QTH–060–01–F–D–DP–A
F-208
QTH–040–01–F–D–DP–A
®
QTH–020–01–L–D–DP–A–RT1
QTH-DP
0,50mm DIFFERENTIAL PAIR SERIES
Integral metal plane
for power or ground
Mates with:
QSH-DP, HQDP,
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?QTH-DP
HFHM, HFHM2
(See Application
Specific note)
Selectively
plated
Insulator Material:
Liquid Crystal Polymer
Contact Material:
®
Phosphor Bronze
Plating:
Au over 50µ" (1,27µm) Ni
Current Rating:
Contact: 1.0A @ 30°C
Temperature Rise
Ground Plane: 7.8A @ 30°C
Temperature Rise
STACK HEIGHT
LEAD
STYLE
Operating Temp Range:
-55°C to +125°C
(0,50mm)
.0197"
pitch
STANDARD
MATED HEIGHT
Voltage Rating:
Alignment
125 VAC mated with QSH-DP
& 5mm Stack Height
RoHS Compliant: Yes
(5,00) .198
–01
Pin
Processing conditions will
affect mated height.
0,50mm QTH/QSH-DP
5mm Stack Height
Rated @ -3dB Insertion Loss
Processing:
ALSO AVAILABLE
Max Processing Temp:
230°C for 60 seconds, or
260°C for 20 seconds 3x
Lead–Free Solderable: Yes
SMT Lead Coplanarity:
(0,10mm) .004" max (020-060)
(0,15mm) .006" max (080)
Board Stacking:
Note: Some lengths,
Differential Pair Signaling
9.5 GHz / 19 Gbps
Performance data for other stack heights
available at www.samtec.com?QTH-DP
styles and options are
Board Spacing Standoffs.
See SO Series.
non-standard, non-returnable.
OTHER
OPTION
PLATING
OPTION
NO. OF PAIRS
01
QTH
D
DP
A
For applications requiring
more than two connectors
per board or 80 pairs or higher,
contact ipg@samtec.com
–L
–020, –040, –060, –080
= 10µ" (0,25µm) Gold on
–K
(20 pairs per bank)
Signal Pins and Ground Plane,
Matte Tin on tails
= (7,00mm) .275" DIA
Polyimide Film
Pick & Place Pad
–F
= Gold Flash on Signal Pins
–TR
and Ground Plane, Matte Tin on tails
= Tape & Reel
(–060 positions maximum)
–RT1
(–060 positions maximum)
= Retention Option
(No. of Pairs/20) x (20,00) .7875
(20,00)
.7875
APPLICATION
01
02
SPECIFIC OPTION
(5,97)
.235
(7,11)
.280
• 30µ" (0,76µm) Gold (Specify -H plating
for Data Rate cable mating applications)
• 8mm, 11mm, 14mm, 15mm, 16mm,
19mm, 22mm, 25mm and 30mm
(0,50)
.0197
(1,50)
.0591
(0,20)
.008
(3,30)
.130
stack height (Caution: Some automatic
placement/inspection machines may
have component height restrictions.
Please consult machinery specifications.)
(0,76)
.030
(1,57)
.062
(4,27)
.168
• 100 Pairs
• Edge Mount & Guide Posts
• “Partitionable” (combine differential &
single-ended banks in same connector)
(1,57)
.062
DIA
(0,89)
.035
DIA
–RT1
–01
Call Samtec.
