1. Precautions

1-1 Safety Precautions

Any measurements not within the limits specified

herein indicate a potential shock hazard that must

be eliminated before returning the instrument to

the customer.

1) Before returning an instrument to the customer,

always make a safety check of the entire instrument,

including, but not limited to, the following items:

(1) Be sure that no built-in protective devices are

defective or have been defeated during servicing.

(1)Protective shields are provided to protect both

the technician and the customer. Correctly replace

all missing protective shields, including any

remove for servicing convenience.

(READING SHOULD

NOT BE ABOVE

0.5mA)

LEAKAGE

DEVICE

UNDER

TEST

CURRENT

TESTER

(2)When reinstalling the chassis and/ or other as-

sembly in the cabinet, be sure to put back in place

all protective devices, including, but not limited to,

nonmetallic control knobs, insulating fish papers,

adjustment and compartment covers/ shields, and

isolation resistor/ capacitor networks. Do not oper-

ate this instrument or permit it to be operated with-

out all protective devices correctly installed and

functioning.

TEST ALL

EXPOSED METER

SURFACES

2-WIRE CORD

ALSO TEST WITH

PLUG REVERSED

(USING AC ADAPTER

PLUG AS REQUIRED)

EARTH

GROUND

Fig. 1-1 AC Leakage Test

(4) Insulation Resistance Test Cold Check-(1) Unplug

the power supply cord and connect a jumper wire

between the two prongs of the plug. (2) Turn on the

power switch of the instrument. (3) Measure the

resistance with an ohmmeter between the

jumpered AC plug and all exposed metallic cabinet

parts on the instrument, such as screwheads,

antenna, control shafts, handle brackets, etc. When

an exposed metallic part has a return path to the

chassis, the reading should be between 1 and 5.2

megohm. When there is no return path to the chas-

sis, the reading must be infinite. If the reading is

not within the limits specified, there is the possibil-

ity of a shock hazard, and the instrument must be

re-pared and rechecked before it is returned to the

customer. See Fig. 1-2.

(2) Be sure that there are no cabinet openings through

which adults or children might be able to insert

their fingers and contact a hazardous voltage. Such

openings include, but are not limited to, excessive-

ly wide cabinet ventilation slots, and an improper-

ly fitted and/ or incorrectly secured cabinet back

cover.

(3) Leakage Current Hot Check-With the instrument

completely reassembled, plug the AC line cord

directly into a 120V AC outlet. (Do not use a isola-

tion transformer during this test.) Use a leakage

current tester or a metering system that complies

with American National Standards institute (ANSI)

C101.1 Leakage Current for Appliances and

Underwriters Laboratories (UL) 1270 (40.7). With

the instrument’s AC switch first in the ON position

and then in the OFF position, measure from a

known earth ground (metal water pipe, conduit,

etc.) to all exposed metal parts of the instrument

(antennas, handle brackets, metal cabinets, screw-

heads, metallic overlays, control shafts, etc.), espe-

cially any exposed metal parts that offer an electri-

cal return path to the chassis.

Antenna

Terminal

Exposed

Melal Part

Any current measured must not exceed 0.5mA.

Reverse the instrument power cord plug in the out-

let and repeat the test. See Fig. 1-1.

ohm

ohmmeter

Fig. 1-2 Insulation Resistance Test

Samsung Electronics

1-1

Precautions

2) Read and comply with all caution and safety re-

lated notes non or inside the cabinet, or on the chas-

sis.

5) Components, parts, and/ or wiring that appear to

have overheated or that are otherwise damaged

should be replaced with components, parts and/ or

wiring that meet original specifications.

3) Design Alteration Warning-Do not alter of add to

the mechanical or electrical design of this instru-

ment. Design alterations and additions, including

but not limited to, circuit modifications and the

addition of items such as auxiliary audio output

connections, might alter the safety characteristics of

this instrument and create a hazard to the user. Any

design alterations or additions will make you, the

service, responsible for personal injury or property

damage resulting therefrom.

Additionally, determine the cause of overheating

and/ or damage and, if necessary, take corrective

action to remove any potential safety hazard.

6) Product Safety Notice-Some electrical and mechani-

cal parts have special safety-related characteristics

which are often not evident from visual inspection,

nor can the protection they give necessarily be

obtained by replacing them with components rated

for higher voltage, wattage, etc. Parts that have spe-

cial safety characteristics are identified by shading,

4) Observe original lead dress. Take extra care to

assure correct lead dress in the following areas:

(1) near sharp edges, (2) near thermally hot parts (be

sure that leads and components do not touch ther-

mally hot parts), (3) the AC supply, (4) high voltage,

and (5) antenna wiring. Always inspect in all areas

for pinched, out-of-place, or frayed wiring, Do not

change spacing between a component and the

printed-circuit board. Check the AC power cord for

damage.

an (

)or a (

)on schematics and parts lists. Use

of a substitute replacement that does not have the

same safety characteristics as the recommended

replacement part might created shock, fire and/ or

other hazards. Product safety is under review con-

tinuously and new instructions are issued whenev-

er appropriate.

1-2

Samsung Electronics

Precautions

1-2 Servicing Precautions

(4) An insulation tube or tape is sometimes used and

some components are raised above the printed

wiring board for safety. The internal wiring is

sometimes clamped to prevent contact with heat-

ing components. Install such elements as they

were.

CAUTION : Before servicing Instruments covered

by this service manual and its supplements, read and

follow the Safety Precautions section of this manual.

Note : If unforseen circument create conflict between

the following servicing precautions and any of the

safety precautions, always follow the safety precau-

tions. Remember: Safety First.

(5) After servicing, always check that the removed

screws, components, and wiring have been in-

stalled correctly and that the portion around the

serviced part has not been damaged and so on.

Further, check the insulation between the blades of

the attachment plug and accessible conductive

parts.

1-2-1 General Servicing Precautions

(1) a. Always unplug the instrument’s AC power cord

from the AC power source before (1) re-moving

or reinstalling any component, circuit board,

module or any other instrument assembly, (2)

disconnecting any instrument electrical plug or

other electrical connection, (3) connecting a test

substitute in parallel with an electrolytic capaci-

tor in the instrument.

1-2-2 Insulation Checking Procedure

Disconnect the attachment plug from the AC outlet

and turn the power ON. Connect the insulation resi-

stance meter (500V) to the blades of the attachment

plug. The insulation resistance between each blade of

the attachment plug and accessible conductive

parts(see note) should be more than 1 Megohm.

b. Do not defeat any plug/ socket B+ voltage inter-

locks with which instruments covered by this

service manual might be equipped.

c. Do not apply AC power to this instrument and

/ or any of its electrical assemblies unless all

solid-state device heat sinks are correctly in-

stalled.

Note : Accessible conductive parts include metal pan-

els, input terminals, earphone jacks, etc.

d. Always connect a test instrument’s ground lead

to the instrument chassis ground before connect-

ing the test instrument positive lead. Always

remove the test instrument ground lead last.

Note : Refer to the Safety Precautions section ground

lead last.

