TYPE NX 5.0x3.2 SEAM SEALED CRYSTAL CLOCK OSCILLATOR
VER. B
3-Aug-15
NX5041D0100.000000
ELECTRICAL SPECIFICATIONS
SRe Part Number :
NX5041D0100.000000
Item
Symbol
Specifications
Units
Notes
Nominal Frequency
Fo
FT
100.000000
± 25
MHz
Frequency Stability
ppm **See note
Operating Temperature Range
Supply Voltage
TR
VCC
LT
-40 to +85
+3.3 ± 5.0%
HCSL
°C
V
Logic Type
I
CC/OE
Supply Current, Output Enabled
Supply Current, Output Disabled
Duty Cycle (Symmetry)
70
mA
mA
%
Max.
Max.
I
CC/OD
40
DC/SY
TR/TF
45 / 55
Measured 50% of Waveform
Max. measured from Vol=0.175V to
Voh=0.525V
Rise / Fall Time
700
ps
VOL
VOH
Output Voltage "0" Level
Output Voltage "1" Level
Output Load
-0.150 / 0
V
V
Min. / Typ.
0.66 / 0.70 / 0.90
Min, / Typ. / Max.
Output requires termination
Rs=33Ω, Rp=50Ω,CL=2pF
Typ. / Max., As defined by PCI-SIG for
PCIe Gen 2.0 reference clock
Output Phase Jitter-PCIe Gen2
Output Phase Jitter-PCIe Gen3
2.0 / 3.0
ps RMS
ps RMS
Typ. / Max., As defined by PCI-SIG for
PCIe Gen 3.0 reference clock
0.43 / 1.0
ps
ps
ps
°C
Max. 12KHz ~ 20MHz Frequency Band
Max. 20,000 Consecutive Periods
Max. 100,000 Random Periods
Jitter, Phase
RMS
RMS(1-σ)
Pk-Pk
1
Jitter, Accumulated
Jitter, Peak to Peak
Storage Temperature Range
6
40
-55 to +125
※ This product doesn't include harmful substance that stipulated by SONY SS-00259 Level 1 and S-AT2-001 Level 1 standard. RoHS Compliant (Pb - Free).
**Stability includes all combinations of Operating Temperature, Load changes, rated Input (Supply) Voltage changes, Initial
Calibration Tolerance (25°C), Aging (1 years at 25°C Average Effective Ambient Temperature), Shock and Vibration.
Output Enable / Disable Function
Parameter
Input Voltage (Pin1), Output Enable
Input Voltage (Pin1), Output Disable (low power standby)
Output Disable Delay
Min.
Typ.
Max.
Notes
Units
V
0.7VCC
Or Open
Output is Hi-Z
0.3VCC
100
V
ns
Output Enable Delay
100
ns
Start Up Time
10
ms
E0-R-4-014 Rev. E
Page 1
