40Gbit/s QSFP Transceiver
Product Brief
4 Channel Parallel QSFP Transceiver
PXD40GVP2130
Features:
• Small form-factor, hot pluggable QSFP module
• Compliant with SFF-8436
• Independent transmitter (Tx) and receiver (Rx)
sections, each with four fibers in parallel
• Support of various communication standards (see
below)
• Maximum aggregate data rate: 45.2 Gbit/s (4 x 11.3
Gbit/s)
• Maximum throughput: 90.4 Gbit/s (Tx and Rx)
• Low power consumption: 1.3 W (typ.)
• I2C based two-wire serial interface for easy control
and monitoring (management interface acc. SFF-8436)
• MergeOptics Parallel Optics Engine
• Support of MPO based multimode fiber interconnects
• Transmission distance up to 150m OM3 MMF
• Laser class 1M IEC / CDRH product
• RoHS 6/6 compliant
Applications:
• 4x QDR InfiniBand data transmission.
• 40G or 4x10G Ethernet data transmission
• 8.5 Gbit/s & 10.52 Gbit/s per channel Fibre Channel data transmission of up to 4 channels.
Supported Standards:
• SFF-8436 (SFF Committee QSFP document)
• QDR 10G InfiniBand
• IEEE P802.3ba (Ethernet)
• 8GFC & 10GFC (Fibre Channel)
Product Brief
13.08.2009
Revision: A02
Page: 1 / 2