(2) The service precautions are indicated or printed on

the cabinet, chassis or components. When servic-

ing, follow the printed or indicated service precau-

tions and service materials.

(3) The components used in the unit have a specified

flame resistance and dielectric strength.

When replacing components, use components

which have the same ratings. Components i-enti-

fied by shading, by( ) or by ( ) in the circuit dia-

gram are important for safety or for the characteris-

tics of the unit. Always replace them with the exact

replacement components.

Samsung Electronics

1-3

Precautions

1-3 ESD Precautions

(7) Immediately before removing the protective ma-

terials from the leads of a replacement ESD device,

touch the protective material to the chassis or cir-

cuit assembly into which the device will be

installed.

Electrostatically Sensitive Devices (ESD)

Some semiconductor (solid state) devices can be dam-

aged easily by static electricity.

Such components commonly are called Electrostati-

cally Sensitive Devices(ESD). Examples of typical ESD

devices are integrated circuits and some field-effect

transistors and semiconductor chip components. The

following techniques should be used to help reduce

the incidence of component damage caused by static

electricity.

CAUTION : Be sure no power is applied to the ch-

assis or circuit, and observe all other safety precau-

tions.

(8) Minimize bodily motions when handling unpack-

aged replacement ESD devices. (Otherwise harm-

less motion such as the brushing together of your

clothes fabric or the lifting of your foot from a car-

peted floor can generate static electricity sufficient

to damage an ESD device).

(1) Immediately before handling any semiconductor

component or semiconductor-equipped assembly,

drain off any electrostatic charge on your body by

touching a known earth ground. Alternatively,

obtain and wear a commercially available dis-

charging wrist strap device, which should be

removed for potential shock reasons prior to apply-

ing power to the unit under test.

(2) After removing an electrical assembly equipped

with ESD devices, place the assembly on a conduc-

tive surface such as aluminum foil, to prevent elec-

trostatic charge buildup or exposure of the assem-

bly.

(3) Use only a grounded-tip soldering iron to solder or

unsolder ESD devices.

(4) Use only an anti-static solder removal devices.

Some solder removal devices not classified as

“anti-static” can generate electrical charges suffi-

cient to damage ESD devices.

(5) Do not use freon-propelled chemicals. These can

generate electrical charges sufficient to damage

ESD devices.

(6) Do not remove a replacement ESD device from its

protective package until immediately before your

are ready to install it.(Most replacement ESD

devices are packaged with leads electrically short-

ed together by conductive foam, aluminum foil or

comparable conductive materials).

1-4

Samsung Electronics

Precautions

1-4 Handling the optical pick-up

The laser diode in the optical pick up may suffer elec-

trostatic breakdown because of potential static elec-

tricity from clothing and your body.

WRIST-STRAP

FOR GROUNDING

1M

The following method is recommended.

THE UNIT

(1) Place a conductive sheet on the work bench (The

black sheet used for wrapping repair parts.)

CONDUCTIVE SHEET

1M

(2) Place the set on the conductive sheet so that the

chassis is grounded to the sheet.

Fig.1-3

(6) Short the short terminal on the PCB, which is in-

side the Pick-Up ASS’Y, before replacing the Pick-

Up. (The short terminal is shorted when the Pick-

Up Ass’y is being lifted or moved.)

(3) Place your hands on the conductive sheet(This

gives them the same ground as the sheet.)

(4) Remove the optical pick up block

(7) After replacing the Pick-up, open the short termi-

nal on the PCB.

(5) Perform work on top of the conductive sheet. Be

careful not to let your clothes or any other static

sources to touch the unit.

◆ Be sure to put on a wrist strap grounded to the

sheet.

◆ Be sure to lay a conductive sheet made of copper

etc. Which is grounded to the table.

Samsung Electronics

1-5

Precautions

1-5 Pick-up disassembly and reassembly

1-5-2 Assembly

1-5-1 Disassembly

1) Replace the Pick-up.

2) Remove the soldering 2 points on Pick-up.

3) Reassemble the Deck-Assy.

1) Remove the power cord.

2) Disassemble the Deck-Assy.

3) Make solder land 2 points short on Pick-up.

(See Fig. 1-4)

4) Disassembly the Pick-up.

Note : If the assembly and disassembly are not done in correct sequence, the Pick-up may be damaged.

SOLDER LAND 2 POINTS SHORT

PICK-UP ASS'Y

Fig. 1-4

1-6

Samsung Electronics

2. Alignment and Adjustment

2-1 Location of Test Point

SKEW

Fig. 2-1 Location of Test Point

Samsung Electronics

2-1

Alignment and Adjustment

2-2 Skew Adjustment

2-2-1 Adjustment Spec. and Test Point

◆ Test Disc ; Service not Available

Test Disc

Adjustment Spec.

Test Point

Adjustment Location

TDV-533

Chapter 14

“ENV”

Screw A / B

Ass’y Deck - Bottom Side

Flat Waveform

(Main PCB - Component Side)

(See Fig. 2-1)

(See Fig. 2-2)

Fig. 2-2 Ass’y Deck (Top Side)

2-2

Samsung Electronics

Alignment and Adjustment

2-2-2 SKEW Adjustment Method

Needed to minimize the variations in Skew of the Pickup unit and to provide optimum match with the recorded

signal on the Disc.

1) Connect an Oscilloscope to the “ENV” Test Point (See Fig. 2-1).

2) Connect Power, Open the Tray and Play the TDV-533 Disc, Chapter 14.

◆ Set the Oscilloscope Range as follows :

(Voltage ; 50mV/ Div., Frequency ; 10m Sec.)

3) Adjust the Screws “A” and “B” (See Fig. 2-2) using a Hex screwdirvier until you obtain a Flat Waveform and

the picture is stable.

Then, go to Chapter 1 and make sure the Waveform is Flat here as well.

If not, you have to go back to Chapter 14 and adjust again.

If you cannot obtain a Flat waveform, then the unit is defective.

Note : The Deck must be in a horizontal position. Use both “A” and “B” screws to adjust.

Typical Waveform before Adjustment

Waveform after Correct Adjustment

Fig. 2-3 Envelope Waveform

Samsung Electronics

2-3

Alignment and Adjustment

MEMO

2-4

Samsung Electronics

3. Exploded View and Parts List

Page

3-1 Cabinet Assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-2

3-2 Deck Assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-4

Notice

You can search for the updated part code through ITSELF web site.

URL; http://itself.sec.samsung.co.kr

3-1

Samsung Electronics

Exploded Views and Parts List

3-1 Cabinet Assembly

151

152

150

101

DECK-DVD MECHA (S.N.A.)

152

151

601 (ASSY-PCB-MAIN)

610

CN1B

152

602 (ASS'Y-PCB-JACK)

S.N.A. (ASS'Y CABINET-BOTTOM)

S.N.A. : Service Not Available

DVD-P230

DVD-P331

UT01

151

701

3

1

4

2

3-2

Samsung Electronics

Exploded Views and Parts List

Loc. No

Parts No.

