1T1 THRU 1T7
1.0 AMP. Silicon Rectifiers
Voltage Range
50 to 1000 Volts
Current
1.0 Ampere
TS-1
Features
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
Low forward voltage drop
High current capability
High reliability
High surge current capability
3mm miniature body
Mechanical Data
ꢀ
ꢀ
ꢀ
Cases: Molded plastic
Epoxy: UL 94V-0 rate flame retardant
Lead: Axial leads, solderable per
MIL-STD-202, Method 208 guaranteed
Polarity: Color band denotes cathode end
High temperature soldering guaranteed:
260℃/10 seconds/.375”,(9.5mm) lead
lengths at 5 lbs.,(2.3kg) tension
Weight: 0.20 gram
ꢀ
ꢀ
ꢀ
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Rating at 25℃ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Symbol
VRRM
VRMS
VDC
Type Number
Maximum Recurrent Peak Reverse Voltage
1T1 1T2 1T3 1T4 1T5 1T6 1T7 Units
50
35
50
100 200 400 600 800 1000
V
V
V
Maximum RMS Voltage
70 140 280 420 560 700
Maximum DC Blocking Voltage
100 200 400 600 800 1000
1.0
Maximum Average Forward Rectified
Current .375”(9.5mm) Lead Length
@TA = 50℃
A
I(AV)
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated
Load (JEDEC method )
Maximum Instantaneous Forward Voltage
@1.0A
Maximum DC Reverse Current @ TA=25℃
at Rated DC Blocking Voltage @ TA=100℃
30
A
V
IFSM
1.0
VF
IR
5.0
50
uA
uA
Maximum Full Load Reverse Current ,Full
CycleAverage .375”(9.5mm) Lead Length
@TA=50℃
HTIR
30
uA
Typical Junction Capacitance ( Note 1 )
Typical Thermal Resistance ( Note 2 )
Operating Temperature Range
Cj
RθJA
TJ
15
50
pF
℃/W
℃
-65 to +150
-65 to +150
℃
Storage Temperature Range
TSTG
Notes:1. Measured at 1 MHz and Applied Reverse Voltage of 4.0 Volts D.C.
2. Mount on Cu-pad size 5mm x 5mm on P.C.B.
- 506 -
