Variable Coils
5mm TYPE 5P, 5PA
Frequency Range: 5P 0.2~2.0MHz, 5PA 0.1-1MHz
5P High Frequency 1-15MHz
Inductance Range: 5P 30mH-1mH, 5PA 0.8–4.2mH
5P High Frequency 1-40mH
Temperature Coefficient: TC (L) of 5P 850±350ppm/°C
5PA 750±450ppm/°C and
5P High Frequency 220±220ppm/°C.
With Internal Capacitor TC (F) of 5P or 5P
High Frequency 0±250ppm/°C
Optional Internal Capacitance Value:(1) (2)
(See selection guide)
(
): 5PA
Unit: mm
Features
• Low profile for compact designs.
STANDARD COILS SELECTION GUIDE
(1) The 5P is available with the following internal ceramic capacitors:
180, 470, 1500pF for standard AM applications.
(2) 5P High Frequency is available with internal ceramic capacitors,
18-47pF for standard FM applications.
TYPE 5P High Frequency
TYPE 5P
TOKO
Part
Number
Inductance
Range
Test
Frequency
(MHz)
TOKO
Part
Number
Inductance
Range
Test
Frequency
(MHz)
Q
(min.)
Q
(min.)
(mH)
(mH)
332PN-T1012Z
332PN-T1013Z
332PN-T1014Z
332PN-T1015Z
332PN-T1016Z
1.0±5%
1.2±5%
1.5±5%
1.8±5%
2.2±5%
55
55
55
55
55
7.96
7.96
7.96
7.96
7.96
5PNR-T1005Z
5PNR-T1006Z
5PNR-T1007Z
5PNR-T1008Z
5PNR-T1009Z
33.0±5%
39.0±5%
47.0±5%
56.0±5%
68.0±5%
40
40
40
40
40
2.52
2.52
2.52
2.52
2.52
332PN-T1017Z
332PN-T1018Z
332PN-T1019Z
332PN-T1020Z
332PN-T1021Z
2.7±5%
3.3±5%
3.9±5%
4.7±5%
5.6±5%
55
55
55
55
55
7.96
7.96
7.96
7.96
7.96
5PNR-T1010Z
5PNR-T1011Z
5PNR-T1012Z
5PNR-T1013Z
5PNR-T1014Z
82.0±5%
100.0±5%
120.0±5%
150.0±5%
180.0±5%
40
40
40
40
40
2.52
0.796
0.796
0.796
0.796
332PN-T1022Z
332PN-T1023Z
332PN-T1024Z
332PN-T1025Z
332PN-T1026Z
6.8±5%
8.2±5%
10.0±5%
12.0±5%
15.0±5%
55
55
55
55
55
7.96
7.96
2.52
2.52
2.52
5PNR-T1015Z
5PNR-T1016Z
5PNR-T1017Z
5PNR-T1018Z
5PNR-T1019Z
220.0±5%
270.0±5%
330.0±5%
390.0±5%
470.0±5%
40
40
40
40
40
0.796
0.796
0.796
0.796
0.796
332PN-T1027Z
332PN-T1028Z
332PN-T1029Z
18.0±5%
22.0±5%
27.0±5%
55
55
55
2.52
2.52
2.52
5PNR-T1020Z
5PNR-T1021Z
560.0±5%
680.0±5%
40
40
0.796
0.796
TYPE 5PA
TOKO
Part
Number
Inductance
Range
Test
Frequency
(kHz)
Q
(min.)
(mH)
451AN-0002Z
451AN-0001Z
451AN-0042Z
451AN-0041Z
0.8±5%
1.0±5%
2.0±5%
3.0±5%
65
50
40
50
796
252
252
252