Description ; Specification

Remark

1

Refer to table below

AH64-01320G

ASSY FRONT CABINET;ASSY,DVD-P231,XAA

DOOR-TRAY;DVD-P231,ABS 94HB,-,12,-,-,GRA

KNOB-VOLUME;DVD-P331,ABS 94HB,-,-,-,-,A7

BUTTON-NAVIGATION;DVD-P331,ABS 94HB,-,-,

CABINET-TOP;EXINO,PCM T0.65,-,-,-,-,GRAY

SCREW-TAPTITE;BH,+,B,M3,L10,BLK ,SWCH101

SCREW-TAPTITE;BH,+,B,M3,L10,ZPC(YEL),SWC

SCREW-TAPTITE;BH,+,B,M3,L8,ZPC(BLK),SWCH

ASSY PCB-MAIN;DVD-P331/XAA,MAIN PCB ASS’

ASSY PCB-JACK;DVD-P331/XAA,EXINO JACK PC

CBF POWER CORD;EP2,SPT-2,AWG#18,1.8MT,WA

ASSY PCB-KEY;DVD-P392,KEY PCB ASS’Y

2

3

Only for DVD-P331

4

AK64-00135C

101

150

151

152

601

602

610

701

CN1B

UT01

Refer to table below

6003-000275

6003-000276

6003-000282

Refer to table below

AC39-10200N

AK92-00148A

Only for DVD-P331

3809-001180

CABLE-FLAT;30V,-30to+80C,80mm,35P,1.25mm

REMOCON-ASS’Y;DVD-P331/XAA,XAA,-,-,-,-,-

Refer to table below

Models

DVD-P230

DVD-P331

1

2

101

601

602

UT01

AK97-00300C

AK97-00328A

AK97-00301C

AK64-00088D

AK64-00101A

AK64-00101C

AK92-00151A

AK92-00149A

AK92-00130A

AK92-00150A

AH59-00092S

AH59-00092T

3-3

Samsung Electronics

Exploded Views and Parts List

3-2 Deck Assembly

H107

H105

H106

H103

H102

S.N.A.

H108

H104

H206

H241

H211

900

904

H206

H203

H207

900

H202

903

H205

H204

903

H210

H209

3-4

Samsung Electronics

Exploded Views and Parts List

Loc. No

Parts No.

Description ; Specification

Remark

900

6003-001157

6001-001370

6002-001086

AH66-00111B

AK66-00007A

AK31-00003A

6602-001076

AK66-00008A

AK66-00009A

AK63-00008A

AK73-00005A

AH61-50327A

AK66-00010A

AK66-00011A

AK61-00032A

AK31-00004A

AK64-00052A

AK31-00005A

AK97-00166B

3809-001409

SCREW-TAPTITE;PWH,+,B,M2,L6,ZPC(YEL),SWR

SCREW-MACHINE;CH,+,M1.7,L3.0,ZPC(YEL),SW

SCREW-TAPPING;PH,+,B,M1.7,L5.0,ZPC(YEL),

CLAMPER-ASSY;DP-5,POM+MAGNET,-,-,-,-,-,-

PULLEY-GEAR;DP-9,POM ,-,-,-,-,-,-

903

904

H102

H103

H104

H105

H106

H107

H108

H202

H203

H204

H205

H206

H207

H209

H210

H211

H241

MOTOR-LOAD ASSY;SM-2412L2,DP-9,-,-,-,-,-

BELT-RECTANGULAR;CR,T1.2,4.3%,1.2X25.1,B

GEAR-TRAY;DP-9,POM,-,-,-,-,-,-,-

SLIDER-HOUSING;DP-9,POM,-,-,-,-,-

TRAY-DISC;DP-9,ABS,-,-,-,-,BLK,DP-9

RUBBER-INSULATOR;DP-9,BUTYL RUBBER,-,-,-

SHAFT-P/U;DP-3,SUS420J2,L84.7,OD3,-,-,-

GEAR-FEED A;DP-9,POM ,-,-,-,-,-,-,-

GEAR-FEED B;DP-9,POM ,-,-,-,-,-,-,-

HOLDER-CAM SKEW;DP-9,POM,-,-,-,BLACK,-

MOTOR SPINDLE;RSM-2606A1,DP-9,350MA,-,-,

CHASSIS-SUB;DP-9,ABS(SR-0320),0,0,0,-,-

MOTOR-FEED ASSY;-,DP-9,-,-,-,-,-,-,-,-,-

ASSY-PICK UP;-,SOH-DSSA, T544C,SEM,W/T

CABLE-FLAT;30V,80C,230MM,24P,1MM,UL2896

3-5

Samsung Electronics

Exploded Views and Parts List

MEMO

3-6

Samsung Electronics

4. Electrical Parts List

Loc.No

Part No

Description ; Specification

Remark

Loc.No

Part No

Description ; Specification

Remark

601

AK92-00151A

AK92-00149A

3708-001364

2203-005148

3708-001696

3708-001695

3711-001018

0407-000116

0501-000341

2007-000090

2007-000075

2007-000090

2007-000075

2007-000116

2203-005148

2203-001222

2203-005148

2203-000140

3708-001165

2401-002144

2401-000414

2007-000084

2007-000090

2007-000124

2007-000090

2007-000655

2007-000090

2007-000088

2007-000092

2007-000084

2007-000034

2007-000093

2007-000090

2007-000093

2007-000090

2007-000092

2007-000075

3404-001235

3404-001164

2203-000257

ASSY PCB-MAIN;DVD-E231/XAA,P331 MAIN PCB

ASSY PCB-MAIN;DVD-P331/XAA,MAIN PCB ASS’

CONNECTOR-FPC/FFC/PIC;35P,1.25MM,STRAIGH

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

CONNECTOR-FPC/FFC/PIC;24P,1MM,STRAIGHT,S

CONNECTOR-FPC/FFC/PIC;13P,1MM,STRAIGHT,S

CONNECTOR-HEADER;BOX,5P,1R,2mm,STRAIGHT,

DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOT-

TR-SMALL SIGNAL;KSC1623-L,NPN,200mW,SOT-

R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

R-CHIP;220ohm,5%,1/16W,DA,TP,1608

R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

R-CHIP;220ohm,5%,1/16W,DA,TP,1608

R-CHIP;120ohm,5%,1/16W,DA,TP,1608

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;820pF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608

