(1/1)
001-01 / 20020221 / e81111_qvc80.fm
QVC80 Series
RF Modules
VCOs
For Cellular Phone/Single Band 8.5x5.5
FEATURES
ELECTRICAL CHARACTERISTICS
PART NO. : QVC800994RT-2132
APPLICATION : AMPS
• VCO for mobile communication equipment applications in the
roughly 0.5 to 2.5GHz frequency range.
• Compact, low profile and light weight type(L8.5×W5.5×T1.8mm,
190mg typ.).
Measuring conditions : Ta=25±2°C Vcc=2.8V
Min.
Typical Max.
value value value
Parameter
Unit
• Low voltage operation, low current consumption.
• Makes cost reduction possible.
Oscillation frequency
Current consumption
Output power [at F0]
MHz
mA
dBm
951
–
–2
994.5 1038
8.5
0
10
+2
SHAPES AND DIMENSIONS/
C/N ratio
[at F0, Offset frequency=60kHz,
B.W.=1Hz]
Tuning sensitivity [Vt=0.5 to 2.5V] MHz/V 50
Frequency pushing
[Vcc=2.8±0.15V]
Frequency pulling
[VSWR=2, all phases]
Spurious level
Operating temperature range
Storage temperature range
dBc/Hz
–
–119
–116
RECOMMENDED PC BOARD PATTERN
1
1
1
8.5±0.5
57.5
±0.2
65
±1
G
G
P
G
C
G
P
MHz
–
MHz
–
±0.4
±1
A
dBc
°C
°C
–
–25
–40
–20
–
–
–10
+75
+85
G
B
C
G
B
2.5
2.5
PART NO. : QVC802330RT-2134
Solder resist
1.37 1.37 1.37
Measuring conditions : Ta=25±2°C Vcc=2.2V
7-ø0.4 Through-hole
Dimensions in mm
C
G
B
Min.
Typical Max.
Parameter
Unit
value value value
Oscillation frequency
Current consumption
Output power [at F0]
C/N ratio
[at F0, Offset frequency=25kHz,
B.W.=1Hz]
Tuning sensitivity [Vt=0.5 to 2.5V] MHz/V 36
Frequency pushing
[Vcc=2.2±0.1V]
Frequency pulling
[VSWR=2, all phases]
Spurious level
Operating temperature range
Storage temperature range
MHz
mA
dBm
2300
–
0
2330
8
+3
2360
10
–
TERMINAL FUNCTIONS
P
B
C
G
Output
G
G
P
Power supply
Frequency tuning
GND
dBc/Hz
–
–100
–97
2.5±0.2 2.5±0.2
40
±1
44
±2
MHz
–
RECOMMENDED REFLOW
SOLDERING CONDITIONS
MHz
–
±1.5
±3
10s max.
dBc
°C
°C
–
–20
–40
–25
–
–
–10
+75
+85
240˚C max.
230˚C
200˚C
• Company and product names mentioned are registered trademarks.
150˚C
120s max.
40s max.
( )
Time s
• All specifications are subject to change without notice.
