1111-201
HZC-02-150-1111-301
HZC-04-150-1111-201
HZC-04-150-1111-301
*HZC-02-150-1111-202
*HZC-02-150-1111-302
**HZC-02-150-1111-211
**HZC-02-150-1111-311
CID2/CIID2 Cert- 180 Degree
CID2/CIID2 Cert - 360 Degree
ATEX Cert - 180 Degree
HZC-02-250-1111-201
HZC-02-250-1111-301
HZC-04-250-1111-201
HZC-04-250-1111-301
*HZC-02-250-1111-202
*HZC-02-250-1111-302
**HZC-02-250-1111-211
**HZC-02-250-1111-311
CID2/CIID2 Cert- 180 Degree
CID2/CIID2 Cert - 360 Degree
ATEX Cert - 180 Degree
ATEX Cert - 360 Degree
ATEX Cert - 360 Degree
CID2/CIID2 Cert - 180 Degree, HVS
CID2/CIID2 Cert - 360 Degree, HVS
CID2/CIID2 Cert - 180 Degree, PC
CID2/CIID2 Cert - 360 Degree, PC
CID2/CIID2 Cert - 180 Degree, HVS
CID2/CIID2 Cert - 360 Degree, HVS
CID2/CIID2 Cert - 180 Degree, PC
CID2/CIID2 Cert - 360 Degree, PC
Additional Options:
* HVS order codes are High Vibration & Shock resistant with T4 rating (CID2)
**PC order codes are hard coated lens and powder coat on all exposed aluminum parts
Dialight Corporation • 1501 Route 34 South Farmingdale, NJ 07727 • www.dialight.com • 1-732-919-3119
Dialight reserves the right to make changes at any time in order to supply the best product possible. Please reference www.dialight.com for the most current literature.
pg. 1