CONNECTOR-FPC/FFC/PIC;6P,1.25mm,STRAIGHT

C-AL;47uF,20%,16V,GP,TP,5x11,5

DVD-P230

DVD-P331

PC10

PC11

PC12

PC3

PC4

PC5

PC6

PC7

PC8

PCN1

PE1

PE10

PE3

PE4

PE5

PE6

PE8

PE9

PIC1

PIC2

PL1

2203-000257

2203-005148

3711-001062

2401-002165

1203-002178

1203-002779

2703-000398

2007-000033

2703-000398

2007-000070

2007-000078

2007-000080

2007-000078

2007-000080

2007-001056

2203-005148

2203-000975

2203-005148

2203-000975

2203-000257

2203-000560

2203-000236

2203-000560

2203-000140

2203-005148

2203-000236

2203-000140

2203-005148

2203-000560

2203-000715

2203-000140

2203-000236

2203-000140

2203-005148

2401-000913

C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

CONNECTOR-HEADER;BOX,6P,1R,2mm,STRAIGHT,

C-AL;100uF,20%,16V,GP,TP,6.3x7,5

IC-VOLTAGE REGULATOR;1563,SOP,7P,173MIL,

IC-VOLTAGE REGULATOR;G952T63U,SOT-223,3P

INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm

R-CHIP;0OHM,5%,1/8W,DA,TP,3216

INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;1Kohm,5%,1/16W,DA,TP,1608

R-CHIP;2Kohm,5%,1/16W,DA,TP,1608

R-CHIP;1Kohm,5%,1/16W,DA,TP,1608

R-CHIP;2Kohm,5%,1/16W,DA,TP,1608

R-CHIP;6.2Kohm,5%,1/16W,DA,TP,1608

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,

C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608

C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608

C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608

C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-AL;22uF,20%,16V,GP,TP,5x11,5

CN8

DC1

DC2

DCN1

DCN2

DCN3

DD1

DQ1

DQ2

DQ3

DR1

DR2

DR3

DR4

DR5

DR6

DR7

DR8

FC1

FC10

FC11

FC12

FC13

FC15

FC2

FC3

FC4

FC5

FC6

FC7

FCN1

FE1

FE2

FE3

FE4

FE5

FE6

FR1

FR10

FR11

FR12

FR13

FR14

FR15

FR16

FR17

FR18

FR2

PL2

PL3

PR1

R1

R2

R3

R4

R5

RC1

RC11

RC12

RC13

RC14

RC15

RC16

RC17

RC18

RC19

RC2

RC21

RC22

RC23

RC24

RC25

RC27

RC28

RC29

RC3

RC31

RC32

RC33

RC34

RC35

RC4

RC5

RC6

RC7

RC8

RC9

RE1

DVD-P331 ONLY

C-AL;47uF,20%,16V,GP,TP,5x11,5

C-AL;10uF,20%,16V,GP,TP,4x7,5

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608

R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

R-CHIP;27Kohm,5%,1/16W,DA,TP,1608

R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

R-CHIP;7.5Kohm,5%,1/16W,DA,TP,1608

R-CHIP;15Kohm,5%,1/16W,DA,TP,1608

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

R-CHIP;1OHM,5%,1/4W,DA,TP,3216

FR3

FR4

FR5

FR6

FR7

FR8

FR9

JB1

R-CHIP;1OHM,5%,1/4W,DA,TP,3216

R-CHIP;20Kohm,5%,1/16W,DA,TP,1608

R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

R-CHIP;20Kohm,5%,1/16W,DA,TP,1608

R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

R-CHIP;15Kohm,5%,1/16W,DA,TP,1608

R-CHIP;220ohm,5%,1/16W,DA,TP,1608

SWITCH-TACT;12V DC,50MA,100GF,62.6X10.8,

SWITCH-TACT;12V DC,50MA,100GF,7X7X6.7MM,

C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608

FSW2

FSW8

PC1

DVD-P230 ONLY

4-1

Samsung Electronics

Electrical Parts List

Loc.No

Part No

Description ; Specification

Remark

Loc.No

Part No

Description ; Specification

Remark

RE10

RE2

RE3

RE4

RE5

RE6

RE7

RE8

RE9

RIC1

RL11

RL3

RQ1

RQ2

RR11

RR12

RR15

RR16

RR17

RR18

RR19

RR2

RR21

RR22

RR23

RR24

RR25

RR26

RR28

RR29

RR3

2401-002165

2401-000414

2401-000913

2401-000414

AH13-00009B

2703-000398

0501-000279

2007-000078

2007-000312

2007-000102

2007-000090

2007-000078

2007-000091

2007-000655

2007-001235

2007-000134

2007-000070

2007-000102

2007-000381

2007-000091

2007-000102

2007-000091

2007-000077

2007-000312

2203-005148

2203-000560

2203-001634

2203-000491

2203-005148

2203-000257

2203-001652

2203-005148

2203-000681

2203-005148

2203-000815

2203-002398

2203-000626

2203-000815

2203-000257

2203-000626

2203-000257

2203-005148

2203-001652

2203-000560

2203-000140

2203-001634

2203-000715

2203-001126

C-AL;100uF,20%,16V,GP,TP,6.3x7,5

C-AL;10uF,20%,16V,GP,TP,4x7,5

C-AL;22uF,20%,16V,GP,TP,5x11,5

C-AL;10uF,20%,16V,GP,TP,4x7,5

SC46

SC47

SC48

SC5

SC50

SC51

SC53

SC6

SC7

SC8

SC9

SE1

SIC1

SIC2

SIC3

SL1

SL2

SL3

2203-000975

2203-000140

2203-000815

2203-002398

2203-000140

2203-001630

2203-000426

2203-005148

2203-000257

2203-000491

2401-000414

AH13-00006B

1105-001355

1003-001489

3301-000314

3301-001419

2007-001235

2007-000124

2007-000092

2007-000091

2007-000655

2007-000090

2007-000078

2007-000090

2007-000093

2007-000078

2007-000109

2007-000070

2007-000074

2007-000092

2007-000078

2007-000070

3301-001419

2007-000070

2007-000074

2007-000116

2007-000070

2007-000643

2007-000078

2007-000070

2007-000084

2007-000102

2007-001164

2007-000070

2007-000116

2007-000091

2007-000643

2007-000075

2007-000113

2007-000074

2007-000070

2007-000091

2007-000124

2801-000261

2007-000033

2203-005148

C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,

C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;330nF,+80-20%,16V,Y5V,TP,

C-CERAMIC,CHIP;0.018NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608

C-AL;10uF,20%,16V,GP,TP,4x7,5

IC ASIC;S5L1455X01,DVD-P293,160,+3.3V,

IC-DRAM;416256,256KX16BIT,TSOP(II),40P

IC-MOTOR DRIVER;FAN8728,HQFP,48P,14X14MM

CORE-FERRITE BEAD;AB,120ohm,1.6x0.8x0.8m

CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m

R-CHIP;910Kohm,5%,1/16W,DA,TP,1608

R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608

R-CHIP;15Kohm,5%,1/16W,DA,TP,1608

R-CHIP;12Kohm,5%,1/16W,DA,TP,1608

R-CHIP;27Kohm,5%,1/16W,DA,TP,1608

R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

R-CHIP;1Kohm,5%,1/16W,DA,TP,1608

R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

R-CHIP;20Kohm,5%,1/16W,DA,TP,1608

R-CHIP;1Kohm,5%,1/16W,DA,TP,1608

R-CHIP;1Mohm,5%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;100ohm,5%,1/16W,DA,TP,1608

R-CHIP;15Kohm,5%,1/16W,DA,TP,1608

R-CHIP;1Kohm,5%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;100ohm,5%,1/16W,DA,TP,1608

