IXKP24N60C5M

型号：

IXKP24N60C5M

品牌：

LITTELFUSE[ LITTELFUSE ]

页数：

4 页

PDF大小：

101 K

下载PDF手册
IXKP 24N60C5M
CoolMOS™ 1) Power MOSFET
ID25
VDSS
= 8.5A
= 600V
RDS(on) max = 0.165Ω
Fully isolated package
N-Channel Enhancement Mode
Low RDSon, High VDSS MOSFET
Ultra low gate charge
D
TO-220 FP
G
D
S
G
Preliminary data
S
Features
MOSFET
• fast CoolMOS™ 1) power MOSFET
Symbol
VDSS
Conditions
Maximum Ratings
4th generation
TVJ = 25°C
600
20
V
- High blocking capability
- Lowest resistance
VGS
V
- Avalanche rated for unclamped
inductive switching (UIS)
- Low thermal resistance
due to reduced chip thickness
• Enhanced total power density
ID25
ID90
TC = 25°C
TC = 90°C
8.5
6.0
A
A
EAS
EAR
single pulse
repetitive
522
0.79
mJ
mJ
ID = 7.9 A; TC = 25°C
dV/dt
MOSFET dV/dt ruggedness VDS = 0...480 V
50 V/ns
Applications
• Switched mode power supplies
(SMPS)
Symbol
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
• Uninterruptible power supplies (UPS)
• Power factor correction (PFC)
• Welding
min. typ. max.
RDSon
VGS = 10 V; ID = 10 A
150
3
165
mΩ
• Inductive heating
• PDP and LCD adapter
VGS(th)
IDSS
VDS = VGS; ID = 0.79 mA
VDS = 600 V; VGS = 0 V
2.5
3.5
1
V
TVJ = 25°C
TVJ = 125°C
µA
µA
10
1) CoolMOS™ is a trademark of
Infineon Technologies AG.
IGSS
VGS
=
20 V; VDS = 0 V
100
52
nA
Ciss
Coss
VGS = 0 V; VDS = 100 V
f = 1 MHz
2000
100
pF
pF
Qg
Qgs
Qgd
40
9
13
nC
nC
nC
VGS = 0 to 10 V; VDS = 400 V; ID = 12 A
td(on)
tr
td(off)
tf
12
5
50
5
ns
ns
ns
ns
VGS = 10 V; VDS = 400 V
ID = 12 A; RG = 3.3 Ω
RthJC
3.65 K/W
IXYS reserves the right to change limits, test conditions and dimensions.
© 2009 IXYS All rights reserved
20090209d
1 - 4
IXKP 24N60C5M
Source-Drain Diode
Symbol
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
min. typ. max.
IS
VGS = 0 V
12
A
VSD
IF = 12 A; VGS = 0 V
0.9
1.2
V
trr
QRM
IRM
390
7.5
38
ns
µC
A
IF = 12 A; -diF/dt = 100 A/µs; VR = 400 V
Component
Symbol
Conditions
Maximum Ratings
TVJ
Tstg
operating
-55...+150
-55...+150
°C
°C
Md
mounting torque
0.4 ... 0.6
Nm
Symbol
Conditions
Characteristic Values
min. typ. max.
RthCH
RthJA
with heatsink compound
thermal resistane juntion - ambient
0.50
80
K/W
K/W
Weight
2
g
IXYS reserves the right to change limits, test conditions and dimensions.
© 2009 IXYS All rights reserved
20090209d
2 - 4
IXKP 24N60C5M
TO-220 ABFP Outline
Ø P
A
E
A1
H
Q
D
L1
A2
L
c
b1
b
e
40
30
20
10
0
40
30
20
10
0
80
60
40
20
0
10V
TJ = 125°C
1 2V
TJ = 25°C
20 V
VGS
=
20 V
8 V
1 2V
6 V
10 V
=
VGS
8 V
5.5 V
6 V
5 V
5.5 V
4.5 V
5 V
4.5 V
0
40
80
120
160
0
5
10
15
20
0
5
10
[V]
15
20
TC [°C]
V
[V]
DS
V
DS
Fig. 1 Power dissipation
Fig. 2 Typ. output characteristics
Fig. 3 Typ. output characteristics
IXYS reserves the right to change limits, test conditions and dimensions.
© 2009 IXYS All rights reserved
20090209d
3 - 4
IXKP 24N60C5M
1.2
0.5
0.4
0.3
0.2
0.1
100
80
60
40
20
0
VDS > 2·RDS(on) max · ID
ID = 12 A
VGS = 10 V
TJV = 150°C
6.5 V
1
25 °C
5.5 V
10 V
0.8
0.6
0.4
0.2
6 V
5 V
=
VDS
7 V
98%
typ
TJ =150 °C
0
0
0
10
20
30
40
50
-60
-20
20
60
j [°C]
100
140
180
0
2
4
6
8
10
T
I D [A]
V
[V]
GS
Fig. 4 Typ. drain-source on-state
Fig. 5 Drain-source on-state resistance
Fig. 6 Typ. transfer characteristics
resistance characteristics of IGBT
10 2
10 1
10 0
10 -1
10 5
10
9
8
7
6
5
4
3
2
1
0
ID = 12 A pulsed
25 °C, 98%
VGS = 0 V
f = 1 MHz
10 4
10 3
10 2
10 1
10 0
150 °C, 98%
25 °C
VDS = 120 V
Ciss
50 °C
TJ =
40 0V
Coss
Crss
0
0.5
1
1.5
2
0
100
200
300
[V]
400
500
0
10
20
30
40
V
[V]
Q
gate [nC]
V
SD
DS
Fig. 7 Forward characteristic
of reverse diode
Fig. 8 Typ. gate charge
Fig. 9 Typ. capacitances
600
500
400
300
200
100
0
700
660
620
580
540
ID = 7.9 A
ID = 0.75 mA
-60
-20
20
60
100
140
180
20
60
100
140
180
T
j [°C]
T
j [°C]
Fig. 10 Avalanche energy
Fig. 11 Drain-source breakdown voltage
IXYS reserves the right to change limits, test conditions and dimensions.
20090209d
© 2009 IXYS All rights reserved
4 - 4
