PLASTIC FILM CAPACITORS
Metallized Polypropylene Film AC Power Capacitor
XG series
Self-healing and non-inductive wound by metallized film, with flame-retardant
epoxy resin coating for humidity resistance.
Application
Motor running
Specifications
Item
Performance Characteristics
Maximum permissible
temperature
+85˚C (Z)
–25˚C (B)
Type numbering system (Example : 200VAC 4µF)
1
2
3
4
5
6
7
8
9 10 11 12
Minimum ambient
temperature
E X G 2 D 4 0 5 H R P T
AC usage applicable (T)
Soldered CP wire (P)
Rated Voltage Range
Rated Capacitance Range
200, 230, 250VAC
0.5 ~ 10µF
Polypropylene film (R)
Capacitance Tolerance +10 ~ –5%
Capacitance tolerance (+10 ~ –5% : H)
Loss factor
0.12% or less (at 20˚C, 50/60Hz 200VAC)
Rated Capacitance (
4µF)
Between Terminals : Rated Voltage(VAC) × 175% 10secs.
Between Terminals connected together and case : 2000VAC 60secs.
Between Terminals connected together and case :
1000 MΩ or more (at 500VDC)
Rated voltage (200V
)
Withstand Voltage
Series name
Type
Insulation Resistance
Encapsulation
Flame retardant epoxy resin
Current duration class
Safety Mechanism
40D (40,000h)
Non-included
Drawing
W MAX.
T MAX.
H MAX.
1.5MAX.
25 MIN.
φ 0.8 ±0.05
+1.0
–2.0
P
Straight lead type
Dimensions
Unit : mm
V(Code)
200VAC (2D)
230VAC (F5)
250VAC (2E)
Code Size
T
W
H
P
T
W
H
P
T
W
H
P
Cap.(µF)
0.5
504
105
155
205
255
305
355
405
455
505
605
705
805
905
106
5.5
26.0
26.0
26.0
26.0
26.0
26.0
31.0
31.0
31.0
31.0
36.0
36.0
36.0
36.0
36.0
15.5
17.0
18.0
19.5
20.5
21.5
20.5
21.5
22.0
23.5
23.5
24.5
25.5
27.5
28.0
22.5
22.5
22.5
22.5
22.5
22.5
27.5
27.5
27.5
27.5
32.5
32.5
32.5
32.5
32.5
6.0
26.0
26.0
26.0
26.0
26.0
31.0
31.0
31.0
31.0
31.0
36.0
36.0
36.0
36.0
36.0
16.0
17.5
19.0
20.5
22.0
21.5
22.0
24.0
25.0
25.5
25.5
27.5
28.5
29.5
30.5
22.5
22.5
22.5
22.5
22.5
27.5
27.5
27.5
27.5
27.5
32.5
32.5
32.5
32.5
32.5
7.0
26.0
26.0
26.0
26.0
31.0
31.0
31.0
31.0
36.0
36.0
36.0
36.0
36.0
16.5
19.0
20.5
23.0
23.0
24.0
25.0
26.0
25.5
26.0
28.5
29.5
31.0
22.5
22.5
22.5
22.5
27.5
27.5
27.5
27.5
32.5
32.5
32.5
32.5
32.5
1.0
7.0
8.0
9.0
1.5
8.5
9.5
11.0
12.0
11.5
12.5
13.5
14.5
14.0
14.5
15.5
16.5
18.0
2.0
9.5
10.5
12.0
11.5
12.5
12.5
13.5
14.0
14.0
14.5
15.5
16.5
17.5
2.5
10.5
11.5
11.0
11.5
12.5
12.5
12.0
13.0
14.0
14.5
15.0
3.0
3.5
4.0
4.5
5.0
6.0
7.0
8.0
9.0
10.0
CAT.8100R