R-CHIP;120ohm,5%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;270ohm,5%,1/16W,DA,TP,1608

R-CHIP;1Kohm,5%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

R-CHIP;100Kohm,5%,1/16W,DA,TP,1608

R-CHIP;75ohm,1%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;120ohm,5%,1/16W,DA,TP,1608

R-CHIP;12Kohm,5%,1/16W,DA,TP,1608

R-CHIP;270ohm,5%,1/16W,DA,TP,1608

R-CHIP;220ohm,5%,1/16W,DA,TP,1608

R-CHIP;33ohm,5%,1/16W,DA,TP,1608

R-CHIP;100ohm,5%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

C-AL;10uF,20%,16V,GP,TP,4x7,5

IC ASIC;S5L1463A01,DVD-P293,80,+5V,-40

INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm

TR-SMALL SIGNAL;KSA1182-Y,PNP,150mW,SOT-

R-CHIP;1Kohm,5%,1/16W,DA,TP,1608

R-CHIP;10OHM,5%,1/8W,DA,TP,3216

R-CHIP;100Kohm,5%,1/16W,DA,TP,1608

R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

R-CHIP;1Kohm,5%,1/16W,DA,TP,1608

R-CHIP;12Kohm,5%,1/16W,DA,TP,1608

R-CHIP;27Kohm,5%,1/16W,DA,TP,1608

R-CHIP;910Kohm,5%,1/16W,DA,TP,1608

R-CHIP;33Kohm,5%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;100Kohm,5%,1/16W,DA,TP,1608

R-CHIP;13Kohm,5%,1/16W,DA,TP,1608

R-CHIP;12Kohm,5%,1/16W,DA,TP,1608

R-CHIP;100Kohm,5%,1/16W,DA,TP,1608

R-CHIP;12Kohm,5%,1/16W,DA,TP,1608

R-CHIP;470ohm,5%,1/16W,DA,TP,1608

R-CHIP;10OHM,5%,1/8W,DA,TP,3216

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608,

C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;0.027NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;0.022NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;0.022NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,

C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,

C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608,

C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;0.68nF,10%,50V,X7R,TP,160

SR1

SR11

SR13

SR14

SR15

SR16

SR17

SR18

SR19

SR2

SR21

SR22

SR23

SR24

SR26

SR27

SR28

SR29

SR3

SR31

SR32

SR33

SR34

SR35

SR36

SR39

SR4

SR41

SR42

SR43

SR44

SR45

SR46

SR48

SR49

SR5

RR31

RR4

RR5

RR8

RR9

SC1

SC11

SC13

SC14

SC15

SC16

SC17

SC18

SC2

SC23

SC24

SC25

SC26

SC27

SC28

SC29

SC3

SC31

SC32

SC33

SC34

SC35

SC36

SC38

SC4

SC41

SC42

SC43

SC44

SC45

SR50

SR52

SR53

SR54

SR6

SR7

SR8

SR9

SY1

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;12Kohm,5%,1/16W,DA,TP,1608

R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608

CRYSTAL-UNIT;33.8688MHz,50ppm,28-AAA,12p

R-CHIP;0OHM,5%,1/8W,DA,TP,3216

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

W1

ZC1

ZC10

Samsung Electronics

4-2

Electrical Parts List

Loc.No

Part No

Description ; Specification

Remark

Loc.No

Part No

Description ; Specification

Remark

ZC101

ZC102

ZC103

ZC104

ZC105

ZC106

ZC107

ZC108

ZC11

ZC110

ZC112

ZC113

ZC12

ZC13

ZC14

ZC15

ZC16

ZC17

ZC18

ZC19

ZC2

ZC20

ZC21

ZC22

ZC23

ZC24

ZC25

ZC27

ZC28

ZC29

ZC3

ZC30

ZC31

ZC32

ZC33

ZC34

ZC35

ZC36

ZC37

ZC38

ZC39

ZC4

ZC40

ZC41

ZC42

ZC44

ZC5

2203-005148

2203-000426

2203-005148

2203-000257

2203-005148

2203-000815

2203-005148

2203-000815

2203-005148

2203-000681

2203-005148

2203-000815

2203-000426

2203-005148

2203-000681

2203-005148

2401-002144

1204-002067

1105-001305

1107-001369

1103-001204

0801-002701

3301-001419

2703-000398

3301-001419

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;0.018NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;0.027NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;0.018NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-CERAMIC,CHIP;0.027NF,5%,50V,C0G,TP,160

C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608

C-AL;47uF,20%,16V,GP,TP,5x11,5

ZL9

ZR1

3301-001419

2007-000360

2007-000084

2007-001101

2007-000084

2011-000816

2007-000074

2007-001164

2007-000360

2007-001164

2007-000113

2007-000070

2007-000084

2007-000118

2007-000084

2007-000074

2007-000084

2007-000078

2007-000074

2007-000090

3301-001309

2007-000074

2007-000078

2007-000084

2007-000070

2007-000074

2007-000070

2007-000084

2007-000074

2007-000084

2007-001164

2007-000070

2007-000113

2007-000070

2007-000074

2007-000084

2801-003554

CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m

R-CHIP;12ohm,1%,1/16W,DA,TP,1608

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

R-CHIP;62ohm,5%,1/16W,DA,TP,1608

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

R-NETWORK;100ohm,5%,63mW,L,CHIP,8P,TP

R-CHIP;100ohm,5%,1/16W,DA,TP,1608

R-CHIP;75ohm,1%,1/16W,DA,TP,1608

R-CHIP;12ohm,1%,1/16W,DA,TP,1608

R-CHIP;75ohm,1%,1/16W,DA,TP,1608

R-CHIP;33ohm,5%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

R-CHIP;390ohm,5%,1/16W,DA,TP,1608

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

R-CHIP;100ohm,5%,1/16W,DA,TP,1608

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

R-CHIP;1Kohm,5%,1/16W,DA,TP,1608

R-CHIP;100ohm,5%,1/16W,DA,TP,1608

R-CHIP;10KOHM,5%,1/16W,DA,TP,1608

CORE-FERRITE BEAD;AB,47ohm,1.6x0.8x0.8mm

R-CHIP;100ohm,5%,1/16W,DA,TP,1608

R-CHIP;1Kohm,5%,1/16W,DA,TP,1608

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;100ohm,5%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

R-CHIP;100ohm,5%,1/16W,DA,TP,1608

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

R-CHIP;75ohm,1%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;33ohm,5%,1/16W,DA,TP,1608

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

R-CHIP;100ohm,5%,1/16W,DA,TP,1608

R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608

CRYSTAL-UNIT;27MHz,10ppm,28-AAM,12pF,40o

ZR10

ZR101

ZR11

ZR12

ZR13

ZR14

ZR15

ZR16

ZR17

ZR18

ZR19

ZR2

ZR20

ZR21

ZR22

ZR23

ZR24

ZR25

ZR26

ZR27

ZR28

ZR29

ZR3

ZR30

ZR31

ZR32

ZR33

ZR34

ZR35

ZR36

ZR37

ZR38

ZR39

ZR4

ZR40

ZR41

ZR42

ZR43

ZR44

ZR45

ZR46

ZR48

ZR5

ZR56

ZR57

ZR6

ZC6

ZC7

ZC9

ZE1

ZE2

ZE3

ZE4

ZIC1

ZIC2

ZIC3

ZIC7

ZIC8

ZL10

ZL2

ZL3

ZL5

ZL6

ZL7

ZR60

ZR62

ZR63

ZR64

ZR66

ZR67

ZR69

ZR7

C-AL;47uF,20%,16V,GP,TP,5x11,5

IC-DECODER;ZR36748,QFP,208P,28X28MM,PLAS

IC-DRAM;4S641632,1Mx16x4Bit,TSOP,54P,4

IC-FLASH MEMORY;MBM29LV800BA-90PFTN,512K

IC-EEPROM;24C021,256x8Bit,SOP,8P,150MIL,

IC-CMOS LOGIC;74VHCT125A,BUFFER,TSSOP,14

CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m

INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm

CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m

ZY1

ZL8

4-3

Samsung Electronics

Electrical Parts List

Loc.No

Part No

Description ; Specification

Remark

Loc.No

Part No

Description ; Specification

Remark

602

AK92-00130A

AK92-00150A

2203-000192

2202-002037

2203-000260

2202-000797

2203-000495

2203-000839

2203-000495

2203-000839

2203-000192

2203-000126

2203-000316

2203-000192

0407-000114

0403-001158

2401-000414

2401-000598

2401-000922

2401-002165

2401-000922

2401-002144

2401-000414

2401-000302

2401-000913

AH14-10004R

1002-001294

2701-000114

3301-001461

2901-001125

3301-001419

2701-000114

1201-000163

0501-000398

0504-000128

0504-000156

0504-000128

0504-000156

0501-000303

0504-000128

0504-000156

2001-000003

2001-000969

2001-000515

2007-000300

2001-000515

2001-000429

2007-000300

2007-000572

2001-000515

2001-000290

2001-000429

2007-001009

ASSY PCB-JACK;DVD-E231/XAA,EXINO JACK PC

ASSY PCB-JACK;DVD-P331/XAA,EXINO JACK PC

C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,

C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V

C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012

C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,

C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,2012

C-CERAMIC,CHIP;0.39NF,5%,50V,C0G,TP,2012

C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,2012

C-CERAMIC,CHIP;0.39NF,5%,50V,C0G,TP,2012

C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,

C-CERAMIC,CHIP;1.2nF,10%,50V,X7R,TP,2012

C-CERAMIC,CHIP;0.12NF,5%,50V,C0G,TP,2012

C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,

DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT-

DIODE-ZENER;MTZJ18C,18,500mW,DO-34,TP

C-AL;10uF,20%,16V,GP,TP,4x7,5

C-AL;1uF,20%,50V,GP,TP,4x7,5

C-AL;22uF,20%,16V,GP,TP,5x5,5

C-AL;100uF,20%,16V,GP,TP,6.3x7,5

C-AL;22uF,20%,16V,GP,TP,5x5,5

C-AL;47uF,20%,16V,GP,TP,5x11,5

C-AL;10uF,20%,16V,GP,TP,4x7,5

C-AL;100uF,20%,25V,GP,TP,6.3x11,5

C-AL;22uF,20%,16V,GP,TP,5x11,5

DVD-P230

DVD-P331

AR405

AR406

AR407

AR408

AR409

AR410

AR411

AR412

AR5

AR51

AR54

AR55

AR56

AVJ1

AVJ2

AVJ4

AVJ5

CN1

FC23

FC24

FC25

FC27

FC28

FC7

FD7

FD9

FE10

FE7

FE8

2001-000977

2007-001009

2007-000409

2007-000221

2001-000290

2001-000429

2001-000273

2001-000780

3722-001469

3722-001467

3722-001516

3707-001052

3708-001364

2203-000595

2203-000192

2202-000173

2203-000260

0401-000101

0403-000551

2401-000922

2401-001507

AH59-00010A

AK09-00012A

1203-001252

2701-000114

0501-000398

2007-000468

2001-000429

2001-000793

2007-000290

2001-000027

2001-000007

2001-000890

2007-000290

2001-000007

2001-000591

2001-000007

2007-000844

2001-000780

2001-000273

2007-000300

2001-000490

2007-000290

2001-000490

2001-000290

2007-000468

2007-000300

2007-000290

2007-000300

R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CHIP;51KOHM,5%,1/10W,DA,TP,2012

R-CHIP;15KOHM,5%,1/10W,DA,TP,2012

R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012

R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM

JACK-PIN;3P/4P,3.2mm,NI,BLK,-

AC201

AC202

AC203

AC204

AC401

AC402

AC403

AC404

AC405

AC406

AC407

AC408

AC409

AC410

AC413

AD1

DVD-P331 ONLY

JACK-PIN;3P,3.2mm,NI,BLK,-

JACK-PIN;1P,3.5mm,NI,BLK,-

CONNECTOR-OPTICAL;PLUG,GP1FA550TZ,6dB,2.

CONNECTOR-FPC/FFC/PIC;35P,1.25MM,STRAIGH

C-CERAMIC,CHIP;0.22NF,5%,50V,C0G,TP,2012

C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,

C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,1

C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012

DIODE-SWITCHING;1N4148,100V,200mA,DO-35,

DIODE-ZENER;MTZ3.9B,3.9V,3.89-4.16V,500m

C-AL;22uF,20%,16V,GP,TP,5x5,5

DVD-P331 ONLY

AD2

AD51

AD54

AD55

AE10

AE201

AE401

AE402

AE403

AE404

AE405

AE406

AE407

AE51

AE52

AE6

AE9

AIC3

AIC4

AL1

AL2

AL201

AL3

AL4

AOP4

AQ1

C-AL;22uF,20%,16V,GP,TP,5x5,5

C-AL;47uF,20%,16V,GP,TP,6.3x5,5

FE9

FEYE

FIC1

FIC7

FL1

MODULE REMOCON;-,-,37.9KHZ,940NM,-,-,-

IC MICOM;GM581C2020,-,64PIN,2.7TO 5.5V,

IC-VOL. DETECTOR;7545,TO-92,3P,-,PLASTIC

INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm

TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T

R-CHIP;1KOHM,5%,1/10W,DA,TP,2012

R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CHIP;100OHM,5%,1/10W,DA,TP,2012

R-CARBON;100OHM,5%,1/4W,AA,TP,2.4X6.4MM

R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CHIP;100OHM,5%,1/10W,DA,TP,2012

R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CHIP;3KOHM,5%,1/10W,DA,TP,2012

FQ29

FQ54

FR07

FR071

FR072

FR1

FR16

FR17

FR19

FR191

FR2

FR20

FR201

FR21

FR22

FR23

FR24

FR25

FR28

FR281

FR29

FR291

FR3

DVD-P331 ONLY

IC;M74HCU04,SOP,TAPE 14P

IC-D/A CONVERTER;PCM1742KE,24BIT,TSSOP,1

INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm

CORE-FERRITE BEAD;AB,300OHM,1.6X0.8X0.8M

FILTER-EMI ON BOARD;50V,0.5A,-,220pF,7x2

CORE-FERRITE BEAD;AB,220ohm,1.6x0.8x0.8m

INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm

IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m

TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T

TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP

TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT

TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP

TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT

TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T

TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP

TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT

R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm

R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CHIP;10KOHM,5%,1/10W,DA,TP,2012

R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CHIP;10KOHM,5%,1/10W,DA,TP,2012

R-CHIP;220OHM,5%,1/10W,DA,TP,2012

R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CHIP;51KOHM,5%,1/10W,DA,TP,2012

AQ3

AQ4

AQ5

AQ51

AQ52

AQ55

AQ6

AQ7

AR201

AR202

AR203

AR21

AR22

AR24

AR26

AR35

AR36

AR38

AR4

R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CHIP;10KOHM,5%,1/10W,DA,TP,2012

R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CHIP;100OHM,5%,1/10W,DA,TP,2012

DVD-P331 ONLY

FR4

FR5

R-CHIP;100OHM,5%,1/10W,DA,TP,2012

FR54

FR541

FR55

FR56

FR59

FR6

R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CHIP;1KOHM,5%,1/10W,DA,TP,2012

R-CHIP;10KOHM,5%,1/10W,DA,TP,2012

R-CHIP;100OHM,5%,1/10W,DA,TP,2012

AR40

AR403

AR404

FR60

R-CHIP;10KOHM,5%,1/10W,DA,TP,2012

Samsung Electronics

4-4

Electrical Parts List

Loc.No

Part No

Description ; Specification

Remark

Loc.No

Part No

Description ; Specification

Remark

FY1

HC1

HC5

HC6

HCC1

HCC2

HE10

HE23

HE24

HE3

HE4

HE7

HE8

HE9

HL1

HL2

HL3

HOP1

HR1

HR15

HR16

HR19

HR2

HR20

HR21

HR22

HR23

HR24

HR3

2802-001094

2202-002037

2202-000173

2401-002075

2401-000913

2401-001250

2401-002075

2701-000114

2202-000121

1201-000163

2001-000666

2001-000515

2001-000837

2001-001015

2001-000837

2001-000273

2001-000800

2001-000666

2001-001015

2001-000800

2001-000290

2001-000527

2007-000070

2101-001090

0601-001587

3722-001465

3301-000297

2201-000828

2201-000129

AK39-00026A

3711-000178

2201-000795

2201-000828

2301-000180

2301-000417

2301-000423

2201-000916

2301-000129

0402-001195

0401-000101

0402-001196

0402-000012

0402-001194

0402-001438

RESONATOR-CERAMIC;4.0MHz,0.5%,TP,8x3x5.5

C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V

C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,1

C-AL;4.7uF,20%,50V,GP,TP,5x11,5

C-AL;22uF,20%,16V,GP,TP,5x11,5

C-AL;4.7uF,20%,35V,GP,TP,4x5,5

PDS34

PDS36

PDS51

PDS52

PER10

PER12

PES31

PES33

PES34

PES35

PES36

PES37

PES51

PES52

PES54

PES56

PES57

PES58

PFD01

PICS1

PICS2

PICS3

PICS5

PLS01

PLS02

PQL51

PQL52

PQL57

PQL58

PQR11

PQR12

PQS55

PQS56

PQS57

PQS58

PRD11

PRD31

PRD32

PRF01

PRL51

PRL52

PRL57

PRL58

PRR11

PRR12

PRR13

PRR14

PRR15

PRR17

PRS12

PRS31

PRS32

PRS33

PRS34

PRS54

PRS55

PTD1

0402-001438

0402-001195

0401-000101

0402-000127

2401-003365

2401-000905

2401-000302

2401-003059

2401-000118

2401-003046

2401-001353

2401-002042

2401-000302

2401-000598

2401-002144

2401-002165

2401-001353

3601-000194

0604-000186

AC14-12006D

1203-000242

1203-002185

AC29-00003A

AC27-12001N

0504-000142

0501-000442

0504-000126

0501-000303

0502-000405

0501-000442

0504-000142

0504-000118

0501-000616

2003-000119

2001-000221

2001-000515

2002-000121

2001-000449

2001-000290

2001-000273

2001-000449

2003-002117

2003-000314

2001-000003

2001-000734

2003-000994

2001-000440

2001-000429

2004-000869

2004-000459

2007-000493

2001-000062

AK26-00008A

1405-000186

0403-001036

0403-000717

3722-001375

3404-001164

2203-000192

DIODE-RECTIFIER;SHK55-65,60V,3A,AXIAL,BK

DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP

DIODE-SWITCHING;1N4148,100V,200mA,DO-35,

DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP

C-AL;150uF,20%,200V,GP,TP,18x25,7.5

C-AL;22uF,20%,16V,BP,-,6x11,2.5mm

C-AL;100uF,20%,25V,GP,TP,6.3x11,5

C-AL;1000UF,20%,16V,WT,TP,10X16,5

C-AL;1000uF,20%,10V,GP,TP,10x12.5,5

C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5

C-AL;470uF,20%,10V,GP,TP,8x11.5,5

C-AL;220uF,20%,10V,GP,TP,6.3x11,5

C-AL;100uF,20%,25V,GP,TP,6.3x11,5

C-AL;1uF,20%,50V,GP,TP,4x7,5

C-AL;47uF,20%,16V,GP,TP,5x11,5

C-AL;100uF,20%,16V,GP,TP,6.3x7,5

C-AL;470uF,20%,10V,GP,TP,8x11.5,5

FUSE-CARTRIDGE;250V,1A,FAST-ACTING,GLASS

PHOTO-COUPLER;TR,-,200mW,DIP-4,ST

IC;KA431Z,TO-92,TAPING

IC-POSI.FIXED REG.;7812,TO-220,3P,-,PLAS

IC-VOLTAGE REGULATOR;3RD13,TO-220,4P,402

FILTER LINE NOISE;-,20mH MIN,-,-,-

COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,-

TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T

TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9

TR-DIGITAL;KSR1101,NPN,200mW,4.7K/4.7K,S

DVD-P331 ONLY

C-AL;4.7uF,20%,50V,GP,TP,5x11,5

INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm

C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP

IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m

R-CARBON;33OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;51KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;9.1KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;51KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;33OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;9.1KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;5.1KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;22OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CHIP;0ohm,5%,1/16W,DA,TP,1608

DVD-P331 ONLY

TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T

TR-POWER;-,NPN,70W,TO-220,BK,10

HR4

HR5

HR6

HR7

TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9

TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T

TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-

TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L

R-METAL OXIDE;0.68ohm,5%,2W,AE,TP,6x16mm

R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-COMPOSITION;1Mohm,10%,1/2W,AA,TP,3.5x9

R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-METAL OXIDE(S);330Kohm,5%,1W,AA,TP,3.3

R-METAL OXIDE;47ohm,5%,2W,AE,TP,6x16mm

R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm

R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x

R-CARBON;1OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm

R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m

R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012

R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6.4MM

TRANS SWITCHING;EXINO,RCC,-,120V/230V,-,

VARISTOR;470V,2500A,17.5x7.5mm,TP

DIODE-ZENER;1N4745A,16V,5%,1W,DO-41,TP

DIODE-ZENER;MTZJ5.1B,5.1V,4.94-5.2V,500m

JACK-DIN;4P,-,NI,BLK,-

SWITCH-TACT;12V DC,50MA,100GF,7X7X6.7MM,

C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,

HR8

HRR1

HRR2

JR1

KVR1

LED54

MIC2

PBR11

PBS01

PCD02

PCD03

PCD11

PCD12

PCNS1

PCNS2

PCR01

PCR02

PCR13

PCR14

PCR15

PCS03

PCS32

PDD35

PDL51

PDR11

PDR12

PDS01

PDS02

PDS03

PDS04

PDS11

PDS31

PDS33

VR-ROTARY;20KOHM,20%,1/20W,SIDE

LED;ROUND,RED,3.1MM,635NM

JACK-PHONE;3P,6.43PI,AG,BLK,-

DVD-P331 ONLY

CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,

C-CERAMIC,DISC;3.3NF,20%,400V,Y5U,TP,15X

C-CERAMIC,DISC;0.1NF,10%,1KV,Y5P,TP,7X4M

CONNECT WIRE;-,1007,#26,1007,#26,6P,-,WH

CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA

C-CERAMIC,DISC;10NF,10%,400V,Y5P,TP,15X1

C-CERAMIC,DISC;3.3NF,20%,400V,Y5U,TP,15X

C-FILM,PEF;18nF,0.05,100V,TP,7.2x4.5x8.0

C-FILM,PEF;24nF,5%,50V,TP,6.5x10.5x4mm,5

C-FILM,PEF;3.3nF,5%,100V,TP,7x10x4.5mm,5

C-CERAMIC,DISC;0.1NF,10%,400V,Y5U,TP,10X

C-FILM,PEF;100nF,5%,50V,TP,10X9X4.3X5,5m

DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP

DIODE-SWITCHING;1N4148,100V,200mA,DO-35,

DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP

PVA1

PZR31

PZS51

SVJ1

SW1

VC1

VC106

VC12

VC14

DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP

DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP

DIODE-RECTIFIER;UG2D,200V,2A,DO-204AC,TP

DIODE-RECTIFIER;SHK55-65,60V,3A,AXIAL,BK

4-5

Samsung Electronics

Electrical Parts List

Loc.No

Part No

Description ; Specification

Remark

Loc.No

Part No

Description ; Specification

Remark

VC15

VC16

VC3

VC5

VC6

VCC3

VE1

VE11

VE12

VE3

VE5

VE7

VE9

VFD1

VIC1

VJ12

VJ14

VJ2

2203-000192

2203-000784

2401-002165

2401-002144

2401-002165

2401-001479

AK07-00003A

1204-001978

2007-000029

2701-000114

2001-000969

2007-000572

2007-000300

2007-000872

2007-000300

2007-000546

2001-000969

2001-000734

2001-000969

2007-000572

AH34-00007A

0403-000720

C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,

C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,2012

C-AL;100uF,20%,16V,GP,TP,6.3x7,5

C-AL;47uF,20%,16V,GP,TP,5x11,5

C-AL;100uF,20%,16V,GP,TP,6.3x7,5

C-AL;470uF,20%,10V,GP,TP,-,-

VF DISPLAY;-,HNV-08SS42,75X18.5MM,1/10,8

IC-VIDEO PROCESS;LA73054,-,36P,-,SSOP,7V

R-CHIP;0OHM,5%,1/10W,DA,TP,2012

INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm

R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CHIP;220OHM,5%,1/10W,DA,TP,2012

R-CHIP;10KOHM,5%,1/10W,DA,TP,2012

R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012

R-CHIP;10KOHM,5%,1/10W,DA,TP,2012

R-CHIP;20KOHM,5%,1/10W,DA,TP,2012

R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CHIP;220OHM,5%,1/10W,DA,TP,2012

SWITCH;-,50V DC,-,-,100MOHM,-,-,-,-

DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500

701

AK92-00148A

3404-001242

3708-001050

3809-001410

2001-000429

2001-000577

2001-000878

2001-000577

2001-000429

2001-000577

2001-000878

2001-000429

2001-000577

2001-000878

2001-000429

3404-001182

0601-000497

ASSY PCB-KEY;DVD-P392,KEY PCB ASS’Y

SWITCH-TACT;15V DC,20MA,250GF,12.4X12.4X

CONNECTOR-FPC/FFC/PIC;6P,1.25mm,ANGLE,SN

FFC CABLE-FLAT;30V,80C,100MM,6P,1.25MM,U

R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;2KOHM,5%,1/8W,AA,TP,1.8X3.2MM

R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2M

R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM

SWITCH-TACT;DC12V,50MA,100GF,6.0X6.0X5.0

LED;ROUND,GRN,3.1mm,565nm

DVD-P331 ONLY

JOY1

KCN1

KCN1B

KR1

KR10

KR11

KR2

KR3

KR4

KR5

KR6

KR7

KR8

KR9

KSW1

KSW2

KSW3

KSW4

KSW5

KSW6

KSW7

KSW8

KSW9

LED1

VJ3

VJ6

VL1

VR11

VR12

VR121

VR123

VR124

VR125

VR127

VR128

VR13

VR14

VR15

VR16

VR18

VR23

VR24

VSW1

VZD1

VZD11

VZD12

VZD2

-

MOTOR-LOAD ASSY;SM-2412L2,DP-9,-,-,-,-,-

CONNECT WIRE;-,#26,-,-,-,WHT/BLK,-,-,-,-

SWITCH-DETECTOR;5V DC,1A,DPST,30GF,-

HCN1

HSW1

AH39-00266B

3409-001138

Samsung Electronics

4-6

厂商	型号	描述	页数
3M	EXII-7720SC	[ EX II Series Capacitive Touch System Electronics ]	4 页
3M	EXII-7730HC	[ EX II Series Capacitive Touch System Electronics ]	4 页
3M	EXII-7760UC	[ EX II Series Capacitive Touch System Electronics ]	4 页
3M	EXII-ASIC-C	[ EX II Series Capacitive Touch System Electronics ]	4 页
ETC	EXINODVD-P230	DVD_ICs ： GMS81C2020 S5L1463 S5L1455 FAN8728 KS1455 PCM1742 LA73054 K6F8008U2M VADDISE5\n[ DVD_ICs:GMS81C2020 S5L1463 S5L1455 FAN8728 KS1455 PCM1742 LA73054 K6F8008U2M VADDISE5 ]	37 页
